🔧 Fusion - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake calipers out of the way, swap the old pads for new ones, then reassemble and torque everything correctly. This restores safe stopping power and prevents metal-to-metal rotor damage.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: factory single-piston front calipers (most Fusion setups).

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support your Fusion on jack stands before going under or pulling on parts.
• ⚠️ Do not press the brake pedal while a caliper is off the rotor, or the piston can pop out and leak brake fluid.
• ⚠️ Keep brake fluid off paint; it can damage the finish.
• ⚠️ Hybrid note: you do not need to disable the high-voltage system for front pads, but keep the car OFF and the key/fob away from the cabin so it can’t “wake up.”
• ⚠️ If brake fluid is near the MAX line, retracting pistons can overflow the reservoir; siphon a little out if needed.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (pair, rated 2-ton minimum)
• Wheel chocks
• 19mm lug nut socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20–200 Nm range)
• 13mm socket
• 15mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (5–80 Nm range)
• Flat-blade screwdriver
• C-clamp (6" minimum)
• Bungee cord
• Wire brush
• Small funnel
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Brake caliper grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on a flat surface, shift to Park, and set the parking brake.
• Place wheel chocks behind the rear tires.
• Open the hood and locate the brake fluid reservoir so you can monitor the fluid level during piston push-back.
• Loosen (crack loose) the front lug nuts about 1/2 turn before lifting the car using a 19mm lug nut socket and breaker bar.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front of the car

• Use a floor jack to lift the front of your Fusion at the proper front jacking point.
• Set the car onto jack stands and gently shake the car to confirm it’s stable.

Step 2: Remove the front wheels

• Remove the lug nuts using a 19mm lug nut socket and ratchet, then remove both front wheels.

Step 3: Locate the caliper and remove the slide-pin bolts

• The brake caliper is the clamp that squeezes the pads onto the rotor.
• Turn the steering wheel to give yourself more room (left for right side work, right for left side work).
• Remove the two caliper slide-pin bolts using a 13mm socket and 3/8" drive ratchet.

Step 4: Swing the caliper up and support it

• Use a flat-blade screwdriver to gently pry the caliper away from the pads if it’s tight.
• Lift the caliper off the bracket and hang it from the strut spring using a bungee cord.
• Do not let the caliper hang by the rubber brake hose.

Step 5: Remove the old pads and hardware clips

• Slide the old pads out of the bracket by hand.
• Remove the stainless pad hardware (abutment clips) from the bracket using a flat-blade screwdriver.

Step 6: Clean the bracket pad lands

• Spray the bracket where the clips sit with brake cleaner (use safety glasses).
• Lightly scrub rust off the pad contact areas using a wire brush.
• Clean metal helps pads slide smoothly.

Step 7: Install new hardware clips and grease contact points

• Snap the new abutment clips into the bracket by hand.
• Apply a very thin film of brake caliper grease where the pad ears touch the clips (do not get grease on pad friction material).

Step 8: Retract the caliper piston

• A C-clamp is a screw clamp that presses parts together.
• Place one old pad against the piston face, then use a C-clamp to slowly press the piston fully back into the caliper.
• Check the brake fluid reservoir while compressing; if it rises near the top, remove a little using a small funnel and a clean method you prefer.

Step 9: Install the new pads

• Install the new inner and outer pads into the bracket by hand.
• If one pad has a wear indicator, install it in the same position as the old set (commonly the inner pad).

Step 10: Reinstall the caliper over the new pads

• Lower the supported caliper back over the pads and align it with the slide-pin holes.
• Install the caliper slide-pin bolts using a 13mm socket and ratchet.
• Torque to 35 Nm (26 ft-lbs).

Step 11: Reinstall the wheels and torque lug nuts

• Reinstall both wheels and snug the lug nuts using a 19mm lug nut socket and ratchet.
• Lower the car using the floor jack, then final-torque the lug nuts in a star pattern with a 1/2" drive torque wrench.
• Torque to 135 Nm (100 ft-lbs).

Step 12: Restore pedal feel before moving the car

• With the car still in Park, press the brake pedal slowly 8–12 times until it feels firm.
• This seats the pads against the rotors after piston compression.

---

✅ After Repair

• Check brake fluid level and top off only if needed (use the correct DOT brake fluid listed on the reservoir cap).
• Road test at low speed first and confirm normal braking with no pulling, grinding, or warning lights.
• Pad bed-in (break-in): make 6–10 moderate stops from ~30 mph to ~5 mph, allowing 30–60 seconds between stops; avoid hard stops for the first 150–200 miles.
• Re-check lug nut torque after 25–50 miles using a 1/2" drive torque wrench.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$140 (parts only)

You Save: $190-$310 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
