🔧 Forester - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake calipers out of the way, replace the pads and hardware, then reinstall and bed-in the new pads. This restores safe stopping power and prevents rotor damage when pads get thin.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• 🛑 Support your Forester with jack stands before working underneath.
• 🛑 Brake dust is harmful—use brake cleaner, not compressed air.
• 🛑 Brakes may be hot—let components cool before touching.
• 🛑 Do not press the brake pedal with the caliper removed.
• 🛑 Watch brake fluid level when compressing the piston (it can overflow).
• 🛑 Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• 19mm socket
• Breaker bar (1/2" drive)
• Torque wrench (10-200 Nm range)
• 14mm socket
• 17mm socket
• Ratchet (1/2" drive)
• Ratchet (3/8" drive)
• Flathead screwdriver
• C-clamp (6" minimum)
• Brake caliper hanger hook (specialty)
• Wire brush
• Brake cleaner spray
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Brake caliper grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• 🧱 Park on level ground and place wheel chocks behind the rear wheels.
• 🧱 Set the parking brake and put the shifter in P.
• 🧱 Pop the hood and check the brake fluid reservoir level; if it’s near MAX, be ready to remove a little fluid later (compressing pistons raises the level).
• 🧱 Loosen the front lug nuts about 1/2 turn using a 19mm socket and breaker bar before lifting.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Use a floor jack to lift the front of your Forester at the front jack point.
• Place jack stands under the proper front support points and lower onto the stands.
• Give the vehicle a gentle shake to confirm it’s stable.

Step 2: Remove the front wheels

• Remove the lug nuts using a 19mm socket and ratchet.
• Remove both front wheels and set them aside.

Step 3: Locate the caliper and caliper bracket

• The caliper is the part that squeezes the pads; the caliper bracket is the fixed mount the pads sit in.
• Turn the steering wheel to give yourself more room to work on the side you’re doing.

Step 4: Remove the caliper slide pin bolts

• Use a 14mm socket and ratchet to remove the two caliper slide pin bolts.
• Slide pins are the caliper’s guide bolts.

Step 5: Hang the caliper safely

• Lift the caliper off the bracket.
• Support it with a brake caliper hanger hook so it hangs from the strut spring.
• Do not let the caliper hang by the brake hose.

Step 6: Remove old pads and hardware

• Pull the inner and outer pads out of the bracket by hand.
• If they’re stuck, gently pry with a flathead screwdriver.
• Remove the pad abutment clips (hardware) from the bracket.

Step 7: Clean the bracket pad lands

• Spray the bracket area with brake cleaner spray.
• Use a wire brush to clean the pad contact areas (“pad lands”) where the clips sit.
• Wipe away residue, then let everything dry.

Step 8: Install new abutment clips and grease contact points

• Install the new abutment clips from your hardware kit into the bracket.
• Apply a thin film of brake caliper grease (silicone) where the pad ears touch the clips.
• Keep grease off pad friction surfaces.

Step 9: Compress the caliper piston

• Place one old pad against the piston face.
• Use a C-clamp (6" minimum) to slowly press the piston fully back into the caliper.
• Check the brake fluid reservoir while compressing and prevent overflow.

Step 10: Install the new pads

• Install the new inner and outer pads into the bracket.
• Make sure the pads slide freely in the clips (they should not bind).

Step 11: Reinstall the caliper

• Lower the caliper over the new pads.
• Install the two slide pin bolts by hand first to avoid cross-threading.
• Tighten using a 14mm socket and torque wrench: Torque to 27 Nm (20 ft-lbs).

Step 12: Repeat on the other front side

• Repeat Steps 4-11 for the other front wheel.
• Always replace pads as a pair.

Step 13: Reinstall wheels and torque lug nuts

• Reinstall both front wheels and hand-thread the lug nuts.
• Lower the vehicle using the floor jack, remove jack stands, then fully lower.
• Tighten lug nuts in a star pattern using a 19mm socket and torque wrench: Torque to 120 Nm (89 ft-lbs).

---

✅ After Repair

• 🧪 Pump the brake pedal 8-12 times until it feels firm (this seats the pistons).
• 🧪 Check brake fluid level and top off only if needed.
• 🧪 Test brakes at low speed in a safe area before normal driving.
• 🧪 Perform a gentle bed-in: 6-10 moderate stops from ~30-40 mph with cool-down driving between stops.
• 🧪 Listen for abnormal scraping or pulling; recheck your work if noticed.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $50-$140 (parts only)

You Save: $110-$400 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
