🔧 Equinox - Front Brake Pads & Rotors Replacement

You'll be replacing the front brake pads and brake rotors on your Equinox. This restores braking power, reduces vibration, and prevents metal-on-metal damage.

Difficulty Level: Beginner/Intermediate | Estimated Time: 2–3 hours

---

⚠️ Safety & Precautions

• 🛑 Always support the vehicle with jack stands; never rely only on a jack.
• 🛑 Work on a flat, solid surface so the vehicle cannot roll or shift.
• 🛑 Wear safety glasses and mechanic gloves; brake dust and metal edges can injure you.
• 🛑 Do one side at a time so you can look at the other side as a reference.
• 🛑 Do not press the brake pedal when a caliper is removed; it can push the piston out.
• 🛑 Keep grease and oil off the friction surfaces of pads and rotors.
• 🛑 No battery disconnect is required for front brakes on your Equinox.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 🧰 Floor jack (rated 3-ton minimum)
• 🧰 Jack stands (rated 3-ton minimum), Qty: 2
• 🧰 Wheel chocks
• 🧰 Lug nut wrench or 22mm socket with breaker bar
• 🧰 13mm socket
• 🧰 18mm socket
• 🧰 Ratchet (3/8" drive)
• 🧰 Breaker bar (1/2" drive)
• 🧰 Torque wrench (ft-lbs scale, up to 150 ft-lbs)
• 🧰 C-clamp (6" or larger) or disc brake caliper piston tool
• 🧰 Flathead screwdriver (medium size)
• 🧰 Bungee cord or strong wire hanger
• 🧰 Wire brush
• 🧰 Shop rags
• 🧰 Brake cleaner spray
• 🧰 Small nylon or brass brush
• 🧰 Rubber mallet
• 🧰 Pick tool or small flat screwdriver
• 🧰 Safety glasses
• 🧰 Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• 🔩 Front brake pad set (left and right) - Qty: 1 set (replace in pairs)
• 🔩 Front brake rotors - Qty: 2 (replace in pairs)
• 🔩 Front brake hardware kit (pad abutment clips / anti-rattle clips) - Qty: 1 set
• 🔩 High-temperature silicone brake grease - Qty: 1 tube
• 🔩 Brake cleaner - Qty: 1–2 cans
• 🔩 Penetrating oil spray - Qty: 1 (for rusty rotor/hub)
• 🔩 Shop towels - Qty: As needed

---

📋 Before You Begin

• 🚗 Park the Equinox on level ground, put the transmission in PARK, and set the parking brake.
• 🧱 Place wheel chocks behind the rear wheels so the vehicle cannot roll.
• 📦 Lay out your new pads, rotors, and hardware so you know where everything is.
• 🧴 Loosen (but do not remove) both front wheel lug nuts slightly before lifting the vehicle.
• 🧯 Keep a small water spray bottle or extinguisher nearby as a general shop safety habit.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Loosen Front Wheel Lug Nuts

• Use the lug nut wrench or 22mm socket with breaker bar to loosen each front wheel lug nut about one turn while the vehicle is still on the ground.
• Do not remove the lug nuts yet; only break them loose.
• Loosening on the ground prevents the wheel from spinning.

Step 2: Lift and Support the Front of the Vehicle

• Position the floor jack under the front center jacking point or under the recommended front subframe area per your owner’s manual.
• Raise the front of the Equinox until both front wheels are off the ground.
• Place jack stands under the proper front pinch welds or frame points on both sides and slowly lower the vehicle onto the stands with the floor jack.
• Gently rock the vehicle by hand to confirm it is stable on the jack stands.

Step 3: Remove Front Wheels

• Use the 22mm socket and ratchet or lug wrench to remove the loosened lug nuts from one front wheel.
• Remove the wheel and set it aside.
• Repeat for the other front wheel once you finish one side, or remove both wheels now if you are comfortable.

Step 4: Inspect the Brake Assembly

• Look at the brake caliper (the clamp-shaped part), the pads (between caliper and rotor), and the rotor (the big disc).
• Note how the pads sit in the bracket and how the anti-rattle/abutment clips are installed; you will match this with the new hardware.
• Take a quick photo with your phone for reference.

Step 5: Remove Caliper Guide Pin Bolts

• On one side, locate the two small bolts on the back of the caliper (guide pin bolts).
• Use a 13mm socket and ratchet to loosen and remove the upper and lower guide pin bolts.
• Set the bolts aside in a clean place.

Step 6: Remove and Support the Caliper

• Use a flathead screwdriver to gently pry the caliper away from the rotor if needed.
• Lift the caliper off the pads and rotor.
• Use a bungee cord or wire hanger to hang the caliper from the spring or strut so that it is not hanging by the rubber brake hose.
• Never let the caliper dangle from the brake hose.

Step 7: Remove Old Brake Pads and Hardware

• Slide the inner and outer brake pads out of the caliper bracket by hand.
• Use a pick tool or small flat screwdriver to remove the metal abutment/anti-rattle clips from the caliper bracket.
• Note the position and shape; they must be reinstalled in the same orientation with the new hardware.

