🔧 Front Brake Pads - Replacement

The front brake pads on your Land Cruiser are a wear item and should be replaced when they are thin, noisy, or causing vibration. This job also gives you a chance to inspect the rotors, caliper hardware, and brake fluid level before putting everything back together.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Brake dust can be harmful, so avoid blowing it off with compressed air.
• Use jack stands; never rely on the floor jack alone.
• Keep fingers clear of the caliper and rotor when compressing the piston.
• If the brake fluid reservoir is full, compressed pistons can cause overflow.
• Your Land Cruiser does not use an electronic parking brake on the front axle, so no EPB service mode is needed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 21mm socket
• 14mm socket
• Ratchet
• Breaker bar
• Torque wrench
• Flat-blade screwdriver
• Brake caliper compression tool (specialty)
• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Wire brush
• Brake cleaner
• Gloves
• Safety glasses
• Wire hanger or bungee cord

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake pad hardware kit - Qty: 1
• Brake grease - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Chock the rear wheels before lifting the front.
• Loosen the front lug nuts before raising the vehicle.
• Make sure the brake pedal is not pressed while the caliper is off.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen and raise the front

• Use a 21mm socket and breaker bar to loosen the front lug nuts while the tire is still on the ground.
• Lift the front of the Land Cruiser with a floor jack and support it with jack stands.
• Remove the front wheel.

Step 2: Remove the caliper

• Use a 14mm socket and ratchet to remove the caliper slide bolts.
• Lift the caliper off the bracket carefully.
• Hang the caliper with a wire hanger or bungee cord; do not let it hang by the hose.

Step 3: Remove the old pads and hardware

• Pull the old brake pads out of the bracket.
• Remove the pad clips and hardware.
• Clean the bracket contact points with brake cleaner and a wire brush.
• Clean metal surfaces help the pads slide smoothly.

Step 4: Compress the caliper piston

• Use a brake caliper compression tool (specialty) to push the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing.
• If needed, remove a small amount of fluid from the reservoir to prevent overflow.

Step 5: Install new hardware and pads

• Install the new pad clips and hardware from the brake pad hardware kit.
• Apply a thin layer of brake grease to the pad ears and contact points only.
• Install the new front brake pads into the bracket.

Step 6: Reinstall the caliper

• Slide the caliper back over the new pads.
• Install the slide bolts with the 14mm socket.
• Torque to 34 Nm (25 ft-lbs).

Step 7: Reinstall the wheel

• Put the wheel back on and start all lug nuts by hand.
• Lower the vehicle enough for the tire to touch the ground.
• Use the 21mm socket and torque wrench to tighten the lug nuts in a star pattern.
• Torque to 131 Nm (97 ft-lbs).

Step 8: Repeat on the other side

• Replace the pads on the opposite front wheel the same way.
• Always replace brake pads in pairs.

---

✅ After Repair

• Press the brake pedal several times before moving the vehicle.
• Check brake fluid level and top off if needed.
• Test the brakes at low speed first.
• Listen for noise and confirm the pedal feels firm.
• Bed in the new pads by making several gentle stops, then a few moderate stops.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$600 (parts + labor)

DIY Cost: $80-$180 (parts only)

You Save: $220-$420 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
