🔧 Durango - Transmission Fluid & Filter (Pan) Service

On your Durango, the transmission fluid level is set through a fill plug and must be checked at a specific fluid temperature while the engine is running. The “filter” is built into the transmission pan on most setups, so a proper service usually means replacing the pan/filter assembly and refilling with the correct ATF.

Difficulty Level: Advanced | Estimated Time: 2-4 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the SUV level on 4 jack stands; an unlevel vehicle causes wrong fluid level.
• ⚠️ Transmission fluid can be hot; wear gloves and safety glasses.
• ⚠️ You’ll run the engine while underneath; keep clear of belts/fans/exhaust.
• ⚠️ Use wheel chocks and keep the shifter in Park with the brake applied.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum) - Qty: 4
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 10-quart)
• 3/8" drive ratchet
• Torque wrench (inch-pound and foot-pound capable)
• Socket set (metric)
• Torx bit set (metric)
• Hex bit socket set (metric)
• Trim clip remover
• Plastic scraper
• Brake cleaner
• Shop towels
• Fluid transfer pump
• OBD-II scan tool that shows transmission fluid temperature (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (8-speed approved ATF) - Qty: 7-9 quarts
• Transmission pan with integrated filter - Qty: 1
• Transmission pan bolt set - Qty: 1
• Fill plug seal (if applicable) - Qty: 1
• Drain plug seal (if applicable) - Qty: 1

---

📋 Before You Begin

• Park on a level surface and let the exhaust cool down.
• Gather an OBD-II scan tool that shows transmission fluid temperature (this is the temperature reading used to set the correct fluid level).
• Plan to lift the SUV and keep it level (front and rear at similar height).
• Tip: Remove the fill plug first. If it’s stuck, don’t drain it yet.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Warm the transmission slightly

• Drive 5–10 minutes so the fluid isn’t ice-cold.
• Plug in your OBD-II scan tool that shows transmission fluid temperature (specialty) and confirm you can view “Transmission Fluid Temperature” (TFT).

Step 2: Raise and level the SUV

• Chock the rear wheels using wheel chocks.
• Lift using a floor jack (rated 3-ton minimum) and support with jack stands (rated 3-ton minimum).
• Make sure it sits level (important for correct fill level).

Step 3: Remove the underbody shield (if equipped)

• Use a trim clip remover and socket set (metric) to remove fasteners.
• Set the shield and fasteners aside in order.

Step 4: Locate the fill and drain points

• Place a drain pan (at least 10-quart) underneath the transmission pan.
• Use a hex bit socket set (metric) and/or Torx bit set (metric) to identify the correct tool for the fill plug and drain plug.
• Crack the fill plug loose first (do not fully remove yet).

Step 5: Drain the old fluid

• Use the correct hex bit socket set (metric) or Torx bit set (metric) to remove the drain plug.
• Let it drain completely into the drain pan (at least 10-quart).
• Clean the drain plug and set it aside.

Step 6: Remove and replace the transmission pan (filter)

• Use a 3/8" drive ratchet with the appropriate socket set (metric) or Torx bit set (metric) to remove the pan bolts.
• Support the pan as you remove the last bolts; more fluid will spill.
• Remove the pan and wipe down the transmission mounting surface using shop towels.
• If any stuck gasket material is present, remove it carefully with a plastic scraper (do not gouge metal).
• Clean the area with brake cleaner and shop towels.
• Install the new pan/filter and hand-start all bolts.
• Tighten bolts evenly in a crisscross pattern using a torque wrench: Torque to 8 Nm (71 in-lbs).

Step 7: Reinstall the drain plug

• Install a new seal if your parts kit includes one.
• Use the proper hex bit socket set (metric) or Torx bit set (metric) and a torque wrench: Torque to 20 Nm (15 ft-lbs).

Step 8: Initial fill (engine OFF)

• Remove the fill plug using the correct hex bit socket set (metric) or Torx bit set (metric).
• Use a fluid transfer pump to pump approved ATF into the fill hole until it starts to run back out.
• Install the fill plug finger-tight for now (so it doesn’t drip heavily).

Step 9: Set the fluid level (engine RUNNING at target temperature)

• Start the engine and keep your foot on the brake.
• With the engine idling, slowly move the shifter through all gears (P-R-N-D and back), pausing 2–3 seconds in each.
• Monitor TFT on your OBD-II scan tool that shows transmission fluid temperature (specialty).
• When TFT is in the typical level-setting window of 30–50°C (86–122°F), remove the fill plug using the correct hex bit socket set (metric) or Torx bit set (metric).
• Use the fluid transfer pump to add ATF until it just begins to dribble out in a steady thin stream.
• Let it drip until it becomes a slow drip, then install the fill plug.
• Use a torque wrench: Torque to 35 Nm (26 ft-lbs).
• Tip: Too hot = wrong fluid level.

Step 10: Reinstall the underbody shield

• Use a socket set (metric) and trim clip remover to reinstall the shield and clips.

Step 11: Lower the SUV and clean up

• Lower it safely using the floor jack (rated 3-ton minimum).
• Clean any spilled ATF with brake cleaner and shop towels.

---

✅ After Repair

• Start the engine and check underneath for leaks with the SUV on the ground.
• Road test 10–15 minutes, then recheck for leaks around the pan, drain plug, and fill plug.
• If shifts feel abnormal, re-check the fluid level procedure (temperature and level stance are the usual cause).
• Dispose of used ATF properly (most parts stores accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $450-$900 (parts + labor)

DIY Cost: $220-$450 (parts only)

You Save: $230-$450 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 2-4 hours.

---
