🔧 ES - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake calipers up, swap the old pads for new ones, then torque everything back to spec. This restores safe braking and prevents rotor damage when pads get thin.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the car with jack stands; never rely on a floor jack alone.
• ⚠️ Brakes create dust—avoid breathing it; use brake cleaner, not compressed air.
• ⚠️ Do not press the brake pedal with a caliper removed; the piston can pop out and leak.
• ⚠️ Brake fluid can damage paint; wipe spills immediately.
• 🔋 Battery disconnect is not required for front pads on your ES.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 21mm socket
• Breaker bar (1/2-inch drive)
• Torque wrench (10-200 ft-lbs range)
• 14mm socket
• 17mm socket
• Ratchet (1/2-inch drive)
• Ratchet (3/8-inch drive)
• Flat trim/pry tool
• C-clamp brake piston compressor
• Bungee cord
• Wire brush
• Brake parts cleaner
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front pad hardware kit (abutment clips) - Qty: 1
• Disc brake caliper grease (silicone) - Qty: 1
• Brake fluid (DOT 3) - Qty: 1
• Front brake rotors - Qty: 2 (optional if worn/grooved)

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind both rear tires.
• Loosen the front lug nuts 1/2 turn with a 21mm socket and breaker bar before lifting.
• Open the hood and loosen the brake fluid reservoir cap slightly (don’t remove it completely). This helps the caliper piston compress.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front of the car

• Lift the front with a floor jack (rated 2-ton minimum) at the front center jacking point.
• Set the car onto jack stands (rated 2-ton minimum) at the factory support points.
• Give the car a gentle shake to confirm it’s stable.

Step 2: Remove the front wheels

• Remove lug nuts using a 21mm socket and ratchet (1/2-inch drive).
• Remove the wheels and set them aside.

Step 3: Locate the caliper and remove the slide pin bolts

• Turn the steering (by hand at the wheel hub) to give yourself more room to work.
• Remove the 2 caliper slide pin bolts using a 14mm socket and ratchet (3/8-inch drive).
• Slide pins are the bolts that let the caliper “float”.

Step 4: Swing the caliper up and support it

• Carefully lift/swing the caliper off the pads.
• Hang the caliper with a bungee cord so it doesn’t pull on the brake hose.
• Never let the caliper dangle by the hose.

Step 5: Remove old pads and hardware

• Pull the inner and outer pads out by hand. If they’re stuck, use a flat trim/pry tool gently.
• Remove the stainless pad abutment clips (hardware) from the bracket.
• Clean the bracket “pad landing” areas with a wire brush and brake parts cleaner.

Step 6: Compress the caliper piston

• Place an old pad against the piston face, then slowly compress the piston using a C-clamp brake piston compressor.
• Watch the brake fluid level in the reservoir; remove excess with towels if it looks like it may overflow.
• Compress slowly to protect seals.

Step 7: Install new hardware and pads (with correct grease locations)

• Install new abutment clips from the front pad hardware kit onto the bracket.
• Apply a thin film of disc brake caliper grease (silicone) where the pad ears touch the clips (metal-to-metal contact points).
• Install the new pads into the bracket. Make sure they slide freely.
• If your new pads include wear indicators, they must match the original orientation.
• Do not grease pad friction material or rotor.

Step 8: Reinstall the caliper and torque the bolts

• Lower the caliper over the new pads.
• Install the 2 slide pin bolts by hand first to avoid cross-threading.
• Tighten using a 14mm socket and torque wrench: Torque to 34 Nm (25 ft-lbs).

Step 9: Reinstall wheels and torque lug nuts

• Reinstall the wheels and hand-thread lug nuts.
• Lower the car off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern with a torque wrench: Torque to 103 Nm (76 ft-lbs).

Step 10: Build pedal pressure before moving the car

• With the engine off, pump the brake pedal 8–15 times until it feels firm.
• Check the brake fluid level and top off with brake fluid (DOT 3) if needed.
• Tighten the reservoir cap.

---

✅ After Repair

• Start the engine and hold the brake pedal; it should feel firm and not sink.
• Do a slow test stop in a safe area. Listen for grinding or clunks.
• Pad bed-in (general Lexus-friendly method): make 6–10 moderate stops from ~40 mph down to ~10 mph, letting brakes cool slightly between stops.
• Recheck brake fluid level after the test drive.
• If you replaced rotors or opened the hydraulic system, a proper brake bleed may be required.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$550 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $120-$490 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.8 hours.

---
