🔧 Front Brakes and Rotors - Replacement

Replacing the front brake pads and rotors restores stopping power and helps fix pulsation, noise, and uneven braking. On your F-150, the front brakes use a caliper, bracket, pads, and rotor setup, so both pads and rotors should be serviced together for even wear.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• Work on a flat surface with the parking brake set and the transmission in Park.
• Use jack stands. Never rely on a jack alone.
• Brake dust can be harmful. Do not blow it off with compressed air.
• Do not press the brake pedal with a caliper removed.
• If the brake fluid reservoir is very full, watch for overflow when compressing the caliper piston.
• No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 1/2-inch drive breaker bar
• Ratchet
• 15mm socket
• 18mm socket
• Torque wrench
• C-clamp or brake caliper compression tool (specialty)
• Bungee cord or mechanic's hook
• Flat-blade screwdriver
• Wire brush
• Brake cleaner
• Safety glasses
• Nitrile gloves

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front brake pad set - Qty: 1 set
• Front brake rotors - Replace in pairs - Qty: 2
• Brake caliper slide pin grease - Qty: 1
• Brake cleaner - Qty: 1 can

---

📋 Before You Begin

• Park on level ground and chock the rear wheels.
• Loosen the front lug nuts slightly before lifting.
• Lift the front of the truck and support it securely on jack stands.
• Remove the front wheels.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the wheel

• Use a 21mm socket and breaker bar to loosen and remove the lug nuts.
• Set the wheel aside.
• Keep lug nuts together so none get lost.

Step 2: Remove the caliper

• Use an 18mm socket to remove the caliper slide pin bolts.
• Lift the caliper off the bracket and support it with a bungee cord or mechanic's hook.
• Do not let the caliper hang by the brake hose.

Step 3: Remove the brake pads

• Slide the old brake pads out of the caliper bracket.
• Remove the pad clips if your new pads include replacements.
• Note how the pads sit in the bracket before removal.

Step 4: Remove the caliper bracket

• Use an 18mm socket to remove the caliper bracket bolts.
• Remove the bracket from the steering knuckle.
• Torque on installation: 184 Nm (136 ft-lbs)

Step 5: Remove the rotor

• Pull the rotor straight off the hub.
• If it is stuck, use a flat-blade screwdriver or tap lightly from behind.
• Clean rust off the hub with a wire brush.
• A clean hub helps prevent brake pulsation.

Step 6: Install the new rotor

• Spray the new rotor with brake cleaner and wipe it dry.
• Install the rotor onto the hub.
• If the rotor has a retaining screw, reinstall it if equipped.

Step 7: Reinstall the caliper bracket

• Put the bracket back on the steering knuckle.
• Use the 18mm socket to tighten the bolts.
• Torque to 184 Nm (136 ft-lbs)

Step 8: Compress the caliper piston

• Use a C-clamp or brake caliper compression tool to push the piston fully back into the caliper.
• Watch the brake fluid reservoir while compressing.
• Push slowly to avoid damaging seals.

Step 9: Install the new pads

• Apply a thin layer of brake caliper slide pin grease to the pad contact points and slide pins.
• Install the new pads into the bracket.
• Make sure the inner and outer pads are in the correct position.

Step 10: Reinstall the caliper

• Slide the caliper over the new pads.
• Use the 18mm socket to install and tighten the caliper slide pin bolts.
• Torque to 34 Nm (25 ft-lbs)

Step 11: Reinstall the wheel

• Put the wheel back on and hand-tighten the lug nuts.
• Lower the truck until the tire just touches the ground.
• Use a 21mm socket and torque wrench to tighten the lug nuts in a star pattern.
• Torque to 204 Nm (150 ft-lbs)

Step 12: Repeat on the other side

• Always replace front brakes and rotors in pairs.
• Repeat the same steps on the opposite side.

---

✅ After Repair

• Before driving, pump the brake pedal slowly until it feels firm.
• Check the brake fluid level and top off if needed.
• Test the brakes at low speed first.
• Expect a short break-in period for the new pads and rotors.
• Avoid hard stops for the first 200 miles if possible.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $180-$350 (parts only)

You Save: $270-$550 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
