🔧 Savana - Front Brake Pad Replacement

You’ll remove the front wheels, swing the front brake caliper out of the way, replace the pads (and hardware), then compress the caliper piston so everything fits back together. New pads restore safe stopping and prevent rotor damage when pads get thin.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• 🛑 Support the van with jack stands before working under it.
• 🛑 Do one side at a time so you can use the other side as a reference.
• 🛑 Brake dust is irritating—wear eye protection and avoid blowing dust with compressed air.
• 🛑 Keep brake fluid off paint; it can damage finishes.
• 🛑 Do not press the brake pedal while the caliper is off the rotor.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (30-250 ft-lbs range)
• Socket set (metric)
• Flat-blade screwdriver
• C-clamp (6" minimum)
• Bungee cord
• Brake parts cleaner
• Wire brush
• Catch pan
• Nitrile gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake pad hardware kit (abutment clips) - Qty: 1
• Brake caliper slide pin grease (silicone brake lube) - Qty: 1
• Brake fluid (DOT 3) - Qty: 1 quart

---

📋 Before You Begin

• Park on level ground, shift to P, and chock the rear wheels using wheel chocks.
• Pop the hood and locate the brake fluid reservoir. Leave the cap on, but be ready for the level to rise when you compress the pistons.
• Set your tools out and plan to do one front corner at a time.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen the front wheel lug nuts

• Use a 21mm socket with a 1/2" drive breaker bar to loosen the lug nuts about 1/2 turn while the tire is still on the ground.

Step 2: Lift and support the front of the van

• Lift the front using a floor jack (rated 3-ton minimum) at a solid front lifting point.
• Set the van onto jack stands (rated 3-ton minimum).
• Give the van a gentle push to confirm it’s stable before you crawl closer. Stability first, speed second.

Step 3: Remove the wheel

• Remove the lug nuts with a 21mm socket and 1/2" drive ratchet.
• Remove the wheel and slide it under the van as an extra safety backup.

Step 4: Locate the caliper and identify the key parts

• The caliper is the clamp that squeezes the rotor.
• The slide pins (guide pins) are bolts that let the caliper move side-to-side smoothly.
• The caliper bracket is the heavy mount that the pads sit in.

Step 5: Remove the caliper slide pin bolts

• Use the correct-size socket (metric) and a ratchet to remove the two caliper slide pin bolts on the back of the caliper.
• If the caliper wants to spin, use a socket set (metric) to counter-hold as needed.

Step 6: Lift the caliper off and support it

• Carefully lift the caliper off the pads/rotor. Use a flat-blade screwdriver gently if you need a little help prying.
• Hang the caliper from the suspension using a bungee cord.
• Do not let the caliper hang by the brake hose.

Step 7: Remove the old pads and hardware

• Pull the inner and outer pads out by hand.
• Remove the stainless pad clips (abutment clips) from the bracket. Use a flat-blade screwdriver if needed.
• Spray the bracket contact areas with brake parts cleaner over a catch pan, then clean rust with a wire brush.

Step 8: Service the slide pins

• Pull the slide pins out of the caliper/bracket by hand.
• Wipe them clean and inspect the rubber boots for tears.
• Apply a thin coat of brake caliper slide pin grease (silicone brake lube) and reinstall the pins so they move smoothly.

Step 9: Install new hardware clips and new pads

• Snap the new abutment clips from the hardware kit into the bracket by hand.
• Apply a very thin film of silicone brake lube where the pad “ears” touch the clips.
• Install the new inner and outer pads into the bracket.

Step 10: Compress the caliper piston

• Place one old brake pad against the caliper piston face.
• Use a C-clamp (6" minimum) to slowly press the piston back into the caliper until it bottoms out.
• Check the brake fluid reservoir level as you compress; remove excess if it gets too high. Use brake parts cleaner only on parts, not in the reservoir.

Step 11: Reinstall the caliper

• Set the caliper back over the new pads/rotor by hand.
• Install the slide pin bolts using a ratchet and the correct-size socket (metric).
• Torque to 31 Nm (23 ft-lbs) for the caliper slide pin bolts.

Step 12: Reinstall the wheel

• Put the wheel on and hand-start all lug nuts.
• Snug the lug nuts with a 21mm socket and ratchet in a star pattern.
• Lower the van off the jack stands using the floor jack.
• Final-tighten lug nuts with a torque wrench: Torque to 190 Nm (140 ft-lbs) in a star pattern.

Step 13: Repeat on the other front side

• Repeat Steps 1–12 for the other front wheel.

---

✅ After Repair

• 🧪 Pump the brake pedal 8–12 times until it feels firm before starting to drive.
• 🧪 Check brake fluid level and top off with DOT 3 if needed.
• 🧪 With the engine running, do a slow test in an empty area to confirm normal stopping.
• 🧪 Pad break-in: make 6–10 smooth stops from ~30 mph to 5 mph, letting brakes cool briefly between stops. Avoid hard panic stops for the first 150–200 miles. Quiet stops now prevent noise later.
• 🧪 Recheck lug nut torque with a torque wrench after 25–50 miles: Torque to 190 Nm (140 ft-lbs).

---

💰 DIY vs Shop Cost

Shop Cost: $350-$650 (parts + labor)

DIY Cost: $80-$200 (parts only)

You Save: $270-$450 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---

🎯 Ready to get started?

HowToo makes it easy: same-day/2-day shipping on every part, plus all the tools and specialty tools you need! Check out the parts and tools sections below to add everything to your cart.

Assumption: This procedure matches the common front floating-caliper setup used on your Savana.
