🔧 Encore - Front Brake Pad Replacement

Replacing the front brake pads restores safe stopping power and prevents damage to your rotors (the round metal discs). You’ll remove the caliper (the clamp that squeezes the pads), swap the pads, compress the piston, and reassemble with correct torque.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

Assumption: Stock front brakes with standard single-piston calipers.

---

⚠️ Safety & Precautions

• 🛑 Support your Encore with jack stands on solid, level ground; never rely on a jack alone.
• 🧤 Wear safety glasses and mechanic gloves; brake dust and cleaner are irritating.
• 🔥 Brakes can be very hot; let the front brakes cool before starting.
• 🧪 Brake fluid can overflow when you compress the piston; keep the reservoir level in check and wipe spills immediately (it can damage paint).
• 🪝 Do not let the caliper hang by the brake hose; support it with a hook/strap.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Breaker bar 1/2"
• Torque wrench 1/2" (20-200 Nm range)
• 19mm socket
• 14mm socket
• 18mm socket
• Ratchet 3/8"
• C-clamp 6"
• Flat-blade screwdriver
• Wire hook or bungee strap
• Brake parts cleaning brush
• Brake cleaner spray
• Shop rags
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Brake lubricant (silicone or synthetic brake grease) - Qty: 1
• Brake cleaner - Qty: 1
• Front brake rotors - Qty: 2 (optional if worn/pulsation)

---

📋 Before You Begin

• Park on level ground, shift to P, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Open the hood and locate the brake fluid reservoir; loosen the cap (do not remove completely) so fluid can move back when you compress the piston.
• Check brake fluid level now; if it’s near MAX, be ready to absorb a small overflow with shop rags.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen lug nuts and raise the front

• Use a 19mm socket and breaker bar to loosen the front wheel lug nuts about 1/2 turn while the tire is still on the ground.
• Lift the front with a floor jack at the proper jacking point and set the vehicle onto jack stands.

Step 2: Remove the wheel

• Remove the lug nuts using a 19mm socket and take the wheel off.
• Set the wheel under the rocker area as an extra safety backup.

Step 3: Remove the brake caliper (not the bracket yet)

• Turn the steering wheel to give yourself more room to work.
• Use a 14mm socket and ratchet to remove the two caliper slide pin bolts (these are the smaller bolts on the back of the caliper).
• Carefully lift the caliper off the pads/rotor. If it’s tight, gently pry with a flat-blade screwdriver.
• Support the caliper with a wire hook or bungee strap. (This prevents damage to the brake hose.)

Step 4: Remove the old pads and hardware clips

• Slide the old inner and outer pads out by hand.
• Remove the stainless hardware/abutment clips from the caliper bracket by hand or with a flat-blade screwdriver.
• Clean the bracket pad “tracks” with brake cleaner spray, a brake parts cleaning brush, and shop rags.

Step 5: Compress the caliper piston

• Place one old brake pad against the piston face.
• Use a C-clamp 6" to slowly compress the piston fully back into the caliper bore.
• Watch the brake fluid reservoir while compressing; stop if it looks like it may overflow and absorb fluid with shop rags.
• Compress slowly to avoid seal damage.

Step 6: Install new hardware clips and lubricate contact points

• Install the new abutment clips onto the bracket (they snap into place by hand).
• Apply a thin film of brake lubricant where the pad “ears” slide on the clips.
• Do not get grease on the pad friction material or rotor surface; if you do, clean with brake cleaner spray.

Step 7: Install the new brake pads

• Install the new inner and outer pads into the bracket by hand.
• Make sure the pads slide freely; if they bind, re-clean the bracket tracks and confirm the clips are seated correctly.

Step 8: Reinstall the caliper and torque bolts

• Lower the caliper back over the new pads.
• Install the caliper slide pin bolts by hand first to avoid cross-threading, then tighten with a 14mm socket and ratchet.
• Tighten with a torque wrench: Torque to 30 Nm (22 ft-lbs).

Step 9: Repeat on the other front wheel

• Repeat Steps 2 through 8 on the other front side. Replace pads on both sides as a pair.

Step 10: Reinstall wheels and torque lug nuts

• Reinstall each wheel and hand-thread the lug nuts.
• Lower the vehicle off the jack stands using the floor jack.
• Use a torque wrench with a 19mm socket to tighten lug nuts in a star pattern: Torque to 140 Nm (103 ft-lbs).

---

✅ After Repair

• With the engine off, pump the brake pedal 10-15 times until it feels firm. This seats the pads against the rotor.
• Check the brake fluid reservoir level and install the cap snugly; top off only if needed with the correct DOT-rated fluid listed on the reservoir cap.
• Start the engine and confirm the pedal feels normal; do a slow test stop in a safe area.
• Pad bedding (recommended): make 6-10 moderate stops from ~50 km/h to ~10 km/h, driving a minute between stops to cool slightly. Avoid hard stops for the first 200 km.
• Listen for grinding/squealing and check for any fluid leaks or pulling while braking.

---

💰 DIY vs Shop Cost

Shop Cost: ₹6,000-₹15,000 (parts + labor)

DIY Cost: ₹2,500-₹8,000 (parts only)

You Save: ₹3,500-₹7,000 by doing it yourself!

Shop labor rates vary in Panipat but often run ₹800-₹2,000/hour. This repair takes a shop approximately 1-2 hours.

---
