🔧 HR-V - Front Brake Pads & Rotor Replacement

You’ll remove the front calipers, replace the brake pads, and swap the rotors. Worn pads reduce stopping power, and worn/warped rotors can cause vibration or squealing.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🛑 Work on level ground and support your HR-V with jack stands, not just a jack.
• 🔥 Brakes can be hot—let them cool before touching.
• 🧴 Brake dust is unhealthy—use brake cleaner, don’t blow with compressed air.
• 🧲 Do not let the caliper hang by the brake hose—support it with a hook/strap.
• 🧯 Keep grease off pad/rotor friction surfaces; clean rotors before installing.
• 🔋 Battery disconnect is not required for this front brake job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Wheel chocks
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Breaker bar 1/2" drive
• Torque wrench 1/2" drive (20-150 ft-lbs range)
• 19mm socket
• 12mm socket
• 17mm socket
• Ratchet 3/8" drive
• Impact screwdriver with JIS #3 bit
• Flat-blade screwdriver
• Bungee cord
• Brake caliper piston compressor tool (specialty)
• Wire brush
• Rubber mallet
• Drain pan

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Replace in pairs - Qty: 2
• Front brake hardware kit (pad clips/shims) - Qty: 1
• Brake lubricant (silicone or synthetic caliper grease) - Qty: 1
• Brake parts cleaner - Qty: 2 cans
• Anti-seize compound - Qty: 1

---

📋 Before You Begin

• 🧭 Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• 🛞 Crack the front lug nuts loose with a 19mm socket and breaker bar before lifting.
• 🧴 Open the hood and locate the brake fluid reservoir. You can loosen the cap to help the piston retract, but watch the fluid level so it doesn’t overflow.
• 🧰 Quick terms: the caliper squeezes the pads; the caliper bracket is the heavy mount that holds the pads.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and secure the front end

• Use a floor jack (rated 3-ton minimum) to lift one front corner at the proper jack point.
• Place jack stands (rated 3-ton minimum) under a solid support point and lower onto the stand.
• Remove the wheel using a 19mm socket and ratchet 3/8" drive.

Step 2: Remove the caliper (do not stretch the hose)

• Turn the steering wheel to give yourself more room at the caliper.
• Remove the two caliper slide bolts using a 12mm socket and ratchet 3/8" drive.
• Lift the caliper off the bracket and hang it from the suspension using a bungee cord.
• Never let the caliper hang by the hose.

Step 3: Remove the old pads and hardware

• Slide the old pads out of the bracket by hand; use a flat-blade screwdriver gently if they’re stuck.
• Remove the stainless pad clips/hardware from the bracket.
• Clean the bracket pad “tracks” using brake parts cleaner and a wire brush.

Step 4: Remove the caliper bracket

• Remove the two caliper bracket bolts using a 17mm socket and breaker bar 1/2" drive.
• Set the bracket aside where it won’t get dirty on the pad surfaces.
• During reassembly: Torque to 108 Nm (80 ft-lbs).

Step 5: Remove the rotor

• If your HR-V has rotor retaining screws, remove them using an impact screwdriver with JIS #3 bit (JIS is the Japanese-style Phillips that fits Honda screws correctly).
• Pull the rotor straight off. If it’s stuck, tap the rotor hat with a rubber mallet.
• Clean the hub face with a wire brush so the new rotor sits flat.
• Apply a very thin film of anti-seize compound to the hub center (not the wheel studs).

Step 6: Install the new rotor

• Spray both sides of the new rotor with brake parts cleaner to remove packing oil, then wipe clean.
• Install the rotor onto the hub. Reinstall the retaining screws (if equipped) using the impact screwdriver with JIS #3 bit until snug.

Step 7: Prepare the bracket and slide pins

• Inspect the caliper slide pins (they should move smoothly). If they feel sticky, pull them out, wipe clean, and apply a thin coat of brake lubricant (silicone or synthetic caliper grease).
• Install the new pad hardware clips into the bracket.
• Apply a thin layer of brake lubricant where the pad “ears” touch the hardware clips.
• Grease goes on metal contact points only.

Step 8: Reinstall the bracket

• Position the bracket over the rotor and start the bolts by hand.
• Tighten using a 17mm socket and torque wrench 1/2" drive (20-150 ft-lbs range).
• Torque to 108 Nm (80 ft-lbs).

Step 9: Install the new pads and compress the piston

• Install the new pads into the bracket.
• Place an old pad against the caliper piston, then use a brake caliper piston compressor tool (specialty) to slowly push the piston back into the caliper.
• Watch the brake fluid reservoir while compressing; use a drain pan underneath if you need to remove a little fluid to prevent overflow.

Step 10: Reinstall the caliper

• Slide the caliper over the new pads/rotor.
• Install and tighten the slide bolts using a 12mm socket and torque wrench 1/2" drive (20-150 ft-lbs range).
• Torque to 34 Nm (25 ft-lbs).

Step 11: Reinstall the wheel

• Reinstall the wheel and hand-thread the lug nuts.
• Lower the vehicle and torque the lug nuts in a star pattern using a 19mm socket and torque wrench 1/2" drive (20-150 ft-lbs range).
• Torque to 108 Nm (80 ft-lbs).

Step 12: Repeat on the other front wheel

• Repeat the same steps for the other side.
• Always replace rotors/pads in pairs.

---

✅ After Repair

• 🦶 With the engine off, pump the brake pedal slowly 10-15 times until it feels firm (this seats the pistons against the new pads).
• 🧴 Check brake fluid level and reinstall the reservoir cap.
• 🛞 Test drive at low speed first, confirm normal stopping and no pulling/noise.
• 🧪 Bed-in procedure: make 8-10 moderate stops from ~30 mph to ~5 mph, letting brakes cool a bit between stops. Avoid hard stops for the first 200 miles.
• 🔍 Re-check for any fluid leaks around the calipers and re-check lug torque after 25-50 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $160-$380 (parts only)

You Save: $290-$470 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
