🔧 3500 - Tail Light Bulb Replacement

On your 3500, the rear bulbs are serviced by removing each tail lamp housing from the bedside, then swapping the bulb(s) in the twist-lock sockets. Left and right sides are the same process.

Before I tailor the parts list: Are you replacing the brake/turn/tail bulbs or the reverse bulbs? And do you have LED tail lamps or regular bulb (incandescent) tail lamps?

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the lights off, remove the key, and let bulbs cool before touching.
• ⚠️ Wear gloves; oils from fingers can shorten bulb life.
• ⚠️ Do not force the lamp housing—there are alignment pins that pull straight out.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Torx T25 driver
• Plastic trim tool
• Needle-nose pliers
• Nitrile gloves
• Safety glasses
• Flashlight

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear tail lamp bulb(s) (correct type for your lamp) - Qty: 2
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground and set the parking brake.
• Open the tailgate for access to the tail lamp screws.
• Lay a towel on the bumper corner to protect paint as you handle the lamp.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Access the tail lamp screws

• Open the tailgate by hand.
• Stand at the rear corner you’re working on (left or right).

Step 2: Remove the tail lamp housing

• Use a Torx T25 driver to remove the two screws on the inboard edge of the tail lamp (the side facing the tailgate opening).
• Grip the tail lamp with both hands and pull it straight rearward to release the alignment pins.
• If it’s stuck, use a plastic trim tool to gently help start it—do not pry hard on the painted bedside.
• Pull straight back, not outward.

Step 3: Disconnect and remove the bulb socket(s)

• Support the lamp so it doesn’t hang by the wiring.
• Twist the correct bulb socket counterclockwise by hand and pull it out of the housing.
• If the socket is tight, use needle-nose pliers carefully on the socket tabs (don’t crush the plastic).

Step 4: Replace the bulb

• Pull the old bulb straight out of the socket by hand (wear nitrile gloves).
• Install the new bulb fully into the socket (it should seat firmly and evenly).
• Apply a very light smear of dielectric grease to the socket seal if it looks dry.
• If you’re replacing “both taillight bulbs,” repeat on the other side before reassembly.

Step 5: Reinstall the socket(s) and tail lamp housing

• Insert the socket back into the housing and twist clockwise until it locks.
• Reconnect any electrical connector you unplugged (it should click).
• Line up the alignment pins and push the tail lamp straight forward until fully seated.
• Use a Torx T25 driver to reinstall the two screws and snug them evenly (do not overtighten).

---

✅ After Repair

• Turn on the parking lights and verify both tail lamps illuminate evenly.
• Test brake lights with a helper (or back up near a wall to see the reflection).
• Test turn signals and hazards.
• If you replaced reverse bulbs, verify in Reverse with the brake held and a helper watching behind the truck.

---

💰 DIY vs Shop Cost

Shop Cost: $80-$180 (parts + labor)

DIY Cost: $10-$60 (parts only)

You Save: $70-$120 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
