🔧 Expedition - Front Brake Pad Replacement

Replacing the front brake pads restores safe stopping power and prevents rotor damage when pads get thin. You’ll remove the front calipers, swap the pads, compress the caliper pistons, then torque everything back to spec.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

Assumption: Factory front brakes with standard single-piston sliding calipers; torque specs can vary by package.

---

⚠️ Safety & Precautions

• 🛑 Support your Expedition with jack stands before working under it.
• 🛑 Never let a brake caliper hang by the brake hose; it can damage the hose.
• 🛑 Brake dust is harmful; use brake cleaner, not compressed air.
• 🛑 Keep grease off pad friction surfaces and rotors.
• 🔋 Battery disconnect is not required for front pad replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 13mm socket
• Ratchet (3/8")
• Breaker bar (1/2")
• Torque wrench (20-250 ft-lbs)
• Flathead screwdriver
• Brake caliper hanger (specialty)
• Brake caliper piston compressor (specialty)
• Wire brush
• Brake parts cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware/clip kit - Qty: 1
• High-temperature silicone brake grease - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear tires.
• Loosen the front lug nuts 1/2 turn using a 21mm socket and breaker bar before lifting.
• Open the hood and locate the brake fluid reservoir; make sure it isn’t overfilled (fluid level rises when you compress pistons).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Lift the front with a floor jack (rated 3-ton minimum) at the proper front jacking point.
• Set the frame onto jack stands (rated 3-ton minimum) and gently shake the vehicle to confirm it’s stable.

Step 2: Remove the front wheels

• Remove the lug nuts using a 21mm socket and ratchet (3/8").
• Remove the wheel and slide it under the frame as an extra safety backup.

Step 3: Remove the brake caliper (do not disconnect the hose)

• Turn the steering wheel to give yourself room to work.
• Remove the caliper slide pin bolts using a 13mm socket and ratchet (3/8").
• Carefully lift the caliper off the bracket.
• Support the caliper with a brake caliper hanger (specialty); it’s a hook/strap that holds the caliper so the hose isn’t stressed.

Step 4: Remove the old pads and hardware

• Pull the old inner and outer pads out of the bracket by hand.
• Remove the old stainless pad clips/hardware using a flathead screwdriver.
• Spray the bracket pad lands (where clips sit) with brake parts cleaner spray and scrub with a wire brush.
• Tip: Clean metal helps prevent pad sticking.

Step 5: Compress the caliper piston

• Place an old pad against the piston face to protect it.
• Compress the piston slowly using a brake caliper piston compressor (specialty); it’s a tool that presses the piston back evenly so new thicker pads will fit.
• Watch the brake fluid reservoir as you compress; stop if it gets near the max line.

Step 6: Install new hardware and pads

• Install the new pad clips/hardware into the bracket by hand.
• Apply a thin film of high-temperature silicone brake grease to the bracket pad lands where the pads slide (not on the pad friction material).
• Install the new pads into the bracket in the same positions as removed.

Step 7: Reinstall the caliper and torque fasteners

• Lower the caliper back over the new pads.
• Install the caliper slide pin bolts by hand first (to avoid cross-threading), then tighten with a 13mm socket and ratchet (3/8").
• Tighten with a torque wrench (20-250 ft-lbs): Torque to 34 Nm (25 ft-lbs) for the caliper slide pin bolts.
• If you removed the caliper bracket (only if needed), tighten bracket bolts with a 21mm socket and torque wrench (20-250 ft-lbs): Torque to 224 Nm (165 ft-lbs).

Step 8: Reinstall wheels and torque lug nuts

• Reinstall the wheel and hand-thread lug nuts.
• Snug lug nuts in a star pattern using a 21mm socket.
• Lower the vehicle off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Final-tighten lug nuts in a star pattern with a torque wrench (20-250 ft-lbs): Torque to 203 Nm (150 ft-lbs).

---

✅ After Repair

• With the engine OFF, pump the brake pedal 10-15 times until it feels firm (this seats the pads against the rotors).
• Check the brake fluid level and top off only if needed.
• Start the engine and confirm the pedal stays firm.
• Road test at low speed first; confirm no pulling, grinding, or warning lights.
• Bed-in the pads: make 6-10 medium stops from ~40 mph down to ~10 mph, allowing short cool-down time between stops.
• Tip: Avoid hard stops for 200 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$650 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $240-$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
