🔧 Challenger - Tie Rod End Replacement

Replacing the tie rod end restores proper steering control and helps prevent uneven tire wear. After replacement, the front toe setting can change, so a professional alignment is strongly recommended.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

---

⚠️ Safety & Precautions

• 🛑 Support the car with jack stands; never rely on a jack alone.
• 🛑 Chock the rear wheels and leave the car in 1st gear before lifting the front.
• 🛑 Do not hammer directly on the steering knuckle; you can damage components.
• 🛑 Plan for an alignment after the repair to prevent tire wear.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Mechanic gloves
• Lug nut socket (size to match your lug nuts)
• Breaker bar (1/2-inch drive)
• Torque wrench (1/2-inch drive)
• Torque wrench (3/8-inch drive)
• Ratchet (3/8-inch drive)
• Socket set (metric)
• Open-end wrench set (metric)
• Needle-nose pliers
• Ball joint separator tool (specialty)
• Penetrating oil
• Paint marker
• Tape measure

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Front outer tie rod end - Qty: 1
• Cotter pin - Qty: 1
• Thread locker (medium strength) - Qty: 1
• Anti-seize compound - Qty: 1

---

📋 Before You Begin

• Park on level ground, straighten the steering wheel, and set the parking brake.
• Loosen the front wheel lug nuts slightly before lifting the car (use a breaker bar and lug nut socket).
• Lift the front and place the car securely on jack stands at the proper lift points.
• Spray penetrating oil on the tie rod end jam nut and the tie rod stud nut.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Quick check (I need 2 details before torque specs)

• Reply with: Front Left or Front Right.
• Reply with: Outer tie rod end (at the wheel) or Inner tie rod (under the boot).

Step 2: Remove the wheel

• Remove the lug nuts using a lug nut socket and breaker bar, then remove the wheel.

Step 3: Mark the current tie rod setting

• Use a paint marker to mark the position of the jam nut against the tie rod (helps keep toe close).
• Use a tape measure to measure from a fixed point on the tie rod end to the jam nut and write it down.

Step 4: Loosen the jam nut

• Hold the tie rod with an open-end wrench (metric) and loosen the jam nut with a second open-end wrench (metric).
• Only crack it loose for now; don’t spin it far yet.

Step 5: Remove the cotter pin (if equipped)

• Straighten and remove the cotter pin using needle-nose pliers.

Step 6: Remove the tie rod stud nut

• Remove the nut from the tie rod end stud using a ratchet (3/8-inch drive) and socket set (metric).
• If it spins, use an open-end wrench to hold.
• Torque spec required here (I’ll provide the exact spec after you answer Step 1).

Step 7: Separate the tie rod end from the steering knuckle

• Use a ball joint separator tool (specialty) to pop the tapered stud free. (This tool presses the joint apart without beating on parts.)
• Go slow; steady pressure works best.

Step 8: Remove the tie rod end from the tie rod

• Spin the tie rod end off by hand, counting turns (example: 17 turns). Write the number down.
• This helps get the alignment close enough to drive to the shop.

Step 9: Install the new tie rod end

• Apply a light coat of anti-seize compound to the threads.
• Thread the new tie rod end on the exact same number of turns you counted using your hands.
• Position the stud into the steering knuckle.

Step 10: Tighten fasteners (final torque)

• Tighten the tie rod stud nut using a torque wrench (3/8-inch drive) and socket set (metric).
• Install a new cotter pin using needle-nose pliers if the nut uses a castle nut design.
• Tighten the jam nut using an open-end wrench (metric).
• Torque to XX Nm (YY ft-lbs) (I’ll fill in the exact Challenger spec after Step 1 answers).

Step 11: Reinstall the wheel

• Install the wheel and hand-tighten lug nuts.
• Lower the car and torque the lug nuts using a torque wrench (1/2-inch drive).
• Torque to XX Nm (YY ft-lbs) (I’ll provide the exact lug nut spec after Step 1 answers).

---

✅ After Repair

• Start the car and turn the steering wheel lock-to-lock to confirm nothing binds or clunks.
• Do a short, slow test drive and confirm the steering wheel is close to centered.
• Get a front-wheel alignment as soon as possible.
• Recheck for any looseness by gently rocking the tire at 3 and 9 o’clock with the car safely lifted.

---

💰 DIY vs Shop Cost

Shop Cost: $200-$450 (parts + labor + basic alignment)

DIY Cost: $40-$120 (parts only)

You Save: $160-$330 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
