🔧 Taillight Bulbs - Replacement

Your XC60 uses serviceable rear lamp bulbs on bulb-equipped positions. Replacing both sides together keeps the rear lighting balanced and avoids doing the job twice. If one side has LED lighting, that side may require a lamp assembly instead of a bulb.

Difficulty Level: Beginner | Estimated Time: 0.5-1 hour

---

⚠️ Safety & Precautions

• Turn the lights off and let the bulbs cool before touching them.
• Disconnect the negative battery cable if you want to avoid shorting a circuit while working.
• Do not touch glass bulb surfaces with bare fingers; oil from skin can shorten bulb life.
• Make sure the lamp housing is fully seated and sealed after repair.
• If a bulb does not fit the socket type, stop and verify the correct bulb style before forcing it.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Phillips screwdriver
• Flat-blade screwdriver
• 10mm socket
• Ratchet
• Trim clip removal tool
• Gloves
• Safety glasses

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Left taillight bulb - Qty: 1
• Right taillight bulb - Qty: 1
• Bulb socket seal or gasket - Qty: 2

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Switch the ignition off.
• Open the tailgate and clear cargo from the rear side trim area.
• If your XC60 has access panels behind the rear lamps, remove the trim carefully.
• Use a flashlight so you can see the bulb holders clearly.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Open access to the rear lamp bulbs

• Open the tailgate.
• Use a trim clip removal tool and flat-blade screwdriver to carefully remove the rear access cover or trim panel behind the taillight area.
• Set the panel and clips aside in order.

Step 2: Remove the bulb holder

• Reach behind the taillight and locate the bulb holder.
• Twist the bulb holder counterclockwise by hand or with a flat-blade screwdriver if the holder is snug.
• Pull the bulb holder straight out of the lamp housing.

Step 3: Replace the bulb

• Remove the old bulb from the socket.
• Install the new bulb using clean gloves.
• Make sure the bulb sits fully in the socket and matches the original style.
• Do not force the bulb into the socket.

Step 4: Test the bulb before reassembly

• Reconnect the bulb holder to the lamp housing temporarily.
• Turn on the parking lights, brake lights, or turn signals as needed to confirm the bulb works.
• If the bulb does not light, check the socket orientation and bulb fit.

Step 5: Reinstall the bulb holder and trim

• Insert the bulb holder back into the taillight housing.
• Twist it clockwise until it locks in place.
• Reinstall the access cover or trim panel using the trim clip removal tool if needed.

Step 6: Repeat on the other side

• Use the same steps on the opposite taillight.
• Confirm both bulbs work before finishing.

---

✅ After Repair

• Check tail lights, brake lights, and turn signals from behind the vehicle.
• Make sure the rear access covers are fully installed.
• Verify there are no warning messages on the dash.
• If one side still does not work, inspect the fuse, socket, or lamp assembly.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$250 (parts + labor)

DIY Cost: $20-$60 (parts only)

You Save: $100-$190 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1 hour.

---
