🔧 Front Brake Pads - Replacement

Replacing the front brake pads on your XC90 restores braking performance and helps prevent rotor damage. On this model, the job is straightforward if you work cleanly and keep the caliper properly supported so the brake hose is never strained.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work on level ground and chock the rear wheels before lifting the front.
• Use jack stands under the vehicle; never rely on the jack alone.
• Do not let the caliper hang by the brake hose.
• Brake dust can be harmful. Wear safety glasses and gloves.
• Front brakes are hot after driving. Let them cool first.
• No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• 19mm lug socket
• Breaker bar
• Ratchet
• Torx T40 screwdriver
• 13mm socket
• Brake caliper compression tool (specialty)
• Torque wrench
• Bungee cord or mechanic’s hook
• Wire brush
• Brake cleaner
• Gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake pad wear sensor - Qty: 1
• Brake grease - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Loosen the front wheel lug bolts slightly before lifting.
• Keep the ignition off and key away from the vehicle.
• Replace pads on both sides together.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen and lift the front

• Use the 19mm lug socket and breaker bar to loosen the front wheel bolts 1/4 turn.
• Lift the front of the XC90 with the floor jack and support it with jack stands.
• Remove the front wheel bolts and wheel.

Step 2: Remove the caliper

• Use the Torx T40 screwdriver to remove the caliper guide pin bolts.
• Lift the caliper off the bracket carefully.
• Hang the caliper with a bungee cord or mechanic’s hook.
• Never let the hose carry the weight.

Step 3: Remove the old pads and sensor

• Slide the old brake pads out of the caliper bracket.
• If equipped, disconnect the pad wear sensor from the pad and harness.
• Note the position of any pad clips before removing them.

Step 4: Clean and inspect

• Use the wire brush and brake cleaner to clean the caliper bracket and pad contact points.
• Check the rotor for heavy grooves, cracks, or blue heat spots.
• If the slider pins are dry or sticky, clean and lubricate them with brake grease.

Step 5: Compress the caliper piston

• Use the brake caliper compression tool (specialty) to push the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing the piston so it does not overflow.
• Compress slowly and evenly.

Step 6: Install the new pads

• Install the new pad clips into the bracket if included with the pad set.
• Apply a thin layer of brake grease to the pad ears and contact points.
• Install the new pads in the same positions as the old ones.
• Connect the new brake pad wear sensor if your XC90 is equipped with one.

Step 7: Reinstall the caliper

• Slide the caliper back over the new pads.
• Install the guide pin bolts with the Torx T40 screwdriver.
• Torque to 35 Nm (26 ft-lbs).

Step 8: Reinstall the wheel

• Put the wheel back on and hand-start the lug bolts.
• Lower the vehicle enough for the tire to touch the ground.
• Use the 19mm lug socket and torque wrench to tighten the lug bolts in a star pattern.
• Torque to 140 Nm (103 ft-lbs).

Step 9: Repeat on the other side

• Repeat the same procedure on the opposite front wheel.
• Always replace front pads in pairs.

---

✅ After Repair

• Before driving, pump the brake pedal several times until it feels firm.
• Check the brake fluid level and top off if needed.
• Test the brakes at low speed first.
• Expect a short bedding-in period. Avoid hard stops for the first 200 miles.
• If the brake wear message stays on, inspect the sensor connection and clear codes with a scan tool if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $90-$220 (parts only)

You Save: $260-$430 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
