🔧 CR-V - Front Brake Pad Replacement

You’ll remove the front calipers, swap the old pads for new ones, and compress the caliper pistons so everything fits back together. Worn pads reduce stopping power and can damage the rotors if you let them go too long.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• 🛑 Support the CR-V on jack stands before working under/around the wheel well.
• 🛑 Do not press the brake pedal while a caliper is off the rotor.
• 🛑 Brake dust is harmful—wear a dust mask and avoid blowing dust with compressed air.
• 🛑 Brake components can be hot; let them cool before touching.
• 🛑 Watch the brake fluid level when compressing the piston; it can overflow.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum) x2
• Wheel chocks
• 19mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-150 ft-lbs range)
• 12mm socket
• 17mm socket
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-60 ft-lbs range)
• C-clamp (6")
• Flat-blade screwdriver
• Needle-nose pliers
• Wire brush
• Bungee cord
• Brake cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Brake caliper grease (silicone-based) - Qty: 1
• Brake hardware kit (clips/shims) - Qty: 1
• Brake fluid (DOT 3) - Qty: 1 bottle

---

📋 Before You Begin

• Park on level ground, shift to P, and set the parking brake.
• Place wheel chocks behind both rear wheels.
• Pop the hood and locate the brake fluid reservoir; do not remove it yet, just know where it is.
• Tip: Take a quick photo of each side before disassembly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen lug nuts

• Use a 19mm socket with a breaker bar to loosen (not remove) the front wheel lug nuts about 1/2 turn.

Step 2: Raise and support the front end

• Use a floor jack to lift the front of the CR-V at the proper jacking point.
• Set the vehicle onto jack stands (rated 3-ton minimum) and lightly shake the vehicle to confirm it’s stable.

Step 3: Remove the front wheels

• Use a 19mm socket to remove the lug nuts, then remove both front wheels.

Step 4: Access the caliper and pads

• Turn the steering wheel to give yourself space (turn left to work on the right side, and vice-versa).
• Use safety glasses and spray the caliper/pad area with brake cleaner spray.

Step 5: Remove the caliper (leave the bracket on)

• Locate the two caliper slide pin bolts on the back of the caliper.
• Use a 12mm socket and 3/8" drive ratchet to remove the two caliper bolts.
• Lift the caliper off the rotor.
• Hang the caliper from the suspension spring using a bungee cord (never let it hang by the brake hose).
• C-clamp: a screw tool that pushes the piston back.

Step 6: Remove old pads and hardware

• Pull the old pads out by hand. If they’re stuck, use a flat-blade screwdriver gently.
• Remove the pad clips/hardware from the bracket (use needle-nose pliers if needed).

Step 7: Clean the bracket contact points

• Use a wire brush to clean rust/scale where the pad clips sit.
• Spray again with brake cleaner spray and wipe with shop towels.

Step 8: Install new hardware and lightly grease contact points

• Install the new clips from the brake hardware kit onto the bracket by hand.
• Apply a very thin film of brake caliper grease where the pads slide on the clips.
• Keep grease off pad friction material and rotor.

Step 9: Compress the caliper piston

• Open the hood and check the brake fluid reservoir level (do not overfill later).
• Place one old pad against the caliper piston face.
• Use a C-clamp (6") to slowly press the piston fully back into the caliper.
• If the reservoir starts to overflow, remove a little fluid using shop towels (do not spill on paint).

Step 10: Install the new pads

• Install the new inner and outer pads into the bracket by hand.
• Make sure the pads slide freely on the new clips (no binding).

Step 11: Reinstall the caliper and torque bolts

• Lower the caliper back over the new pads.
• Thread the caliper slide pin bolts in by hand first (prevents cross-threading).
• Use a 12mm socket and 3/8" drive torque wrench to tighten the slide pin bolts: Torque to 34 N·m (25 ft-lbs).

Step 12: Repeat on the other front wheel

• Repeat Steps 4–11 on the other front brake.

Step 13: Reinstall wheels and torque lug nuts

• Put the wheels back on and hand-thread the lug nuts.
• Lower the CR-V off the jack stands using the floor jack.
• Use a 19mm socket and 1/2" drive torque wrench to tighten lug nuts in a star pattern: Torque to 108 N·m (80 ft-lbs).

---

✅ After Repair

• With the engine OFF, press the brake pedal slowly 10–15 times until it feels firm (this seats the pads against the rotors).
• Check the brake fluid reservoir and top off with DOT 3 only if needed (do not overfill).
• Start the engine and do a low-speed test in a safe area. Confirm normal braking and no pulling or grinding.
• Pad break-in: make 8–10 moderate stops from 30–35 mph, allowing short cool-down between stops.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $40-$120 (parts only)

You Save: $130-$410 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
