🔧 Front Brake Pads - Replacement

The front brake pads on your F-150 can be replaced with the wheels on the truck and the front brakes safely supported. You’ll remove the caliper, swap the pads, and then compress the caliper piston before reassembly. This is a straightforward beginner job if you work cleanly and keep brake fluid from overflowing.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work on a flat surface and chock the rear wheels before lifting the front.
• Use jack stands; never rely on a floor jack alone.
• Brake dust can be harmful. Wear safety glasses and gloves.
• Do not press the brake pedal with the caliper removed.
• Keep brake fluid off painted surfaces.
• No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated for truck weight)
• Wheel chocks
• 21mm lug wrench or socket
• 13mm socket
• 15mm socket
• Ratchet
• Breaker bar
• Torque wrench
• Brake caliper compression tool (specialty)
• Bungee cord or mechanic’s wire
• Flat-blade screwdriver
• Wire brush
• Brake cleaner
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake hardware kit - Qty: 1
• Brake grease - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Put the transmission in Park.
• Loosen the front lug nuts before lifting the truck.
• Lift the front and support it securely on jack stands.
• Remove the front wheels.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the wheel

• Use a 21mm lug wrench or socket to remove the lug nuts.
• Remove the wheel and set it aside.

Step 2: Remove the caliper

• Use a 13mm socket to remove the caliper guide pin bolts.
• Lift the caliper off the bracket carefully.
• Hang the caliper with a bungee cord or mechanic’s wire so the brake hose is not stretched.

Step 3: Remove the old pads

• Slide the old brake pads out of the caliper bracket.
• Remove any pad clips or hardware from the bracket.
• Use a wire brush and brake cleaner to clean rust and debris from the pad contact points.

Step 4: Compress the caliper piston

• Use a brake caliper compression tool (specialty) to slowly push the piston back into the caliper.
• Check the brake fluid reservoir while compressing; remove a little fluid if it starts to overflow.
• Go slow and keep it straight.

Step 5: Install the new pads and hardware

• Install the new pad clips or hardware from the brake hardware kit.
• Apply a thin layer of brake grease to the pad ears and contact points only.
• Install the new front brake pads in the bracket.

Step 6: Reinstall the caliper

• Lower the caliper over the new pads.
• Use a 13mm socket to reinstall the guide pin bolts.
• Torque to 34 Nm (25 ft-lbs).

Step 7: Reinstall the wheel

• Put the wheel back on and start the lug nuts by hand.
• Lower the truck enough for the tire to touch the ground.
• Use a 21mm lug wrench or socket to snug the lug nuts in a star pattern.
• Torque to 204 Nm (150 ft-lbs).

Step 8: Repeat on the other side

• Replace the pads on the opposite front brake using the same steps.
• Front pads should always be replaced as a set on both sides.

---

✅ After Repair

• Pump the brake pedal slowly until it feels firm before driving.
• Check the brake fluid level and top off if needed.
• Test the brakes at low speed first.
• Expect new pads to need a short break-in period.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $70-$180 (parts only)

You Save: $180-$270 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
