🔧 Escape - Front Brake Pad Replacement

Replacing the front brake pads restores safe stopping and prevents grinding damage to the rotors. On your Escape, the front brakes use a floating caliper, so you’ll remove the caliper, swap pads (and hardware), then compress the piston to fit the new thicker pads.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• 🛑 Support the Escape on jack stands before working under/near the wheel.
• 🛑 Do not press the brake pedal while the caliper is off the rotor.
• 🛑 Brake dust is harmful—use brake cleaner, not compressed air.
• 🛑 Brake fluid can overflow when compressing the piston—check the reservoir level first.
• 🛑 If your Escape has ABS, avoid letting the caliper hang by the hose.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Lug wrench
• Torque wrench (20-200 ft-lbs range)
• Socket set (metric)
• 7mm hex key socket
• 15mm socket
• Breaker bar
• Flat-blade screwdriver
• C-clamp (6-inch minimum)
• Wire hook or bungee cord
• Wire brush
• Turkey baster

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake hardware kit (abutment clips) - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• 🧱 Park on level ground, put the transmission in 1st gear, and set the parking brake.
• 🧱 Chock the rear wheels with wheel chocks.
• 🧱 Open the hood and locate the brake fluid reservoir; if it’s near “MAX,” remove a little fluid using a turkey baster (a suction bulb used to draw out fluid).
• 🧱 Loosen the front wheel lug nuts slightly using a lug wrench before lifting.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Use a floor jack to lift one front corner at a time (or the front subframe lift point if you prefer).
• Place jack stands under solid frame/support points and lower the Escape onto them.
• Remove the wheel using a lug wrench.

Step 2: Locate the caliper and slide pin bolts

• Turn the steering wheel to give yourself working room.
• Find the two caliper slide pin bolts on the back of the caliper.
• Use a 7mm hex key socket with a ratchet to remove the slide pin bolts.

Step 3: Remove and support the caliper

• Carefully lift the caliper off the rotor.
• Hang the caliper from the strut spring using a wire hook or bungee cord.
• Never let it hang by the brake hose.

Step 4: Remove the old pads and hardware

• Pull the inner and outer brake pads out by hand.
• Remove the old abutment clips (pad “rails”) from the caliper bracket using a flat-blade screwdriver.
• Spray the bracket pad lands with brake cleaner and scrub with a wire brush until smooth.

Step 5: Remove the caliper bracket (if needed for cleaning or rotor replacement)

• If you need more access, remove the bracket bolts using a 15mm socket and breaker bar.
• Reinstall the bracket and Torque to 136 Nm (100 ft-lbs).

Step 6: Service the slide pins

• Pull the slide pins out of the bracket by hand.
• Wipe old grease off and inspect the rubber boots for tears.
• Apply a thin coat of brake caliper slide pin grease (silicone) and reinstall the pins so they move freely.

Step 7: Install new hardware and pads

• Install the new abutment clips from the front brake hardware kit into the bracket by hand.
• Install the new pads in the same positions as the old ones (inner pad goes on the piston side).

Step 8: Compress the caliper piston

• Place one of the old brake pads against the caliper piston face.
• Use a C-clamp to slowly press the piston fully back into the caliper.
• Check the brake fluid reservoir level while compressing; remove extra fluid with a turkey baster if needed.
• Go slowly to avoid damaging seals.

Step 9: Reinstall the caliper

• Set the caliper back over the new pads.
• Install the slide pin bolts using a 7mm hex key socket and ratchet.
• Torque to 25 Nm (18 ft-lbs).

Step 10: Reinstall the wheel

• Install the wheel and hand-thread lug nuts.
• Lower the Escape off the jack stands using the floor jack.
• Tighten lug nuts in a star pattern using a torque wrench: Torque to 135 Nm (100 ft-lbs).

Step 11: Repeat on the other front wheel

• Repeat Steps 1–10 on the opposite front side.

---

✅ After Repair

• 🧪 Pump the brake pedal 10–15 times until it feels firm (this seats the pistons against the new pads).
• 🧪 Top off brake fluid to the correct level (do not overfill).
• 🧪 Start the engine and confirm the pedal stays firm.
• 🧪 Test drive at low speed first; confirm no pulling, grinding, or warning lights.
• 🧪 Pad break-in: do 6–10 gentle stops from ~30 mph with cool-down time between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$160 (parts only)

You Save: $190-$290 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
