🔧 Gladiator - Tail Light Bulb Replacement

On your Gladiator, the tail lamp housing comes off from the outside (no interior trim removal). If you have the standard bulb-style tail lamps, you’ll swap the bulb(s) from the back of the housing; if you have factory LED tail lamps, the “bulbs” aren’t serviceable and the whole tail lamp assembly gets replaced.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the lights OFF and remove the key before starting.
• ⚠️ Let bulbs cool before touching; they can burn you.
• ⚠️ Don’t touch new glass bulbs with bare fingers; oils can shorten bulb life.
• ⚠️ Support the tail lamp so it doesn’t fall and scratch the paint.
• 🔋 Battery disconnect is not required for this job.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Torx T30 screwdriver
• Plastic trim removal tool
• Nitrile gloves
• Safety glasses
• Small flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Tail/stop light bulbs (match the bulb number from your old bulbs) - Qty: 2
• Optional: Turn signal bulbs (match the bulb number from your old bulbs) - Qty: 2
• Optional: Reverse light bulbs (match the bulb number from your old bulbs) - Qty: 2
• If equipped with LED tail lamps: Tail lamp assemblies - Qty: 2

---

📋 Before You Begin

• Park on level ground and turn the lights OFF.
• Open the tailgate to access the tail lamp fasteners.
• Set a soft towel near the work area to rest the tail lamp on.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the left tail lamp assembly

• Open the tailgate.
• Use a Torx T30 screwdriver to remove the two tail lamp screws on the inside edge of the lamp (visible with the tailgate open).
• Gently pull the tail lamp straight rearward to release the alignment pins.
• If it feels stuck, use a plastic trim removal tool to gently help it pop loose. Pull straight back, not sideways.

Step 2: Disconnect wiring (so you can work comfortably)

• Support the lamp with one hand.
• Unplug the main connector by pressing the lock tab and pulling the connector apart by hand.

Step 3: Replace the “taillight” bulb(s) (bulb-style lamps only)

• Find the bulb socket(s) on the back of the tail lamp.
• Twist the correct socket counterclockwise by hand and pull it out.
• Pull the old bulb straight out of the socket.
• Install the new bulb by pushing it straight into the socket.
• Reinstall the socket into the lamp and twist clockwise by hand until it locks.
• If unsure, match bulb number on old bulb.

Step 4: If equipped with factory LED tail lamps (no serviceable bulbs)

• If you do not see removable bulb sockets and the lamp has a sealed rear cover, it’s an LED unit.
• Use a Torx T30 screwdriver to remove the two screws, pull the lamp out, and use your hands to unplug the connector.
• Install the new tail lamp assembly, plug in the connector, and set the lamp into place.

Step 5: Reinstall the left tail lamp

• Plug the connector back in until it clicks.
• Align the guide pins and push the lamp straight forward into the body.
• Install the two screws using a Torx T30 screwdriver.
• Torque to 3 Nm (27 in-lbs)

Step 6: Repeat on the right side

• Repeat Steps 1–5 for the right tail lamp using the same Torx T30 screwdriver and method.

---

✅ After Repair

• Turn on the parking lights and confirm both tail lights illuminate evenly.
• Press the brake pedal (have a helper or back up near a wall) and confirm both brake lights work.
• Test turn signals and reverse lights if you replaced those bulbs.
• Make sure both lamps sit flush and don’t wiggle.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$200 (parts + labor)

DIY Cost: $10-$60 (parts only, depends on bulb/LED)

You Save: $70-$140 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
