🔧 Grand Cherokee - Engine Mount Replacement

On your Grand Cherokee, the engine mounts support the 6.4L and keep vibration under control while you accelerate, brake, and shift. Replacing worn mounts usually fixes clunks/thumps on takeoff, excess vibration in gear, and drivetrain “lash” noises.

Difficulty Level: Advanced | Estimated Time: 3-6 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the engine before loosening mounts; it can drop suddenly.
• ⚠️ Use jack stands; never work under a vehicle held by a jack only.
• ⚠️ Let the exhaust cool fully; the mount areas are near hot components.
• ⚠️ If you lift the engine, lift slowly and watch hoses/wiring for stretching.
• 🔋 Recommended: disconnect the negative battery cable to reduce accidental short risk.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• Wood block (2x6 in or similar)
• Engine support bar (specialty)
• Metric socket set (10mm, 13mm, 15mm, 18mm, 21mm)
• Metric wrench set (13mm, 15mm, 18mm)
• 3/8 in ratchet
• 1/2 in breaker bar
• Socket extensions (3 in, 6 in, 12 in)
• Universal joint adapter
• Trim clip remover
• Torque wrench (20–250 ft-lbs range)
• Flat pry bar
• Penetrating oil
• Paint marker

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Right engine mount - Qty: 1
• Left engine mount - Qty: 1
• Engine mount fastener kit - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and chock the rear wheels.
• Open the hood and remove the plastic engine cover by pulling straight up (it’s held by rubber grommets).
• Disconnect the negative battery terminal using a 10mm socket.
• Plan how you’ll support the engine: an engine support bar (specialty) from above is safest; a floor jack with a wood block under the oil pan can work if you lift gently. (An engine support bar holds the engine from the top using hooks and a crossbar.)

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure your Grand Cherokee

• Use a floor jack (rated 3-ton minimum) to lift the front at the approved front lift point.
• Set the vehicle onto jack stands (rated 3-ton minimum) at the front support points.
• Give the vehicle a firm shake check before you go underneath.

Step 2: Remove the lower splash shields/skid panels

• Use a trim clip remover for plastic push pins (a push pin is a plastic fastener that pops out in two stages).
• Use a 13mm socket and 3/8 in ratchet to remove any bolts holding the underbody panels.
• Set hardware aside in labeled piles (left/right) using a simple “egg carton” organizer.

Step 3: Support the engine

• If using an engine support bar (specialty), install it across the fender rails and take the engine’s weight slightly (do not lift yet).
• If using a jack: place a wood block (2x6 in or similar) on the floor jack pad and gently contact the oil pan, then lift just enough to “take the load.”
• Stop if you see the radiator fan shroud, hoses, or wiring start to tension.

Step 4: Loosen the mount through-bolt(s)

• Spray fasteners with penetrating oil and wait a few minutes.
• Use a paint marker to mark the position of the mount and brackets (helps alignment during install).
• Use a 21mm socket with a 1/2 in breaker bar to loosen the engine mount through-bolt nut/bolt.
• Do not fully remove the through-bolt until the engine is clearly supported.

Step 5: Remove the right engine mount

• Use socket extensions (3 in, 6 in, 12 in) and a universal joint adapter to access the right-side mount fasteners.
• Use a 15mm socket or 18mm socket (varies by fastener position) to remove the mount-to-frame bolts.
• Use a 21mm socket to slide out the through-bolt.
• Use a flat pry bar to gently persuade the mount free if it’s stuck.

Step 6: Remove the left engine mount

• Repeat the same approach on the left side using the 15mm socket, 18mm socket, and 21mm socket as needed.
• If bolt holes don’t line up, raise/lower the engine slightly with the engine support bar (specialty) or floor jack to relieve bind.
• Small height changes make big alignment differences.

Step 7: Install the new mounts (leave bolts slightly loose first)

• Position the new mounts exactly like the originals (use your paint marker reference).
• Start all mount-to-frame bolts by hand using a 15mm socket / 18mm socket so you don’t cross-thread.
• Slide the through-bolt back in using a 21mm socket to guide/hold it straight.

Step 8: Tighten fasteners to specification

• With the engine sitting naturally (no lifting force), tighten hardware using a torque wrench (20–250 ft-lbs range).
• Engine mount through-bolt: Torque to 203 Nm (150 ft-lbs)
• Engine mount-to-cradle/frame bolts: Torque to 95 Nm (70 ft-lbs)
• Engine mount bracket-to-engine bolts (if removed): Torque to 61 Nm (45 ft-lbs)

Step 9: Reinstall shields/skid panels and lower the vehicle

• Reinstall panels using a 13mm socket and 3/8 in ratchet.
• Reinstall push pins using a trim clip remover to align them, then press to lock.
• Lower the vehicle using the floor jack (rated 3-ton minimum).

Step 10: Reconnect battery and reinstall engine cover

• Reconnect the negative battery terminal using a 10mm socket.
• Press the engine cover back onto its grommets until it seats.

---

✅ After Repair

• Start the engine and let it idle in Park for 1–2 minutes. Listen for new knocks or rattles.
• With your foot on the brake, shift Park → Reverse → Drive and feel for excessive engine movement.
• Take a short test drive. Recheck for clunks on acceleration and when coming to a stop.
• After the test drive, do a quick visual check underneath for any disturbed shields or loose hardware.

---

💰 DIY vs Shop Cost

Shop Cost: $900-$1,800 (parts + labor)

DIY Cost: $220-$650 (parts only)

You Save: $680-$1,150 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 3-6 hours.

---
