🔧 Charger - Headlight Bulb Replacement (Both Sides)

On your Charger, the headlight bulbs are accessed from behind the headlamp through the front wheel-well liner (inner fender). You’ll replace the bulb(s) on the left and right sides the same way, then verify aim and operation.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• ⚠️ If equipped with HID bulbs, they run high voltage—turn lights off, remove key, and disconnect the battery before unplugging anything.
• ⚠️ Support the car with jack stands before working near/behind a wheel.
• ⚠️ Do not touch the glass on halogen/HID bulbs; skin oil can shorten bulb life.
• ⚠️ Let the headlamp area cool if lights were recently on.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• 21mm socket
• 3/8" drive ratchet
• 6" socket extension
• 8mm socket
• Trim clip removal tool
• Flashlight
• Nitrile gloves
• Safety glasses
• Torque wrench (10-150 ft-lbs)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Low beam headlight bulb - Replace in pairs - Qty: 2
• High beam headlight bulb - Replace in pairs - Qty: 2

---

📋 Before You Begin

• Park on level ground, set the parking brake, and chock the rear wheels.
• Turn the steering wheel toward the side you’re working on (gives more room in the wheel well).
• If your Charger has HID headlights, disconnect the battery negative cable before starting.
• Tip: Replace bulbs in pairs for matching color.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Identify which bulb type you have

• Open the hood and look at the back of the headlamp area.
• If you see a large igniter/ballast-style connector and “HID” labeling, follow the HID path below. Otherwise, follow the Halogen path.
• Tip: Match the bulb you remove to the new one.

Step 2: Raise the front corner (recommended for space)

• Place wheel chocks behind the rear tires.
• Use a floor jack (rated 3-ton minimum) to lift one front corner.
• Set the car onto jack stands (rated 3-ton minimum) before reaching into the wheel well.

Step 3: Remove enough of the inner fender liner to access the headlamp

• Use an 8mm socket with a 3/8" drive ratchet and 6" socket extension to remove the small bolts along the front section of the liner.
• Use a trim clip removal tool to pop out any plastic push-clips. (A trim clip tool is a small forked tool that lifts plastic clips without breaking them.)
• Pull the liner back just enough to reach the rear of the headlamp.
• Tip: A flashlight makes this much easier.

Step 4 (Halogen path): Remove the bulb

• Put on nitrile gloves.
• Reach to the back of the headlamp and locate the bulb socket/connector.
• Twist the bulb counterclockwise to unlock it, then pull it straight out.
• Disconnect the electrical connector from the bulb (press the tab and pull).

Step 5 (Halogen path): Install the new bulb

• Connect the wiring connector to the new bulb until it clicks.
• Insert the bulb into the headlamp and twist clockwise to lock it.
• Make sure the bulb sits fully flush; a crooked bulb will aim poorly.

Step 6 (HID path): Power down and remove the HID bulb

• Disconnect the battery negative terminal using an 8mm socket.
• At the rear of the headlamp, carefully disconnect the HID electrical connector.
• Twist the HID bulb/retainer counterclockwise to unlock, then pull the bulb straight out.
• Tip: Do not force the connector—recheck the lock tab.

Step 7 (HID path): Install the new HID bulb

• With nitrile gloves on, insert the new HID bulb without touching the glass.
• Twist clockwise to lock the bulb in place.
• Reconnect the HID connector securely.
• Reconnect the battery negative terminal using an 8mm socket.

Step 8: Reinstall the inner fender liner

• Reposition the liner.
• Reinstall bolts using an 8mm socket and clips using a trim clip removal tool (press clips back in by hand after aligning).

Step 9: Repeat on the other side

• Turn the steering wheel the opposite direction and repeat Steps 2–8 for the other headlight.

Step 10: If you removed a wheel (optional method), torque lug nuts

• Install the wheel and hand-start lug nuts.
• Lower the car and torque lug nuts using a torque wrench (10-150 ft-lbs): Torque to 176 Nm (130 ft-lbs).

---

✅ After Repair

• Turn headlights on and verify low beam and high beam work on both sides.
• Check that the bulb is not flickering and that the connector is fully seated.
• At night, confirm both beams aim evenly; mis-aim usually means the bulb isn’t fully seated/locked.
• Tip: Keep old working bulb as an emergency spare.

---

💰 DIY vs Shop Cost

Shop Cost: $150-$400 (parts + labor)

DIY Cost: $30-$250 (parts only, depends on halogen vs HID)

You Save: $120-$250 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
