🔧 Sportage - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake calipers off the rotors, swap in new pads (and hardware if included), then reassemble and pump the brake pedal to restore a firm pedal. This restores braking power and prevents pad-to-rotor damage when pads get thin.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

Assumption: Factory front brakes/rotors; torque values listed are best-effort—verify for your exact brake package.

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the SUV on jack stands—never rely on a jack alone.
• ⚠️ Brake dust is harmful—avoid blowing it with compressed air; use brake cleaner instead.
• ⚠️ Brake fluid can damage paint—wipe spills immediately.
• ⚠️ Do not press the brake pedal while a caliper is off the rotor.
• ⚠️ Keep grease off pad friction material and rotor faces.
• 🔋 Battery disconnect is not required for front pads.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-200 Nm range)
• 3/8" drive ratchet
• 3/8" drive torque wrench (5-60 Nm range)
• 14mm socket
• 17mm socket
• Flathead screwdriver
• C-clamp (6-inch) or disc brake piston compressor (specialty)
• Bungee cord or mechanics wire
• Brake cleaner spray
• Small wire brush
• Turkey baster or fluid siphon
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake parts cleaner - Qty: 1
• Brake fluid (DOT 3 or DOT 4) - Qty: 1 quart

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Chock the rear wheels with wheel chocks.
• Pop the hood and locate the brake fluid reservoir; if it’s near “MAX,” remove a little fluid using a turkey baster or fluid siphon (this helps prevent overflow when you compress the pistons).
• Loosen the front lug nuts slightly before lifting the SUV.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift the front and remove the wheels

• Use wheel chocks to secure the rear wheels.
• Use a 21mm socket and breaker bar to loosen the front lug nuts 1/2 turn.
• Use a floor jack (rated 3-ton minimum) to lift the front of the SUV and place it on jack stands (rated 3-ton minimum).
• Remove the lug nuts with a 21mm socket and take off both front wheels.

Step 2: Access the front caliper and inspect

• Turn the steering wheel to give yourself more space at the caliper (left turn to work right side, right turn to work left side).
• Look at the rotor surface and pad thickness. Deep grooves mean consider rotors.

Step 3: Remove the caliper slide (guide) bolts

• Locate the two caliper slide/guide bolts on the back of the caliper.
• Use a 14mm socket and 3/8" drive ratchet to remove the upper and lower slide bolts.
• If the slide pin spins, hold it with a 17mm socket while turning the bolt (some setups require this).

Step 4: Support the caliper (do not let it hang)

• Lift the caliper off the rotor.
• Hang the caliper from the strut spring using a bungee cord or mechanics wire.
• Never hang by the brake hose.

Step 5: Remove old pads and hardware clips

• Pull the inner and outer brake pads out of the caliper bracket by hand.
• Remove the stainless pad hardware/abutment clips from the caliper bracket using a flathead screwdriver.
• Clean the bracket pad lands (where clips sit) with a wire brush and brake cleaner spray.

Step 6: Check and service the slide pins

• Pull the caliper slide pins out of the bracket by hand.
• Wipe old grease off and inspect the rubber boots for tears.
• Apply a thin, even coat of brake caliper slide pin grease (silicone) and reinstall the pins so they move smoothly.
• Slide pins must move freely.

Step 7: Compress the caliper piston

• Place an old brake pad against the piston face to spread the force.
• Use a C-clamp (6-inch) or disc brake piston compressor (specialty) to slowly press the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing; remove fluid with a turkey baster or fluid siphon if it approaches overflow.
• Go slow to protect seals.

Step 8: Install new hardware and new pads

• Install new abutment clips from the hardware kit into the bracket.
• Apply a very light film of brake caliper slide pin grease (silicone) to the abutment clip “rails” (metal-to-metal contact only).
• Install the new pads into the bracket in the same positions as removed (some pads are inner/outer specific).
• Keep grease off pad faces.

Step 9: Reinstall the caliper and torque the slide bolts

• Lower the caliper over the new pads.
• Start the slide bolts by hand to avoid cross-threading.
• Use a 14mm socket and 3/8" drive torque wrench (5-60 Nm range) to tighten the caliper slide bolts: Torque to 25-35 Nm (18-26 ft-lbs).

Step 10: Reinstall wheels and torque lug nuts

• Reinstall both front wheels and hand-thread all lug nuts.
• Lower the SUV off the jack stands using the floor jack (rated 3-ton minimum).
• Use a 21mm socket and 1/2" drive torque wrench (20-200 Nm range) to tighten lug nuts in a star pattern: Torque to 90-110 Nm (66-81 ft-lbs).

Step 11: Restore pedal feel and set fluid level

• With the engine OFF, press the brake pedal slowly 10–15 times until it feels firm.
• Check the brake fluid reservoir level and top off with brake fluid (DOT 3 or DOT 4) as needed (do not overfill).
• Spray any greasy fingerprints off rotors with brake cleaner spray.

---

✅ After Repair

• Start the engine and confirm the brake pedal stays firm (it will drop slightly with vacuum assist).
• Do a slow test roll in a safe area and confirm the SUV stops straight with no pulling.
• Perform pad bedding (break-in): 6–10 moderate stops from 30–40 mph with cool-down driving between stops; avoid hard panic stops for the first 150–200 miles.
• Recheck for leaks around the calipers and recheck lug nut torque after 50–100 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$180 (parts only)

You Save: $170-$320 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
