🔧 XT5 - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake calipers up/off, swap the old pads for new ones, and compress the caliper pistons so everything fits back together. This restores safe stopping power and prevents metal-to-metal rotor damage when pads are worn.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• 🛑 Support your XT5 with jack stands before working under/around the wheels.
• 🛑 Do not press the brake pedal while a caliper is removed.
• 🛑 Brake parts can be hot; let them cool before starting.
• 🛑 Avoid breathing brake dust; use brake cleaner, not compressed air.
• 🛑 Keep grease off pad/rotor friction surfaces.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• 19mm socket
• 1/2" breaker bar
• 1/2" torque wrench (40-200 Nm range)
• 3/8" torque wrench (5-60 Nm range)
• 3/8" ratchet
• 13mm socket
• 18mm socket
• Flat-blade screwdriver
• C-clamp or brake caliper piston compressor (specialty)
• Bungee cord or mechanic’s wire
• Brake parts cleaner
• Small wire brush
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware/clip kit - Qty: 1
• Silicone brake lubricant - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• 🧱 Park on level ground, shift to P, and set the parking brake.
• 🧱 Place wheel chocks behind the rear tires.
• 🧱 Loosen the front wheel lug nuts 1/2 turn using a 19mm socket and breaker bar before lifting.
• 🧱 Open the hood and locate the brake fluid reservoir. Fluid may rise when compressing pistons.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the front wheels

• Lift the front with a floor jack (rated 3-ton minimum) and support with jack stands (rated 3-ton minimum).
• Remove lug nuts using a 19mm socket and 3/8" ratchet or breaker bar.

Step 2: Locate the caliper and pads

• Turn the steering wheel to give yourself room (left for right side work, right for left side work).
• Identify the front brake caliper (the clamp over the rotor) and the caliper bracket behind it.

Step 3: Remove the caliper slide pin bolts

• Remove the two caliper slide pin bolts using a 13mm socket and 3/8" ratchet.
• Lift the caliper off the bracket. If it’s tight, gently pry with a flat-blade screwdriver.
• Hang the caliper from the suspension using a bungee cord or mechanic’s wire. Never let it hang by the hose.
• Reinstall/torque later: Torque to 38 Nm (28 ft-lbs).

Step 4: Remove the old pads and hardware clips

• Slide the old inner and outer pads out by hand.
• Remove the stainless hardware clips from the caliper bracket.
• Clean the bracket pad “lands” (where clips sit) using a small wire brush and brake parts cleaner.

Step 5: Compress the caliper piston

• Place an old pad against the piston face, then slowly compress the piston using a C-clamp or brake caliper piston compressor (specialty).
• Check the brake fluid reservoir while compressing; remove excess if it gets too high using shop towels. Compress slowly to avoid overflow.

Step 6: Install new hardware clips and lubricate correctly

• Install new hardware clips onto the bracket by hand.
• Apply a thin film of silicone brake lubricant where the pad ears contact the clips.
• Do not lubricate the pad friction material or rotor face.

Step 7: Install the new pads

• Install the new inner and outer pads into the bracket.
• If one pad has a wear indicator/squealer, install it in the same position as the original on that wheel.

Step 8: Reinstall the caliper

• Lower the caliper over the new pads.
• Install the slide pin bolts using a 13mm socket and 3/8" ratchet.
• Final tighten with a 3/8" torque wrench (5-60 Nm range): Torque to 38 Nm (28 ft-lbs).

Step 9: Repeat on the other front wheel

• Repeat Steps 2–8 on the other side.
• Do one side at a time to avoid mixing parts.

Step 10: Reinstall wheels and torque lug nuts

• Reinstall wheels and hand-thread lug nuts.
• Lower your XT5 to the ground.
• Torque lug nuts in a star pattern using a 1/2" torque wrench (40-200 Nm range): Torque to 190 Nm (140 ft-lbs).

---

✅ After Repair

• 🧪 Before driving, pump the brake pedal 10–15 times until it feels firm.
• 🧪 Check the brake fluid level and top off only if needed.
• 🧪 Do a slow test drive and confirm no pulling, grinding, or warning lights.
• 🧪 Pad bed-in (break-in): make 8–10 moderate stops from 30–35 mph, letting brakes cool a bit between stops.
• 🧪 Recheck lug nut torque after 25–50 miles using a 1/2" torque wrench (40-200 Nm range): Torque to 190 Nm (140 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $300-$550 (parts + labor)

DIY Cost: $70-$180 (parts only)

You Save: $230-$370 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
