🔧 CX-5 - Front Brake Pad Replacement

Replacing the front brake pads restores stopping power and prevents rotor damage from worn pads. On your CX-5, this is a straightforward job if you keep the caliper supported and torque everything correctly.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work on a flat surface and chock the rear wheels before lifting the vehicle.
• Use jack stands; never rely on a floor jack alone.
• Do not press the brake pedal with the caliper removed.
• Support the caliper with wire or a hanger so the brake hose is not stretched.
• Brake dust can be harmful; avoid blowing it off with compressed air.
• If your CX-5 has a hill-start or stability system warning after service, cycle the ignition and recheck pedal feel.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 19mm socket
• 14mm socket
• Torque wrench
• Breaker bar
• Ratchet
• C-clamp
• Brake caliper compression tool (specialty)
• Flat-blade screwdriver
• Wire hanger
• Wire brush
• Bungee cord
• Gloves
• Safety glasses
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake pad hardware kit - Qty: 1
• Brake caliper grease - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, put the transmission in Park, and set the parking brake.
• Loosen the front wheel lug nuts slightly before lifting.
• If the rotor has a large ridge, inspect it before installing new pads.
• Keep the ignition off while the caliper is off the rotor.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the wheel

• Use a 19mm socket and breaker bar to loosen the lug nuts one turn each.
• Lift the front corner with a floor jack (rated 3-ton minimum) and support it with jack stands (rated 3-ton minimum).
• Remove the lug nuts and wheel with the 19mm socket.
• Keep the lug nuts together in one safe spot.

Step 2: Remove the caliper

• Use a 14mm socket to remove the two caliper slide pin bolts.
• Carefully lift the caliper off the bracket.
• Hang the caliper with a wire hanger or bungee cord so the brake hose is not stretched.
• Torque to 25 Nm (18 ft-lbs) during reassembly.

Step 3: Remove the old pads and hardware

• Slide the old brake pads out of the bracket by hand or with a flat-blade screwdriver.
• Remove the stainless pad clips and inspect the bracket for rust.
• Use a wire brush to clean the pad landing surfaces.
• Spray with brake cleaner and let it dry.

Step 4: Retract the caliper piston

• Use a brake caliper compression tool (specialty) or a C-clamp to slowly push the piston back into the caliper.
• Watch the brake fluid reservoir under the hood so it does not overflow.
• Push the piston in slowly and evenly.

Step 5: Install new hardware and pads

• Install the new pad clips in the bracket.
• Apply a thin layer of brake caliper grease to the contact points where the pads touch the hardware.
• Install the new front brake pads in the bracket.
• Make sure the pad friction material faces the rotor.

Step 6: Reinstall the caliper

• Lower the caliper over the new pads.
• Install the slide pin bolts by hand first, then tighten with a 14mm socket.
• Torque to 25 Nm (18 ft-lbs).

Step 7: Reinstall the wheel

• Put the wheel back on and start all lug nuts by hand.
• Tighten the lug nuts in a crisscross pattern with a 19mm socket.
• Lower the vehicle and finish tightening with a torque wrench.
• Torque to 108 Nm (80 ft-lbs).

Step 8: Seat the brake pads

• Before moving the vehicle, pump the brake pedal several times until it feels firm.
• Check the brake fluid level and top off if needed.
• Test the brakes at low speed in a safe area.

---

✅ After Repair

• Verify the brake pedal is firm before driving.
• Listen for noise on the first stop; a light squeak for a short time can be normal while the pads settle.
• Check both front wheels for leaks, drag, or abnormal heat after a short test drive.
• Bed in the pads gently for the first 200 miles unless the pad maker says otherwise.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $70-$160 (parts only)

You Save: $180-$290 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
