🔧 Tucson - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake calipers up, swap the old pads for new ones, and reassemble with proper torque. This restores safe stopping power and prevents metal-to-metal brake damage.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• 🛑 Support your Tucson on jack stands—never rely on a floor jack alone.
• 🧤 Brake dust is irritating—wear gloves and safety glasses; avoid blowing dust with compressed air.
• 🔥 Brakes can be hot—let everything cool before touching the caliper/rotor.
• 🧪 Brake fluid damages paint—cover the fender and clean spills immediately.
• ⚠️ Do not press the brake pedal while a caliper is off the rotor.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-150 ft-lbs range)
• 14mm socket
• 17mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-80 ft-lbs range)
• Flathead screwdriver
• C-clamp (6" minimum)
• Caliper hanger hook (specialty)
• Wire brush
• Brake cleaner spray
• Shop towels
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, put the shifter in P, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Loosen the front lug nuts about 1/2 turn using a 21mm socket and breaker bar before lifting.
• Open the hood and loosen the brake fluid reservoir cap (leave it sitting on top). This helps the caliper piston retract.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the front wheels

• Lift the front using a floor jack (rated 3-ton minimum) at the front jacking point, then set the Tucson onto jack stands (rated 3-ton minimum).
• Remove the lug nuts with a 21mm socket and 3/8" drive ratchet, then remove both front wheels.

Step 2: Locate the caliper and remove the slide pin bolts

• Turn the steering wheel to give yourself room (left to work on the right side; right to work on the left side).
• On the back of the caliper, remove the two caliper slide pin bolts using a 14mm socket and 3/8" drive ratchet.
• Slide pins are the caliper’s moving bolts.

Step 3: Swing the caliper up and support it

• Carefully swing the caliper up off the pads.
• Hang the caliper from the strut spring using a caliper hanger hook (specialty).
• Do not let the caliper hang by the brake hose.

Step 4: Remove the old pads and hardware

• Pull the inner and outer pads out by hand.
• Remove the stainless pad clips (abutment clips) from the caliper bracket using a flathead screwdriver.

Step 5: Remove the caliper bracket (if needed for hardware cleaning)

• If you need more access to clean the bracket properly, remove the caliper bracket bolts using a 17mm socket and breaker bar.
• Reinstall later and Torque to 78-98 Nm (58-72 ft-lbs) using a 1/2" drive torque wrench (20-150 ft-lbs range).
• If hardware fights you, remove the bracket.

Step 6: Clean the bracket pad lands and install new clips

• Spray the bracket area with brake cleaner spray and wipe with shop towels.
• Lightly scrub the pad “lands” (where the clips sit) using a wire brush.
• Snap the new abutment clips from the hardware kit into place by hand.

Step 7: Retract the caliper piston

• Place one old pad against the piston face, then use a C-clamp (6" minimum) to slowly push the piston back into the caliper.
• Check the brake fluid reservoir level as you compress; stop if it gets near the top.
• Slow pressure prevents seal damage.

Step 8: Grease contact points and install new pads

• Apply a thin film of brake caliper slide pin grease (silicone) to the pad ears where they touch the clips (do not get grease on pad friction material).
• Install the inner and outer pads into the bracket in the same orientation as removed.

Step 9: Reinstall caliper and torque slide pin bolts

• Lower the caliper over the new pads.
• Install the slide pin bolts using a 14mm socket and 3/8" drive ratchet.
• Torque to 22-32 Nm (16-24 ft-lbs) using a 3/8" drive torque wrench (10-80 ft-lbs range).

Step 10: Reinstall wheels and torque lug nuts

• Reinstall both front wheels and hand-thread the lug nuts.
• Lower the Tucson off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern with a 21mm socket and 1/2" drive torque wrench (20-150 ft-lbs range).
• Torque to 88-108 Nm (65-80 ft-lbs).

---

✅ After Repair

• With the engine off, pump the brake pedal slowly 10-15 times until it feels firm.
• Top off brake fluid only if needed, then reinstall the reservoir cap securely.
• Do a low-speed test in a safe area: confirm normal pedal feel and no pulling/noise.
• Bed-in the pads: make 6-10 gentle stops from ~30 mph to 5 mph, letting brakes cool between stops.
• Recheck for leaks and make sure no warning lights appear.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $50-$140 (parts only)

You Save: $110-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
