🔧 Front Brake Pads & Rotors - Replacement

Replacing the front pads and rotors restores stopping power, reduces brake noise, and fixes pulsation from warped or worn rotors. On your Land Cruiser, this job is straightforward if you keep the caliper supported and torque everything correctly.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• Work on level ground and chock the rear wheels before lifting the front.
• Use jack stands. Never rely on the floor jack alone.
• Do not press the brake pedal with a caliper removed.
• Support the caliper with a hanger or wire so the brake hose is not stretched.
• Brake dust can be harmful. Do not blow it off with compressed air.
• No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 14mm socket
• 17mm socket
• Ratchet
• Breaker bar
• Torque wrench
• Flat blade screwdriver
• Caliper hanger wire
• C-clamp or brake caliper compression tool
• Wire brush
• Brake cleaner
• Shop towels
• Safety glasses
• Mechanic gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Brake pad hardware kit - Qty: 1
• Brake cleaner - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Loosen the front lug nuts slightly before lifting the vehicle.
• Lift the front and support it securely on jack stands.
• If the brake fluid reservoir is full, open it carefully before compressing the caliper pistons.
• Keep the rotor clean.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the front wheels

• Use the 21mm socket and breaker bar to loosen the lug nuts, then remove the wheels.
• Set the wheels aside flat so they cannot roll.

Step 2: Remove the brake caliper

• Use the 14mm socket to remove the caliper slide pin bolts.
• Lift the caliper off the bracket and hang it with caliper hanger wire.
• Do not let the hose hang.

Step 3: Remove the old pads and hardware

• Pull the brake pads out of the bracket.
• Remove the pad clips and shims if they are being replaced.
• Clean the bracket contact points with a wire brush and brake cleaner.

Step 4: Remove the caliper bracket

• Use the 17mm socket to remove the caliper bracket bolts.
• Remove the bracket from the knuckle.
• Torque to 107 Nm (79 ft-lbs) when reinstalling.

Step 5: Remove the rotor

• Pull the rotor straight off the hub.
• If it is stuck, tap the rotor hat lightly with a rubber mallet or threaded removal holes if equipped.
• Clean the hub face with a wire brush so the new rotor sits flat.

Step 6: Install the new rotor

• Spray the new rotor with brake cleaner and wipe it dry.
• Install the rotor on the hub.
• If the rotor has a retaining screw, install and snug it with the correct driver.

Step 7: Reinstall the caliper bracket and pads

• Install the caliper bracket using the 17mm socket.
• Torque to 107 Nm (79 ft-lbs).
• Install the new pad hardware and brake pads.
• Apply a small amount of brake grease to pad contact points only if included with the pad kit.

Step 8: Compress the caliper piston

• Use a C-clamp or brake caliper compression tool to push the piston back into the caliper.
• Compress slowly and watch the brake fluid level.
• Go slow to avoid fluid overflow.

Step 9: Reinstall the caliper

• Set the caliper over the new pads.
• Install the slide pin bolts with the 14mm socket.
• Torque to 35 Nm (26 ft-lbs).

Step 10: Reinstall the wheels

• Install the front wheels and hand-tighten the lug nuts.
• Lower the vehicle and torque the lug nuts in a star pattern with the 21mm socket.
• Torque to 131 Nm (97 ft-lbs).

---

✅ After Repair

• Press the brake pedal several times before moving the vehicle. The pedal should firm up.
• Check the brake fluid level and correct it if needed.
• Test the brakes at low speed first.
• Listen for rubbing or clicking and recheck lug nut torque after the test drive.
• Bed the pads gently.

---

💰 DIY vs Shop Cost

Shop Cost: $650-$1,100 (parts + labor)

DIY Cost: $220-$420 (parts only)

You Save: $430-$680 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
