🔧 Rogue - Front Brake Pads & Rotor Replacement

You’ll remove the front wheels, take the calipers off, replace the brake pads and rotors, then reassemble and torque everything correctly. New rotors give the new pads a flat, clean surface so you get smooth, quiet braking and avoid vibration.

Difficulty Level: Intermediate | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• 🛑 Support your Rogue with jack stands; never rely on a jack.
• 🛑 Do not press the brake pedal with a caliper removed.
• 🛑 Brake dust is harmful—use brake cleaner, not compressed air.
• 🛑 Let brakes cool completely before starting.
• 🛑 Hang the caliper with a hook; don’t let it hang by the brake hose.
• 🛑 Keep grease off pad/rotor friction surfaces.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 1/2" drive breaker bar
• Torque wrench (20-200 ft-lbs range)
• 14mm socket
• 19mm socket
• Flathead screwdriver
• C-clamp (6" minimum)
• Caliper hanger hook
• Wire brush
• Rubber mallet
• Brake parts cleaner spray
• Shop towels
• Nitrile gloves
• Safety glasses
• Bungee cord

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1
• Front brake rotors - Qty: 2
• Front brake hardware kit (pad clips/abutment clips) - Qty: 1
• Brake caliper grease (silicone) - Qty: 1
• Medium-strength threadlocker - Qty: 1

---

📋 Before You Begin

• Park on level ground, turn the steering wheel straight, and set the parking brake.
• Place wheel chocks behind the rear wheels.
• Loosen the front lug nuts 1/2 turn using a 21mm socket and breaker bar before lifting.
• Open the hood and locate the brake fluid reservoir; leave the cap resting loose (don’t remove it fully). This helps when pushing the pistons back.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Lift and remove the front wheels

• Lift the front using a floor jack (rated 3-ton minimum) at the front center jack point.
• Set the Rogue onto jack stands (rated 3-ton minimum) at the front pinch welds/side support points.
• Remove lug nuts with a 21mm socket and ratchet, then remove both front wheels.

Step 2: Remove the caliper (the “squeezing” part)

• Turn the steering wheel to give yourself room to work on that side.
• Remove the two caliper slide bolts using a 14mm socket and ratchet.
• Carefully lift the caliper off the pads.
• Support the caliper with a caliper hanger hook or bungee cord. (A caliper hanger is a simple hook that holds the caliper so the brake hose isn’t stressed.)

Step 3: Remove the old pads and hardware

• Pull the brake pads out by hand; use a flathead screwdriver gently if they’re stuck.
• Remove the pad clips/abutment clips from the caliper bracket using a flathead screwdriver.
• Clean the bracket “pad sliding” surfaces with brake parts cleaner spray and a wire brush.
• Clean metal lets pads slide quietly.

Step 4: Remove the caliper bracket (the pad “frame”)

• Remove the two large caliper bracket bolts using a 19mm socket and breaker bar.
• Set the bracket aside.
• When reinstalling later: apply a small amount of medium-strength threadlocker to clean bolt threads and Torque to 137 Nm (101 ft-lbs).
• (The caliper bracket is the fixed mount the pads ride in.)

Step 5: Remove the rotor

• Pull the rotor straight off the hub.
• If it’s stuck from rust, spray the hub area with brake parts cleaner spray and tap the rotor hat firmly with a rubber mallet to break it loose.
• Clean the hub face with a wire brush and wipe with shop towels. A clean hub helps prevent brake shake.

Step 6: Install the new rotor

• Spray both sides of the new rotor with brake parts cleaner spray and wipe with shop towels (removes shipping oil).
• Place the rotor onto the hub and hold it flush by threading on one lug nut by hand (use the vehicle’s lug nut) to keep it from wobbling while you work.

Step 7: Reinstall the caliper bracket

• Position the bracket over the new rotor.
• Install bracket bolts using a 19mm socket and ratchet, then tighten with a torque wrench.
• Torque to 137 Nm (101 ft-lbs).

Step 8: Install new pad hardware and pads

• Install the new pad clips from your front brake hardware kit into the bracket.
• Apply a thin film of brake caliper grease (silicone) where the pad “ears” contact the clips (metal-to-metal contact points only).
• Install the new pads into the bracket by hand.
• Grease only on contact points, never rotor.

Step 9: Compress the caliper piston and reinstall the caliper

• Place an old pad against the caliper piston face.
• Slowly compress the piston using a C-clamp (6" minimum) until the piston is fully seated.
• Reinstall the caliper over the new pads.
• Install the slide bolts using a 14mm socket and ratchet, then tighten with a torque wrench.
• Torque to 35 Nm (26 ft-lbs).
• (The slide bolts/pins let the caliper move evenly as the pads wear.)

Step 10: Repeat on the other front wheel

• Repeat Steps 2 through 9 on the other side using the same tools and torque specs.
• Do one side at a time to compare.

Step 11: Reinstall wheels and torque lug nuts

• Reinstall both wheels and hand-thread lug nuts.
• Lower the Rogue off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Tighten lug nuts in a star pattern with a torque wrench.
• Torque to 113 Nm (83 ft-lbs).

---

✅ After Repair

• With the engine OFF, pump the brake pedal slowly 10-15 times until it feels firm.
• Check brake fluid level at the reservoir; top off only if needed.
• Start the engine and confirm the pedal feels normal (it may drop slightly with brake boost).
• Test in a safe area at low speed first.
• Pad break-in (bedding): do 6-10 moderate stops from 30–40 mph to 5 mph, allowing a little cool-down driving between stops. Avoid hard stops for the first 150-200 miles.
• Recheck lug nut torque with a torque wrench after 25-50 miles.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$850 (parts + labor)

DIY Cost: $160-$350 (parts only)

You Save: $290-$500 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
