🔧 SRX - Front Brake Pad Replacement

You’ll be removing the front caliper, swapping the old pads for new ones, then reassembling everything with the correct torque. New pads restore stopping power and prevent rotor damage when pads get thin.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the SRX with jack stands (never rely on a floor jack alone).
• ⚠️ Brake dust is unhealthy—wear a dust mask and use brake cleaner (do not blow with compressed air).
• ⚠️ Do not let the brake caliper hang by the brake hose—support it with a bungee cord.
• ⚠️ Watch brake fluid level while compressing the piston; it can overflow the reservoir.
• ⚠️ If you feel unsure at any step, stop—brakes are safety-critical.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 22mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (30-200 ft-lb range)
• 13mm socket
• 18mm socket
• Ratchet (3/8" drive)
• Socket extension (3" and 6")
• Flat-blade screwdriver
• Brake caliper piston compressor tool (specialty)
• Bungee cord
• Wire brush
• Shop rags
• Nitrile gloves
• Safety glasses
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (clips/shims) - Qty: 1
• Brake parts cleaner - Qty: 1
• High-temperature silicone brake lubricant - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to P, and set the parking brake.
• Chock the rear wheels using wheel chocks.
• Turn the steering wheel to give you more room at the caliper (turn left to work on the right side, and vice versa).
• Open the hood and locate the brake fluid reservoir. Do not remove fluid yet—just be ready to catch overflow with shop rags.
• A piston compressor pushes the piston back evenly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the front wheel lug nuts

• Use a 22mm socket with a 1/2" drive breaker bar to loosen each lug nut about 1/2 turn (do not remove yet).

Step 2: Lift and support the SRX

• Lift the front using the floor jack (rated 3-ton minimum) at the proper front jacking point.
• Set the SRX onto jack stands (rated 3-ton minimum).
• Give the vehicle a gentle push to confirm it’s stable before working.

Step 3: Remove the front wheel

• Remove the lug nuts using the 22mm socket and take the wheel off.

Step 4: Locate the caliper and caliper bracket

• The caliper is the part that squeezes the rotor; the bracket is the larger mount behind it.
• Turn the steering for better access if needed.

Step 5: Remove the caliper guide pin bolts

• Use a 13mm socket with a ratchet (3/8" drive) and socket extension to remove the caliper guide pin bolts.
• Carefully lift the caliper off the bracket.
• Support the caliper with a bungee cord so the brake hose is not stretched.
• If it’s tight, wiggle—don’t pry the hose.

Step 6: Remove the old brake pads and hardware

• Slide the old pads out by hand. Use a flat-blade screwdriver gently if they’re stuck.
• Remove the pad clips (hardware) from the bracket. Use the flat-blade screwdriver carefully.

Step 7: Compress the caliper piston

• Place an old pad against the piston face, then use the brake caliper piston compressor tool (specialty) to slowly push the piston back into the caliper.
• Check the brake fluid reservoir as you compress. If it starts to rise toward the top, soak some up with shop rags (avoid spilling on paint).
• Go slow—fast compression can overflow fluid.

Step 8: Clean and prep the bracket contact points

• Spray the bracket and rotor area with brake parts cleaner and wipe with shop rags.
• Use a wire brush to clean the pad “rails” where the clips sit (rust here causes sticking).

Step 9: Install new pad hardware and lubricate correctly

• Install the new clips from the front brake pad hardware kit into the bracket by hand.
• Apply a thin layer of high-temperature silicone brake lubricant to:
  • The pad ears where they slide on the clips
  • The caliper slide pin contact areas (metal-to-metal only)
• Do not get lubricant on the pad friction material or rotor.

Step 10: Install the new pads

• Slide the new pads into the bracket until they seat fully.

Step 11: Reinstall the caliper

• Set the caliper back over the new pads.
• Install the guide pin bolts by hand first (to avoid cross-threading).
• Tighten using the 13mm socket and ratchet (3/8" drive).
• Torque to 38 Nm (28 ft-lb) using the 1/2" drive torque wrench (with the appropriate socket/adapter setup).

Step 12: Reinstall the wheel

• Put the wheel back on and thread lug nuts by hand.
• Snug the lug nuts in a star pattern using the 22mm socket.

Step 13: Lower the SRX and torque the lug nuts

• Raise slightly with the floor jack (rated 3-ton minimum), remove the jack stands, then lower to the ground.
• Torque lug nuts in a star pattern using the 22mm socket and 1/2" drive torque wrench.
• Torque to 190 Nm (140 ft-lb).

Step 14: Repeat on the other front wheel

• Repeat Steps 1–13 on the other side. Replace pads as a pair (left and right).

---

✅ After Repair

• Before starting the engine, pump the brake pedal slowly 8–12 times until it feels firm (this seats the pads against the rotor).
• Check brake fluid level in the reservoir and top off only if needed with the correct DOT fluid listed on the cap.
• With the engine running, confirm the pedal stays firm and the vehicle stops normally at low speed in a safe area.
• Brake pad break-in: make 8–10 moderate stops from ~30 mph down to ~5 mph, allowing short cool-down between stops (avoid hard panic stops for the first ~200 miles).
• If you hear grinding, have a soft pedal, or the car pulls hard to one side, stop driving and recheck your work.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$160 (parts only)

You Save: $190-$290 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
