🔧 Renegade - Headlight Bulb Replacement

You’ll replace the left and right headlight bulbs by accessing the back of each headlamp housing (usually through the front wheel-well liner). This restores proper night visibility and keeps you legal/safe on the road.

Difficulty Level: Beginner | Estimated Time: 0.8-1.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Turn the lights OFF and let bulbs cool 10+ minutes; they get extremely hot.
• ⚠️ Wear gloves and do not touch halogen bulb glass with bare fingers (skin oils can shorten bulb life).
• ⚠️ If equipped with HID/LED headlamps, do not power the system with the bulb/module unplugged; high voltage may be present on HID systems.
• ⚠️ If you lift the vehicle, support it with jack stands on solid points—never rely on a floor jack alone.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Nitrile gloves
• Wheel chocks
• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• 17mm socket
• 3/8" drive ratchet
• 3" extension (3/8" drive)
• 7mm socket
• Trim clip remover (panel tool)
• Flashlight
• Torque wrench (10-150 ft-lbs range)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Low beam headlight bulb (pair) - Qty: 1
• Wheel liner push clips - Qty: 2

---

📋 Before You Begin

• Park on level ground, set the parking brake, and turn the steering wheel to give access to the wheel well you’re working on.
• If you’re lifting the vehicle, place wheel chocks behind the rear wheels before jacking.
• Tip: Replace bulbs in pairs for even color.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Make space to reach the headlamp (one side at a time)

• Turn the steering wheel fully away from the side you’re working on (this opens up the wheel-well access area).
• If your hands don’t fit comfortably, lift that corner of the vehicle using a floor jack (rated 2-ton minimum) and support it with jack stands (rated 2-ton minimum).
• If you remove the wheel for extra room: loosen lug nuts with a 17mm socket and 3/8" drive ratchet, remove the wheel, then reinstall later and Torque to 135 Nm (100 ft-lbs) using a torque wrench (10-150 ft-lbs range).

Step 2: Open the wheel-well liner access to the bulb

• Use a flashlight to locate the small access area on the front portion of the wheel-well liner (closest to the headlight).
• Remove the fasteners with a 7mm socket, 3/8" drive ratchet, and 3" extension (3/8" drive).
• Remove any plastic push-clips using a trim clip remover (panel tool). (A panel tool is a forked pry tool made to pop clips out without breaking them.)
• Pull the liner back just enough to reach the rear of the headlamp housing.

Step 3: Remove the old bulb

• Find the bulb socket at the back of the headlight housing using a flashlight.
• Disconnect the electrical connector by pressing the lock tab and pulling straight back (use nitrile gloves for grip).
• Rotate the bulb/socket counterclockwise by hand and pull it straight out.

Step 4: Install the new bulb (don’t touch the glass)

• Put on nitrile gloves before handling the new bulb.
• Insert the new bulb into the housing (match the tabs), then rotate clockwise until it locks fully.
• Reconnect the electrical connector until it clicks into place.
• Tip: If touched, wipe glass with alcohol.

Step 5: Quick function check

• Turn the headlights ON and verify the new bulb works (use a flashlight only if needed—don’t stare into the beam).
• Turn the headlights OFF again before reassembly.

Step 6: Reassemble the wheel-well liner and (if removed) the wheel

• Reposition the liner and reinstall screws using a 7mm socket, 3/8" drive ratchet, and 3" extension (3/8" drive).
• Reinstall push-clips using a trim clip remover (panel tool) to seat them squarely.
• If the wheel was removed, reinstall it and Torque to 135 Nm (100 ft-lbs) using a torque wrench (10-150 ft-lbs range).

Step 7: Repeat on the other side

• Repeat Steps 1-6 for the other headlight bulb.

---

✅ After Repair

• Verify both low beams work, and check high beams/parking lights to ensure nothing else was disturbed.
• Take a short night drive and confirm the light pattern looks even left-to-right.
• If a bulb doesn’t light: re-check the connector is fully clicked and the bulb is fully locked in the housing.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$280 (parts + labor)

DIY Cost: $30-$120 (parts only)

You Save: $90-$160 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.8-1.2 hours.

---

🎯 Ready to get started?

HowToo makes it easy: same-day/2-day shipping on every part, plus all the tools and specialty tools you need! Check out the parts and tools sections below to add everything to your cart.

Assumption: This covers the common halogen-bulb setup; if your Renegade has factory HID/LED headlamps, the access is similar but the bulb/module type differs—use the same access steps, and install the correct matched part.