Step 8: Remove Caliper Bracket

• Locate the two larger bolts on the back of the steering knuckle that hold the caliper bracket.
• Use an 18mm socket with breaker bar to loosen and remove these two caliper bracket bolts.
• Remove the caliper bracket and set it on a clean surface.
• Torque on reassembly: 170 Nm (125 ft-lbs)

Step 9: Remove the Old Rotor

• If the rotor is stuck due to rust, spray a little penetrating oil where the rotor meets the hub.
• Let it soak for a few minutes, then tap around the rotor hat (center area) with a rubber mallet to loosen it.
• Slide the rotor straight off the hub.

Step 10: Clean Hub Surface

• Use a wire brush to clean the face of the hub where the rotor sits; remove rust and debris.
• Wipe with a shop rag and a bit of brake cleaner so the new rotor sits flat.
• A clean hub prevents brake pulsation later.

Step 11: Install New Rotor

• Spray the new rotor friction surfaces with brake cleaner to remove any protective oil, then dry with a clean rag.
• Place the new rotor onto the hub, aligning the bolt holes.
• You can temporarily install one lug nut by hand to hold the rotor flush while you work.

Step 12: Service Caliper Slide Pins

• Take the caliper bracket you removed earlier.
• Pull the two slide pins (also called guide pins) out of the bracket by hand; note which pin goes top and bottom.
• Clean old grease and dirt off the pins with a shop rag and a little brake cleaner.
• Apply a thin, even coat of high-temperature silicone brake grease to each pin and reinsert them into the bracket boots; make sure they move smoothly.

Step 13: Install New Pad Hardware

• Use a wire brush or small nylon/brass brush to clean the pad contact areas on the caliper bracket where the clips sit.
• Snap the new abutment/anti-rattle clips from your hardware kit into the same locations on the bracket.
• Apply a very light film of brake grease to the surfaces of the clips where the pad “ears” will touch. Do not get grease on pad friction material.

Step 14: Reinstall Caliper Bracket

• Position the caliper bracket over the new rotor and line up the bolt holes.
• Install the two caliper bracket bolts by hand to avoid cross-threading.
• Use the 18mm socket and ratchet to snug them, then use a torque wrench with 18mm socket to tighten to 170 Nm (125 ft-lbs).

Step 15: Install New Brake Pads

• Compare new pads to old ones to confirm shape and size match.
• Apply a thin layer of brake grease to the pad ears (the small tabs that sit in the clips) and to the backing plate where it contacts the caliper/piston; keep grease off the friction surface.
• Slide the inner and outer pads into the new clips in the bracket. They should move freely but fit snugly.

Step 16: Compress the Caliper Piston

• Take the hanging caliper and position an old brake pad against the piston face.
• Use a C-clamp or disc brake caliper piston tool to slowly push the piston back into the caliper housing until it is fully seated.
• Go slowly and check that the rubber boot around the piston does not pinch or tear.
• Compressing makes room for the thicker new pads.

Step 17: Reinstall the Caliper Over New Pads

• Position the caliper over the new pads and caliper bracket.
• Align the slide pin holes with the threaded holes in the bracket.
• Install the slide pin bolts by hand to avoid cross-threading.
• Use a 13mm socket and ratchet to tighten both guide pin bolts, then torque them with a torque wrench to 32 Nm (24 ft-lbs).

Step 18: Repeat on the Other Side

• Repeat Steps 5–17 on the other front wheel.
• Ensure both sides have new pads, rotors, and hardware installed the same way.

Step 19: Reinstall Front Wheels

• Place the wheel back onto the hub, lining up the holes.
• Install the lug nuts by hand and snug them in a star pattern using the 22mm socket and ratchet.

Step 20: Lower Vehicle and Torque Lug Nuts

• Use the floor jack to raise the vehicle slightly, remove the jack stands, then lower the vehicle fully to the ground.
• Use a torque wrench with 22mm socket to tighten the lug nuts in a star pattern to 140 Nm (103 ft-lbs).

Step 21: Pump Brake Pedal

• Sit in the driver’s seat and slowly press and release the brake pedal several times until it feels firm.
• This seats the pads against the rotors and takes up the gap from the compressed pistons.

---

✅ After Repair

• 🚦 Start the engine and press the brake pedal again to confirm it feels solid and does not sink.
• 🛻 Perform a short test drive in a safe area: make several gentle stops from low speeds to confirm there are no noises, pulling, or vibrations.
• 🧊 New pads and rotors need to be “bedded in”: for the first 200–300 km, avoid hard panic stops unless necessary and avoid riding the brakes.
• 🔍 After the test drive, check around the front wheels for any obvious leaks or loose hardware, and recheck lug nut torque once the brakes have cooled.

---

💰 DIY vs Shop Cost

Shop Cost: $450–$650 (parts + labor)

DIY Cost: $160–$260 (parts only)

You Save: $290–$390 by doing it yourself!

Shop labor rates vary but typically run $100–$150/hour. This repair takes a shop approximately 1.5–2.0 hours.

---
