🔧 Taillight Bulbs - Replacement

This job replaces both rear taillight bulbs on your Equinox. On this vehicle, the bulb sockets are typically accessed from inside the cargo area, so you do not need to remove the whole lamp assembly unless the lamp is LED-only. If your rear lamps are not lighting at all, this is the first thing to check before replacing the entire housing.

Difficulty Level: Beginner | Estimated Time: 0.5-1 hour

---

⚠️ Safety & Precautions

• Turn the ignition off and remove the key/fob from the vehicle.
• Let the bulbs cool before touching them. Hot bulbs can burn your fingers.
• Use care around plastic trim so the clips do not break.
• Do not touch the glass of a new halogen bulb with bare hands; oil from skin can shorten bulb life.
• No battery disconnect is required for this repair.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Trim panel tool
• Small flat-blade screwdriver
• Gloves
• Safety glasses
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Left rear taillight bulb - Qty: 1
• Right rear taillight bulb - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the liftgate for better access to the rear lamp service area.
• Keep the new bulbs in their packaging until you are ready to install them.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the rear lamp service area

• Open the liftgate.
• Use the trim panel tool to gently pry off the rear side cargo trim access cover behind the taillight area.
• Work slowly to avoid breaking clips.

Step 2: Remove the bulb socket

• Locate the bulb socket on the back of the taillight housing.
• Use your hand to turn the socket counterclockwise and pull it straight out.
• If it is tight, use a small flat-blade screwdriver carefully to help release the tab, but do not force it.

Step 3: Replace the bulb

• Pull the old bulb straight out of the socket.
• Install the new bulb by pressing it straight into the socket until fully seated.
• Make sure the bulb is locked in straight and not crooked.

Step 4: Reinstall the socket

• Line up the socket with the housing.
• Use your hand to turn it clockwise until it locks in place.
• Do not overtighten.

Step 5: Repeat on the other side

• Perform the same steps for the opposite taillight bulb.
• Replace both bulbs together so the light output matches side to side.

Step 6: Reinstall the trim cover

• Use your hands to press the cargo trim access cover back into place.
• Make sure all clips are fully seated.

---

✅ After Repair

• Turn the ignition on and test both taillights.
• Check brake lights, parking lights, and turn signals if those bulbs share the same socket.
• Walk around the vehicle and confirm both sides match in brightness.
• If a bulb does not work, remove it and make sure it is seated correctly.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$180 (parts + labor)

DIY Cost: $20-$50 (parts only)

You Save: $60-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1 hour.

---
