🔧 Escape - Front Brake Pad Replacement

You’ll remove the front calipers, swap the worn pads for new ones, then reassemble and torque everything correctly. Fresh pads restore braking performance and help prevent rotor damage and squealing.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

Assumption: Factory single-piston front calipers; bolt sizes may vary slightly by supplier.

---

⚠️ Safety & Precautions

• ⚠️ Support your Escape with jack stands; never rely on a floor jack.
• ⚠️ Brake dust is unhealthy—wear a dust mask and use brake cleaner, not compressed air.
• ⚠️ Don’t let the caliper hang by the brake hose—support it with a hanger.
• ⚠️ Keep grease off pad friction material and rotor faces.
• ⚠️ Brake fluid may rise when compressing pistons—watch the reservoir to prevent overflow.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Lug nut socket (19mm)
• Ratchet (3/8")
• Breaker bar (1/2")
• Socket set (13mm, 15mm, 18mm)
• Torque wrench (10–200 ft-lbs range)
• C-clamp (6")
• Caliper hanger hook
• Flat trim/pry tool
• Wire brush
• Safety glasses
• Nitrile gloves
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware/clip kit - Qty: 1
• Brake caliper grease (silicone-based) - Qty: 1
• Brake cleaner - Qty: 1
• Brake fluid (DOT 4) - Qty: 1 bottle
• Front brake rotors - Replace in pairs - Qty: 2 (optional if worn/pulsation)

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Loosen the front lug nuts 1/2 turn using a 19mm lug nut socket and breaker bar (do not remove yet).
• Open the hood and locate the brake fluid reservoir. Leave the cap sitting loosely on top (this helps fluid move when compressing the piston).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Lift the front using a floor jack (rated 3-ton minimum) at the proper front jack point.
• Set the Escape onto jack stands (rated 3-ton minimum) and give the vehicle a gentle shake to confirm it’s stable.
• Remove the front wheels using a 19mm lug nut socket and ratchet.

Step 2: Access the caliper

• Turn the steering wheel to give yourself more room (turn left to work on the right side, and vice versa).
• If needed, use a flat trim/pry tool to gently pry the caliper outward a few millimeters to relieve pad tension. Pry on metal only.

Step 3: Remove the caliper slide pin bolts

• Remove the two caliper slide pin bolts using a 13mm socket and ratchet (some setups use a different size; use the socket that fits snugly).
• Lift the caliper off the bracket.
• Hang the caliper from the strut spring using a caliper hanger hook. (A caliper hanger is a hook that supports the caliper so the rubber brake hose isn’t strained.)

Step 4: Remove old pads and hardware

• Pull the old inner and outer pads out of the bracket by hand.
• Remove the stainless hardware clips from the bracket using a flat trim/pry tool.
• Clean the bracket pad lands (where clips sit) using brake cleaner and a wire brush.

Step 5: Compress the caliper piston

• Position an old pad against the piston face, then compress the piston slowly using a C-clamp (6").
• Go slowly and watch the brake fluid reservoir so it doesn’t overflow.
• Slow compression helps prevent seal damage.

Step 6: Service and lubricate the slide pins

• Pull the slide pins out of the bracket by hand (one at a time so parts don’t get mixed).
• Wipe them clean and apply a thin coat of brake caliper grease (silicone-based).
• Reinstall the slide pins and make sure they move smoothly.

Step 7: Install new hardware clips and pads

• Install the new hardware clips onto the bracket by hand (they should snap fully into place).
• Apply a very thin film of brake caliper grease (silicone-based) to the pad ears (the small metal “tabs” that slide in the clips). Do not grease the pad friction surface.
• Install the new inner and outer pads into the bracket.

Step 8: Reinstall the caliper and torque fasteners

• Place the caliper over the new pads.
• Reinstall the caliper slide pin bolts using a 13mm socket and ratchet.
• Tighten with a torque wrench: Torque to 35 Nm (26 ft-lbs) for the front caliper slide pin bolts.

Step 9: Reinstall wheels and torque lug nuts

• Reinstall the wheels and hand-thread the lug nuts.
• Lower the Escape off the jack stands using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern using a torque wrench: Torque to 135 Nm (100 ft-lbs).

Step 10: Restore pedal feel

• With the engine OFF, pump the brake pedal 10–15 times until it feels firm. This seats the pads.
• Check brake fluid level and top off with DOT 4 if needed (do not overfill).

---

✅ After Repair

• Start the engine and confirm the brake pedal remains firm.
• Do a slow test in a safe area: verify the Escape stops straight with no grinding.
• Bed-in the pads: make 6–10 moderate stops from ~30 mph to ~5 mph, allowing 30–60 seconds between stops for cooling. Avoid hard panic stops for the first 200 miles.
• Recheck for fluid leaks and recheck lug nut torque after 25–50 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$150 (parts only)

You Save: $100-$350 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
