🔧 Versa - Headlight Bulb Replacement

You’ll replace the bulbs from behind each headlight housing under the hood. Most of the job is creating enough hand room, twisting the bulb socket out, and installing the new bulb without touching the glass.

Assumption: “Both headlight bulbs” = left and right low-beam bulbs. If you meant high-beams too, I’ve included those bulb types in the Parts section.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the lights off and let the bulbs cool for 10+ minutes (they get extremely hot).
• ⚠️ Wear gloves and do not touch the new bulb glass with bare fingers (skin oil can shorten bulb life).
• ⚠️ Do not force the bulb—plastic tabs can break in cold weather; warm the car up if it’s very cold.
• 🔋 Battery disconnect is not required, but keep the headlight switch OFF while working.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Nitrile gloves
• Safety glasses
• Flashlight
• 10mm socket
• 1/4" ratchet
• 6" socket extension
• Trim clip removal tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Low-beam headlight bulb (H11) - Replace in pairs - Qty: 2
• High-beam headlight bulb (9005) - Replace in pairs - Qty: 2

---

📋 Before You Begin

• 🅿️ Park on level ground, shift to Park, and set the parking brake.
• 💡 Turn the headlight switch OFF and remove the key/fob from the car.
• 🔦 Open the hood and use a flashlight so you can see the bulb base and locking tabs.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Confirm which bulb you’re replacing (low vs high)

• Use a flashlight to look behind the headlight housing and locate the bulb socket you’re changing.
• Low-beam (H11) is typically the main “night driving” lamp; high-beam (9005) is the brighter “brights” lamp.

Step 2: Create working room (passenger side is usually tighter)

• If access is tight, remove the air intake snorkel/duct clips using a trim clip removal tool.
• Remove any 10mm fasteners holding the intake duct/air box resonator (if equipped) using a 10mm socket, 1/4" ratchet, and 6" socket extension.
• Move the ducting aside just enough to get your hand to the rear of the headlight. Don’t yank—plastic tabs snap.

Step 3: Remove the electrical connector

• Put on nitrile gloves.
• Press the connector lock tab and pull the connector straight off the bulb.
• If it’s stubborn, wiggle gently while holding the connector (not the wires). Small wiggles beat big pulls.

Step 4: Remove the old bulb

• Grip the bulb base (plastic), then rotate it counterclockwise about 1/8 to 1/4 turn to unlock.
• Pull the bulb straight out of the headlight housing.

Step 5: Install the new bulb (no touching glass)

• Hold the new bulb by the plastic base with your nitrile gloves.
• Align the bulb tabs with the slots in the housing, insert fully, then rotate clockwise to lock.
• If you accidentally touch the glass, clean it with rubbing alcohol and let it dry fully before installing.

Step 6: Reconnect and verify the lock

• Push the electrical connector on until it clicks.
• Gently tug the connector to confirm it’s fully seated.

Step 7: Repeat on the other headlight

• Repeat Steps 2–6 on the other side.
• Replace bulbs in pairs (left and right) so brightness/color matches.

Step 8: Reinstall any intake ducting you moved

• Reposition the intake pieces and reinstall fasteners using a 10mm socket, 1/4" ratchet, and 6" socket extension.
• Reinstall any clips using a trim clip removal tool (to line them up) and press them in by hand.

---

✅ After Repair

• 💡 Turn the headlights ON and check: low-beams, high-beams, and that both sides match in brightness.
• 👀 Verify the bulb is not flickering (often caused by a loose connector).
• 📏 At night, confirm the beam pattern looks even; if it looks wildly off, the bulb may not be fully locked in.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$250 (parts + labor)

DIY Cost: $30-$120 (parts only, depending on bulb type)

You Save: $90-$130 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
