🔧 Focus - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake caliper off the rotor, swap the old pads for new ones, then reassemble and torque everything correctly. This restores braking performance and prevents metal-to-metal damage if the pads are worn thin.

Difficulty Level: Intermediate | Estimated Time: 1-2 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support your Focus with jack stands, not just a jack.
• ⚠️ Brake dust is harmful; use brake cleaner, not compressed air.
• ⚠️ Brakes can be hot; let them cool before you start.
• ⚠️ Watch the brake fluid level while compressing the piston; it can overflow.
• ⚠️ Do one side at a time so you can use the other side as a reference.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 19mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-200 ft-lbs range)
• 3/8" drive ratchet
• 7mm hex bit socket
• 18mm socket
• C-clamp brake piston compressor
• Bungee cord
• Flathead screwdriver
• Wire brush
• Brake cleaner spray
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Disc brake hardware kit (clips/shims) - Qty: 1
• Brake caliper grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1
• Brake fluid (DOT 4) - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift into Park (or in gear if manual), and set the parking brake.
• Chock the rear wheels using wheel chocks.
• Loosen the front lug nuts slightly using a 19mm socket and breaker bar before lifting.
• Open the hood and check the brake fluid reservoir level; if it’s near “MAX,” be ready to remove a little fluid if it rises. Use a clean syringe or turkey baster.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front of your Focus

• Lift the front using a floor jack (rated 3-ton minimum) at the proper front jacking point.
• Set the car onto jack stands (rated 3-ton minimum) and gently shake the car to confirm it’s stable.

Step 2: Remove the front wheels

• Remove the lug nuts using a 19mm socket and take off the wheel.
• Set the wheel under the rocker panel area as an extra safety backup.

Step 3: Remove the brake caliper (slide pin bolts)

• Turn the steering wheel to give yourself space at the caliper you’re working on.
• Locate the two caliper slide pin bolts on the back of the caliper.
• Remove both bolts using a 7mm hex bit socket and 3/8" drive ratchet.
• Carefully lift the caliper off the bracket.
• Hang the caliper from the strut spring using a bungee cord so the brake hose isn’t stretched. Never let the caliper dangle.

Step 4: Remove the old pads and hardware

• Pull the inner and outer pads out of the bracket by hand. If stuck, gently pry with a flathead screwdriver.
• Remove the old pad clips (hardware) from the bracket.
• Clean the pad “rails” (where the pad ears slide) using brake cleaner spray and a wire brush.

Step 5: Compress the caliper piston

• Place an old pad against the piston face to spread the force evenly.
• Slowly compress the piston using a C-clamp brake piston compressor until it bottoms out.
• Keep an eye on the brake fluid reservoir while compressing; stop if it looks like it may overflow.
• Slow pressure helps prevent seal damage.

Step 6: Install new hardware and new pads

• Install the new pad clips from the disc brake hardware kit onto the bracket by hand.
• Apply a thin film of brake caliper grease (silicone) to the pad ears where they contact the clips. Keep grease off pad friction material.
• Install the new inner and outer pads into the bracket.

Step 7: Reinstall the caliper and torque fasteners

• Lower the caliper over the new pads by hand.
• Install the caliper slide pin bolts using a 7mm hex bit socket and 3/8" drive ratchet.
• Tighten using a torque wrench: Torque to 35 Nm (26 ft-lbs).

Step 8: Reinstall wheels and torque lug nuts

• Put the wheel back on and hand-thread the lug nuts.
• Lower the car off the stands using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench: Torque to 135 Nm (100 ft-lbs).

---

✅ After Repair

• Before driving, pump the brake pedal 10-15 times until it feels firm. This seats the pads to the rotor.
• Check the brake fluid level and top off with DOT 4 if needed.
• With the engine running, hold the brake pedal firmly for 15 seconds to confirm it doesn’t slowly sink.
• Do a cautious test drive and verify no pulling, grinding, or warning lights.
• Pad break-in: make 8-10 smooth stops from 30–40 mph to 5 mph, allowing brief cool-down between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$150 (parts only)

You Save: $190-$300 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1-1.5 hours.

---
