🔧 CX-9 - Front Brake Pads & Rotor Replacement

You’ll remove the front wheels, take off the brake calipers and brackets, replace the rotors, then install new pads and reassemble. This restores braking performance and fixes common issues like pulsation (warped rotors) and squealing or thin pads.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

Assumption: Torque specs can vary slightly by wheel/brake package; verify with a factory spec source if available.

---

⚠️ Safety & Precautions

• 🛑 Support the CX-9 with jack stands on solid ground—never rely on a jack alone.
• 🧤 Brake dust is harmful—wear gloves and a dust mask, and use brake cleaner instead of compressed air.
• 🔥 Brakes get hot—let the front brakes cool before touching parts.
• 🧪 Brake fluid damages paint—wipe spills immediately.
• 🚫 Do not press the brake pedal while a caliper is off the rotor.
• 🔋 Battery disconnect is not required for front brake/rotor service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2" drive breaker bar
• 1/2" drive torque wrench (20-200 ft-lbs range)
• 3/8" drive ratchet
• 3/8" drive torque wrench (10-80 ft-lbs range)
• Socket set (10mm-21mm)
• 14mm socket
• 17mm socket
• Flat blade screwdriver
• C-clamp (6")
• Brake caliper hanger hook (specialty)
• Wire brush
• Rubber mallet
• Bungee cord
• Catch pan
• Safety glasses
• Nitrile gloves
• Dust mask

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Front pad hardware/abutment clip kit - Qty: 1
• Brake caliper slide pin grease (silicone) - Qty: 1
• Brake parts cleaner - Qty: 1
• Brake fluid (DOT 3) - Qty: 1 quart
• Medium-strength threadlocker - Qty: 1

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to P, and set the parking brake.
• 🧱 Place wheel chocks behind the rear wheels.
• 🔓 Loosen the front lug nuts 1/2 turn before lifting, using a 21mm socket and breaker bar.
• 🧴 Open the hood and locate the brake fluid reservoir. Keep the cap loosely set on top (do not remove it completely). This helps piston push-back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Lift the front at the approved front jacking point using a floor jack.
• Set the vehicle onto jack stands placed at the proper front support points.
• Give the CX-9 a gentle shake to confirm it’s stable.

Step 2: Remove the front wheels

• Remove lug nuts with a 21mm socket and ratchet.
• Remove both front wheels and set them aside.
• During reassembly, lug nuts typically torque to Torque to 108-147 Nm (80-108 ft-lbs) using a 1/2" drive torque wrench.

Step 3: Remove the caliper (the clamp that squeezes the pads)

• Turn the steering wheel to give yourself room (left side: turn wheel right; right side: turn wheel left).
• Use a flat blade screwdriver to gently pry the caliper outward a few millimeters. Makes bolt removal easier.
• Remove the two caliper slide bolts using a 14mm socket and 3/8" drive ratchet.
• Lift the caliper off the bracket and hang it from the strut spring using a brake caliper hanger hook (specialty) or bungee cord. Never hang by the hose.
• Reinstall torque (typical): Torque to 25-35 Nm (18-26 ft-lbs) using a 3/8" drive torque wrench.

Step 4: Remove the pads and the caliper bracket (the pad “frame”)

• Slide the old pads out of the bracket by hand.
• The caliper bracket is the heavy metal mount the pads sit in.
• Remove the caliper bracket bolts using a 17mm socket and breaker bar.
• Reinstall torque (typical): Torque to 90-120 Nm (66-89 ft-lbs) using a 1/2" drive torque wrench.
• If desired, apply a small amount of medium-strength threadlocker to clean bracket bolt threads before reinstalling.

Step 5: Remove the old rotor

• Pull the rotor straight off the hub by hand.
• If it’s stuck from rust, tap the rotor hat between the studs with a rubber mallet until it breaks free.
• Use a wire brush to clean rust off the hub face (where the rotor sits). A clean hub prevents rotor wobble.

Step 6: Install the new rotor

• Spray both sides of the new rotor with brake parts cleaner to remove protective oil.
• Install the rotor onto the hub.
• To hold the rotor tight while you work, thread on a couple lug nuts backward by hand, then snug them using a 21mm socket (do not fully torque yet).

Step 7: Service the bracket hardware and slide pins

• Remove the old pad clips from the bracket using a flat blade screwdriver.
• Clean the clip “shelves” on the bracket using a wire brush and brake parts cleaner.
• Install the new clips from the hardware kit.
• Pull the slide pins out (they’re the smooth pins the caliper floats on), wipe them clean, and apply brake caliper slide pin grease (silicone).
• Reinsert the slide pins and ensure they move smoothly by hand.

Step 8: Reinstall the bracket and install new pads

• Reinstall the caliper bracket using a 17mm socket and 1/2" drive torque wrench.
• Torque to 90-120 Nm (66-89 ft-lbs).
• Install the new pads into the bracket by hand.
• Apply a thin smear of brake caliper slide pin grease (silicone) to pad “ears” (the metal ends that touch the clips). Do not get grease on pad friction material.

Step 9: Compress the caliper piston and reinstall the caliper

• Place one old brake pad against the caliper piston.
• Use a C-clamp (6") to slowly press the piston back until it’s fully seated. Go slow; watch fluid level.
• Check the brake fluid reservoir—remove a little with a clean towel if it’s getting too high (use a catch pan underneath).
• Install the caliper over the new pads.
• Install the slide bolts using a 14mm socket, then torque with a 3/8" drive torque wrench.
• Torque to 25-35 Nm (18-26 ft-lbs).

Step 10: Repeat on the other front wheel

• Repeat Steps 3 through 9 for the other side.
• Work one side at a time so you can reference the assembled side if needed.

Step 11: Reinstall wheels and lower the vehicle

• Reinstall wheels and hand-thread lug nuts.
• Lower the CX-9 off the jack stands using the floor jack.
• Torque lug nuts in a star pattern using a 1/2" drive torque wrench: Torque to 108-147 Nm (80-108 ft-lbs).

---

✅ After Repair

• 🦶 Before starting the engine, pump the brake pedal 10-15 times until it feels firm. This seats the pads.
• 🧪 Check brake fluid level and top off with DOT 3 if needed.
• 👀 Check for leaks around calipers and confirm no tools are left in the engine bay.
• 🚗 Bed-in (break-in) the pads/rotors: make 6-10 moderate stops from ~40 mph to ~10 mph, with 30-60 seconds of driving between stops to cool. Avoid hard panic stops for the first 200 miles.
• 🔊 If you hear grinding, strong pulling, or the pedal stays soft, stop driving and recheck your work.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $180-$450 (parts only)

You Save: $270-$450 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
