🔧 Durango - Headlight Bulb Replacement

You’ll replace the left and right headlight bulbs by accessing the rear of each headlamp housing from inside the engine bay. This is a common wear item, and new bulbs restore safe nighttime visibility.

Difficulty Level: Beginner | Estimated Time: 0.5-1.0 hours

Assumption: Your Durango has halogen headlights (most SXT models). Typical low-beam bulb is H11. If your headlights are factory HID/LED, the steps/parts differ.

---

⚠️ Safety & Precautions

• ⚠️ Turn headlights OFF and let bulbs cool 10+ minutes (they get very hot).
• ⚠️ Do not touch the new bulb glass with bare fingers (skin oil can shorten bulb life).
• ⚠️ Keep the bulb sealing area clean and dry to prevent condensation inside the headlamp.
• ⚠️ Battery disconnect is not required, but keep the headlight switch OFF while working.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Nitrile gloves
• Safety glasses
• Flashlight
• 8mm socket
• 10mm socket
• 1/4" drive ratchet
• 6" 1/4" drive extension
• Trim clip removal tool

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Low beam headlight bulb (H11) - Qty: 2
• Dielectric grease - Qty: 1

---

📋 Before You Begin

• Park on level ground, shift to Park, and set the parking brake.
• Open the hood and use a flashlight to locate the back of each headlamp housing.
• Put on nitrile gloves and safety glasses.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Create access on the passenger side (if tight)

• Use an 8mm socket with a 1/4" drive ratchet to loosen the intake hose clamp near the air box.
• If there are air box fasteners/bolts, remove them with a 10mm socket and 6" extension.
• Move the intake tube/air box cover slightly for hand room (no need to fully remove it on most setups).
• Tip: Move parts gently; don’t force plastic.

Step 2: Remove the low-beam bulb dust cover (rear cap)

• Behind the headlamp, find the round rear cover over the low-beam bulb.
• Twist the cover counterclockwise by hand and pull it off (set it somewhere clean).

Step 3: Unplug the bulb connector

• Press the locking tab on the electrical connector and pull it straight off the bulb.
• If the tab is stubborn, use a trim clip removal tool to gently help lift the tab while pulling.

Step 4: Remove the old bulb

• Grab the bulb base (not the glass).
• Twist the bulb counterclockwise about a quarter-turn, then pull it straight out.

Step 5: Install the new bulb (H11)

• With nitrile gloves on, insert the new bulb into the housing, aligning the tabs.
• Twist clockwise until it locks in place (it should sit flat and secure).
• Apply a tiny amount of dielectric grease to the connector seal area (a light smear only), then reconnect the plug until it clicks.

Step 6: Reinstall the dust cover

• Reinstall the rear cover and twist clockwise until fully seated.
• This seal is important to keep moisture out of the headlamp.

Step 7: Repeat on the driver side

• Repeat Steps 2 through 6 on the other headlamp.
• If the washer filler neck blocks your hand, carefully unclip/move it using a trim clip removal tool (do not crack the plastic).

Step 8: Reinstall any intake/air box parts you moved

• Reposition the intake tube/air box parts.
• Tighten the clamp using an 8mm socket until snug (do not overtighten).
• If you removed air box bolts, reinstall them using a 10mm socket and ratchet, Torque to 10 Nm (89 in-lbs).

---

✅ After Repair

• Turn the headlights ON and verify both low beams work.
• Check that both dust covers are fully seated (prevents fogging).
• At night, confirm the beams look even. If one looks “off,” the bulb may not be fully locked in.

---

💰 DIY vs Shop Cost

Shop Cost: $120-$250 (parts + labor)

DIY Cost: $30-$80 (parts only)

You Save: $90-$170 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 0.5-1.0 hours.

---
