🔧 Front Brake Pads - Replacement

Replacing the front brake pads on your Prius v means removing the front calipers, swapping the pads, and compressing the caliper pistons before reassembly. Since this is a hybrid, you should keep the car in a safe, powered-down state so the brake system does not wake up unexpectedly.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• Keep the vehicle in READY mode OFF and the key/fob away from the car.
• Do not press the brake pedal with a caliper removed.
• Use jack stands on solid ground; never rely on a jack alone.
• Front brakes can be hot; let them cool before starting.
• Use brake cleaner only in a well-ventilated area.
• No battery disconnect is normally required for front pad replacement.
• Use care when compressing the piston; brake fluid may rise in the reservoir.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 14mm socket
• 17mm socket
• Ratchet
• Breaker bar
• Torque wrench
• Flat-blade screwdriver
• Brake caliper piston compressor tool (specialty)
• C-clamp
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Wire brush
• Brake cleaner
• Shop towels
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake pad hardware kit - Qty: 1
• Brake caliper slide pin grease - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Shift to PARK and power the car fully OFF.
• Chock the rear wheels before lifting the front.
• Loosen the front lug nuts slightly before raising the vehicle.
• Open the hood and check the brake fluid level before compressing pistons.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the front of the car

• Use the floor jack to lift the front of the Prius v at the approved center lift point.
• Support both front sides with jack stands.
• Remove the front wheels with the 14mm socket.
• Keep the key fob away from the car.

Step 2: Remove the caliper

• Use the 17mm socket and ratchet to remove the two caliper slide pin bolts.
• Lift the caliper off the bracket.
• Hang the caliper with a hook or support it so the hose is not stretched.
• Torque on reassembly: 34 Nm (25 ft-lbs)

Step 3: Remove the old pads and hardware

• Slide the old pads out of the bracket.
• Remove the anti-rattle clips and pad shims with a flat-blade screwdriver.
• Clean the bracket and contact points with brake cleaner and a wire brush.
• Do not leave rust under the clips.

Step 4: Compress the caliper piston

• Use the brake caliper piston compressor tool (specialty) or a C-clamp to slowly push the piston back in.
• Watch the brake fluid reservoir while compressing.
• Stop if fluid starts to overflow.
• Compress slowly and evenly.

Step 5: Install the new hardware and pads

• Install the new anti-rattle clips and shims from the brake pad hardware kit.
• Apply a thin layer of brake caliper slide pin grease to the pad contact points and slide pins.
• Install the new front brake pads into the bracket.
• Make sure the wear indicator, if equipped, is positioned the same way as the old pad.

Step 6: Reinstall the caliper

• Set the caliper back over the new pads.
• Install the caliper slide pin bolts using the 17mm socket.
• Torque to 34 Nm (25 ft-lbs)
• Spin the rotor by hand to confirm it turns freely.

Step 7: Reinstall wheels and lower the car

• Install the front wheels and hand-tighten the lug nuts with the 14mm socket.
• Lower the car with the floor jack.
• Torque the lug nuts in a star pattern to 103 Nm (76 ft-lbs).

Step 8: Restore pedal feel

• Before moving the car, pump the brake pedal slowly with your foot until it becomes firm.
• Check the brake fluid level and top off only if needed.
• Do not drive until the pedal feels firm.

---

✅ After Repair

• Test the brakes at very low speed first.
• Listen for scraping, clicking, or grinding.
• Recheck lug nut torque after the first drive.
• Follow a gentle brake break-in for the first 200 miles.
• If the pedal feels soft, stop and inspect immediately.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$500 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $190-$320 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
