Assumption: your Fusion has the standard rear door power window (cable regulator). Torque values below are common Ford specs—verify with OEM data if available.

🔧 Fusion - Rear Window Regulator Replacement

The rear window regulator is the cable-and-track assembly that raises and lowers the glass. When it fails, the window may fall into the door, move crooked, or stop moving. This job involves removing the rear door panel, separating the glass from the regulator, then swapping the regulator assembly.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours (one door)

---

⚠️ Safety & Precautions

• ⚠️ Disconnect the negative battery cable before door work to reduce accidental airbag deployment risk.
• ⚠️ Support the window glass at all times; unsecured glass can drop and shatter.
• ⚠️ Wear gloves and safety glasses; inner door metal edges are sharp.
• ⚠️ Do not tear the vapor barrier; it keeps water off the electronics and carpet.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Safety glasses
• Mechanic gloves
• Trim removal tool set
• Pick tool
• Phillips screwdriver
• Torx T20 screwdriver
• Torx T25 screwdriver
• 7mm socket
• 8mm socket
• 10mm socket
• 1/4" drive ratchet
• 3" extension
• Torque wrench (20–200 in-lb range)
• Painters tape (2" wide)
• Plastic razor blade scraper
• Shop towels
• Work light

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Rear window regulator assembly - Qty: 1
• Rear door trim panel clips - Qty: 1 set
• Vapor barrier butyl seal tape - Qty: 1
• Medium-strength threadlocker - Qty: 1

---

📋 Before You Begin

• Park on level ground and open the rear door fully.
• Turn the ignition OFF and remove the key/fob from the vehicle.
• Use a 10mm socket to disconnect the negative battery terminal; wait at least 5 minutes before unplugging door wiring.
• Have painters tape ready to hold the glass up when the regulator is disconnected.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the rear door trim panel

• Use a trim removal tool set to gently pry up the window switch panel.
• Unplug the switch connector(s) by releasing the tab with a pick tool. Connector tab = small locking clip.
• Remove any visible screws behind trim covers using a Torx T20 screwdriver or 7mm socket (varies by door).
• Use a trim removal tool set to pop the door panel clips free around the edges.
• Lift the door panel upward to unhook it from the window ledge.
• If equipped, disconnect the courtesy light connector using a pick tool.

Step 2: Remove the vapor barrier (water shield)

• Use a plastic razor blade scraper to carefully separate the vapor barrier from the butyl adhesive.
• Peel it back slowly and stick it out of the way without tearing it.
• Use shop towels to keep adhesive off your hands and door panel.

Step 3: Position the glass to access the clamp/attachment points

• Reconnect the window switch temporarily (use the same connector) and reconnect the battery negative with a 10mm socket.
• Turn ignition ON and use the window switch to move the glass until you can see the glass-to-regulator fasteners through the access holes.
• Turn ignition OFF and disconnect the battery negative again using a 10mm socket.

Step 4: Secure the glass in the full-up position

• Use painters tape (2" wide) to tape the glass to the door frame from the outside.
• Add at least 2–3 long strips; the goal is to prevent the glass from dropping.

Step 5: Detach the glass from the regulator

• Through the access opening, loosen/remove the glass clamp bolts using an 8mm socket or 10mm socket (varies by regulator design).
• Once loose, gently lift the glass by hand to confirm it’s free from the regulator, then re-tape it securely.
• If the glass binds, stop and re-check bolt location.

Step 6: Disconnect the window motor electrical connector

• Unplug the motor connector by releasing the lock with a pick tool.
• Move the harness out of the regulator path.

Step 7: Remove the regulator/motor assembly

• Remove the regulator mounting bolts using a 10mm socket and 1/4" drive ratchet.
• If the motor is separate, remove motor fasteners using a Torx T25 screwdriver.
• Carefully snake the regulator out through the largest access opening. Use a work light to avoid snagging cables.

Step 8: Install the new regulator

• Guide the new regulator into the door the same way the old one came out.
• Start all mounting bolts by hand to prevent cross-threading, then tighten using a 10mm socket.
• Apply a small amount of medium-strength threadlocker to the regulator bolts if desired.
• Torque to 10 Nm (89 in-lb) for regulator-to-door bolts.
• Reconnect the motor electrical connector until it clicks.

Step 9: Reattach the glass to the regulator

• Remove some tape so the glass can lower slightly, but keep at least one strip supporting it.
• Lower the glass carefully into the regulator clamp/attachment points by hand.
• Install/tighten the glass clamp bolts using an 8mm socket or 10mm socket.
• Torque to 8 Nm (71 in-lb) for glass clamp bolts.

Step 10: Function test before reassembly

• Reconnect the battery negative using a 10mm socket.
• Plug in the window switch and turn ignition ON.
• Run the window down and up while watching for smooth travel and straight alignment.
• If it tilts or clicks, turn ignition OFF and re-check glass seating in the clamps.
• Turn ignition OFF and disconnect the battery negative using a 10mm socket before reinstalling the vapor barrier/trim.

Step 11: Reinstall the vapor barrier

• Press the vapor barrier back into place.
• If the butyl no longer sticks, add vapor barrier butyl seal tape to reseal the edges.
• A good seal prevents wet carpets.

Step 12: Reinstall the door trim panel

• Reconnect all connectors (switch, courtesy light) by pushing them in until they click.
• Hook the top of the panel onto the window ledge, then press the panel in to seat the clips.
• Reinstall screws using a Torx T20 screwdriver or 7mm socket.
• Torque to 2 Nm (18 in-lb) for interior trim screws (snug, do not strip).
• Snap any trim covers back on using the trim removal tool set.

---

✅ After Repair

• Reconnect the negative battery cable using a 10mm socket.
• Window relearn (if needed): turn ignition ON, hold the switch to fully DOWN for 2 seconds, then fully UP for 2 seconds.
• Confirm the door locks, speaker, and window switch all work.
• Check for wind noise or water leak signs after the next car wash/rain; reseal the vapor barrier if needed.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$800 (parts + labor)

DIY Cost: $120-$250 (parts only)

You Save: $330-$550 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-3 hours.

---
