🔧 Escape - Front Brake Pad Replacement

Replacing the front brake pads on your Escape means removing the front wheels, opening the front brake calipers, swapping the pads, and reinstalling everything correctly. This restores stopping power and prevents worn pads from damaging the rotors.

Difficulty Level: Beginner | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a flat, solid surface only. Never rely on a jack alone.
• ⚠️ Always support your Escape with jack stands before removing a wheel.
• ⚠️ Brake dust can be harmful. Do not blow it with compressed air; use brake cleaner instead.
• ⚠️ The brake pedal will feel soft after the repair until you pump it several times.
• ⚠️ Do not disconnect the brake hose from the caliper for a pad-only replacement.
• ⚠️ Battery disconnect is not required for this front brake pad job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 19mm lug nut socket
• 13mm socket
• 15mm wrench
• 3/8-inch ratchet
• Torque wrench rated to 150 ft-lbs
• Disc brake caliper piston compressor (specialty)
• Flat-blade screwdriver
• Brake caliper hanger hook
• Floor jack rated 2-ton minimum
• Jack stands rated 2-ton minimum
• Wheel chocks
• Brake cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit - Qty: 1
• Brake lubricant - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• 🅿️ Park your Escape on level ground and shift to Park.
• 🧱 Place wheel chocks behind both rear wheels. Wheel chocks are blocks that stop the vehicle from rolling.
• 🔒 Set the parking brake before lifting the front of the vehicle.
• 🧤 Put on safety glasses and gloves before touching brake parts.
• 📦 Open the new brake pad box and confirm you have inner and outer pads plus hardware clips.
• 🛑 Do one side at a time so the other side can be used as a reference.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the Front Lug Nuts

• Use a 19mm lug nut socket and 3/8-inch ratchet to loosen each front lug nut about 1/2 turn.
• Do this while the tires are still touching the ground so the wheels do not spin.
• Do not remove the lug nuts yet.

Step 2: Lift and Support the Front

• Use a floor jack rated 2-ton minimum at the front jacking point to raise the front of your Escape.
• Place jack stands rated 2-ton minimum under the front side support points.
• Slowly lower the vehicle onto the jack stands.
• Gently shake the vehicle by hand to confirm it is stable before working near the wheels.

Step 3: Remove the Front Wheel

• Use the 19mm lug nut socket to remove the loosened lug nuts.
• Pull the wheel straight off and set it flat under the side of the vehicle as a backup safety cushion.

Step 4: Inspect the Brake Assembly

• Look at the brake caliper, rotor, pads, and rubber brake hose before removing anything.
• The caliper is the clamp-shaped part that squeezes the pads against the rotor.
• Use brake cleaner spray and shop towels to clean loose dust from the caliper area.
• If the rotor is deeply grooved, cracked, or badly rust-scaled, replace or resurface the rotor before installing new pads.

Step 5: Remove the Lower Caliper Slide Pin Bolt

• Use a 15mm wrench to hold the caliper slide pin if it spins.
• Use a 13mm socket and 3/8-inch ratchet to remove the lower caliper slide pin bolt.
• The slide pin lets the caliper move evenly as the pads wear.

Step 6: Swing the Caliper Up

• Use a flat-blade screwdriver gently between the caliper and outer pad to create a little space.
• Pivot the caliper upward away from the brake pads.
• Use a brake caliper hanger hook to support the caliper from the strut spring if needed.
• Do not let the caliper hang by the rubber brake hose.

Step 7: Remove the Old Brake Pads

• Pull the inner and outer brake pads out of the caliper bracket by hand.
• If they are stuck, use a flat-blade screwdriver to gently pry them out.
• Note how the pad wear indicator is positioned before removing the pads.

Step 8: Remove and Replace the Pad Hardware

• Use a flat-blade screwdriver to pop the old stainless pad clips out of the caliper bracket.
• Clean the bracket contact areas with brake cleaner spray and shop towels.
• Install the new clips from the front brake pad hardware kit by pressing them fully into place by hand.
• Clean clips help prevent brake noise.

Step 9: Compress the Caliper Piston

• Check the brake fluid reservoir under the hood. If it is very full, place shop towels around it in case fluid rises.
• Place an old brake pad against the caliper piston.
• Use a disc brake caliper piston compressor to slowly push the piston fully back into the caliper.
• The piston is the round part inside the caliper that pushes the inner pad.
• Compress it slowly to avoid forcing brake fluid backward too quickly.

Step 10: Lubricate the Pad Contact Points

• Apply a thin layer of brake lubricant to the pad ears where they touch the new clips.
• Use only a small amount. Do not get lubricant on the pad friction material or rotor face.
• If lubricant gets on the rotor, clean it with brake cleaner spray and shop towels.

Step 11: Install the New Brake Pads

• Slide the new inner and outer pads into the caliper bracket by hand.
• Make sure the pads sit flat and move slightly in the hardware clips.
• If a pad will not slide in easily, remove it and recheck the clip position.

Step 12: Reinstall the Caliper

• Rotate the caliper back down over the new pads by hand.
• Use the 13mm socket to reinstall the lower caliper slide pin bolt.
• Use the 15mm wrench to hold the slide pin if it turns.
• Use a torque wrench rated to 150 ft-lbs with the 13mm socket and tighten the caliper slide pin bolt to Torque to 35 Nm (26 ft-lbs).

Step 13: Repeat on the Other Front Side

• Use the same tools and steps on the opposite front wheel.
• Replace front brake pads in pairs only. Never replace just one side.

Step 14: Reinstall the Wheels

• Put each wheel back on by hand.
• Thread the lug nuts on by hand first to avoid cross-threading.
• Use the 19mm lug nut socket to snug the lug nuts in a star pattern.

Step 15: Lower the Vehicle and Torque the Lug Nuts

• Use the floor jack rated 2-ton minimum to lift your Escape slightly off the jack stands.
• Remove the jack stands rated 2-ton minimum.
• Lower the vehicle until the tires touch the ground fully.
• Use a torque wrench rated to 150 ft-lbs with the 19mm lug nut socket to tighten the lug nuts in a star pattern to Torque to 135 Nm (100 ft-lbs).

Step 16: Pump the Brake Pedal

• Sit in the driver seat and press the brake pedal slowly 5-10 times.
• The pedal should become firm. This moves the caliper pistons back against the new pads.
• Do not drive until the brake pedal feels firm.

---

✅ After Repair

• ✅ Check the brake fluid level and top off only if needed with the correct brake fluid listed on the reservoir cap.
• ✅ Start your Escape and press the brake pedal again. It should stay firm and not sink to the floor.
• ✅ Test drive slowly in a safe area before normal driving.
• ✅ Bed in the pads with several gentle stops from about 30 mph, allowing time between stops for cooling.
• ✅ Avoid hard braking for the first 150-200 miles unless needed for safety.
• ✅ Recheck lug nut torque after your first short drive: Torque to 135 Nm (100 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $220-$380 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $175-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---
