🔧 Explorer - Front Brake Pad Replacement

You’ll be removing the front wheels, taking the brake caliper off, swapping the old pads for new ones, then reinstalling everything with the correct torque. New pads restore stopping power and prevent metal-to-metal grinding that can ruin the rotors.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: Factory front single-piston calipers (most Limited trims).

---

⚠️ Safety & Precautions

• ⚠️ Work on flat, solid ground; use jack stands, not just a jack.
• ⚠️ Do not press the brake pedal while the caliper is off the rotor.
• ⚠️ Brake dust is unhealthy; use brake cleaner, not compressed air.
• ⚠️ Keep grease off pad friction material and rotor surfaces.
• ✅ Battery disconnect is not required for front pad replacement.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (30-250 ft-lbs range)
• 13mm socket
• 18mm socket
• Ratchet (3/8" drive)
• Torque wrench (10-80 ft-lbs range)
• Large C-clamp (6" minimum)
• Flathead screwdriver
• Small wire brush
• Bungee cord
• Brake cleaner spray
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Silicone brake lubricant - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to P, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Pop the hood and check the brake fluid reservoir level. If it’s near “MAX,” remove a small amount (pads going in will push fluid back up).
• Crack the front lug nuts loose while the tires are still on the ground.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Use a 21mm socket and breaker bar to loosen (do not remove) the front lug nuts.
• Lift the front with a floor jack at a proper front jacking point, then support with jack stands.
• Remove the lug nuts with a 21mm socket and take the wheel off.

Step 2: Remove the brake caliper

• Turn the steering wheel to give yourself room (left for right side, right for left side).
• Use a 13mm socket and ratchet to remove the two caliper slide pin bolts.
• Lift the caliper off the rotor and hang it from the suspension spring using a bungee cord.
• Tip: Never let the caliper hang by the hose.

Step 3: Remove old pads and hardware

• Pull the old pads out by hand. Use a flathead screwdriver gently if they’re stuck.
• Remove the old stainless pad clips (abutment clips) from the caliper bracket.
• Spray the bracket pad “tracks” with brake cleaner spray.
• Use a small wire brush to clean rust where the clips sit so the new pads can slide freely.

Step 4: Compress the caliper piston

• Place one old pad against the piston face, then use a large C-clamp to slowly push the piston back into the caliper.
• Watch the brake fluid reservoir while compressing. Stop if it looks like it may overflow.
• Tip: Go slow to avoid damaging seals.
• Definition: A caliper piston is the round part that pushes the pad into the rotor when you press the brake pedal.

Step 5: Install new hardware and pads

• Install the new abutment clips onto the bracket by hand.
• Apply a thin film of silicone brake lubricant where the pad “ears” touch the clips (metal-to-metal contact points only).
• Slide the new pads into place. Make sure they move smoothly in the clips.
• Tip: If pads don’t slide easily, re-clean the clip seats.

Step 6: Reinstall the caliper and torque fasteners

• Set the caliper back over the new pads.
• Install the slide pin bolts using a 13mm socket and ratchet.
• Tighten slide pin bolts with a torque wrench: Torque to 34 Nm (25 ft-lbs).
• If you removed the caliper bracket (not always required for pads): reinstall bracket bolts using an 18mm socket and torque wrench: Torque to 200 Nm (148 ft-lbs).

Step 7: Reinstall wheels and torque lug nuts

• Reinstall the wheel and hand-thread the lug nuts.
• Lower the vehicle off the jack stands using the floor jack.
• Torque the lug nuts in a star pattern using a 21mm socket and torque wrench: Torque to 203 Nm (150 ft-lbs).

Step 8: Repeat on the other front wheel

• Do the exact same steps on the other side.
• Tip: Always replace front pads as a pair.

---

✅ After Repair

• With the engine off, pump the brake pedal slowly 8–15 times until it feels firm.
• Check brake fluid level and top off only if needed (use the correct DOT brake fluid listed on the reservoir cap).
• Start the engine and confirm the pedal feels normal (it may drop slightly with power assist).
• Do a cautious test drive and verify no pulling, grinding, or warning lights.
• Bed-in (break-in) the pads: make 8–10 medium stops from ~40 mph to ~10 mph, allowing a little cooling time between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $300-$550 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $120-$490 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
