🔧 Santa Fe XL - Transmission Fluid Drain & Level Set

On your Santa Fe XL, the most DIY-friendly way to service the automatic transmission fluid is a drain-and-fill, then setting the fluid level at the correct temperature. This helps restore shift quality and protects the transmission, without needing a flush machine.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on level ground and support the vehicle with jack stands; never rely on a jack alone.
• ⚠️ Transmission fluid can be very hot; wear gloves and safety glasses.
• ⚠️ Keep the engine running only when required for the level check; stay clear of moving parts.
• ⚠️ Do not overfill; incorrect level can cause slipping, foaming, or harsh shifts.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 10-quart)
• Funnel with long hose
• Plastic trim clip removal tool
• Ratchet
• Socket set (8mm-19mm)
• 10mm socket
• 12mm socket
• 24mm socket
• Torque wrench (10-100 ft-lbs)
• Hex bit socket set (5mm-10mm)
• OBD2 scan tool with transmission fluid temperature data (specialty)
• Shop rags
• Brake cleaner spray

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Hyundai-spec automatic transmission fluid (ATF SP-IV) - Qty: 5-7 quarts
• Transmission drain plug crush washer - Qty: 1
• Transmission fill plug sealing washer - Qty: 1

---

📋 Before You Begin

• Park on a flat, level surface, apply the parking brake, and chock the rear wheels.
• Plan to set the fluid level at temperature; you’ll need a scan tool that can read Transmission Fluid Temperature (TFT) (that’s the fluid temp sensor reading inside the transmission).
• Gather enough ATF: a drain-and-fill is commonly around 4-5 quarts, but have extra on hand for proper level setting.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and level the vehicle

• Use a floor jack (rated 3-ton minimum) to lift the front, then support with jack stands (rated 3-ton minimum).
• If needed, lift the rear and support it too so the vehicle sits level (important for correct fluid level).
• Place wheel chocks at the rear wheels.

Step 2: Remove the lower splash shield (if equipped)

• Use a 10mm socket and ratchet to remove the bolts.
• Use a plastic trim clip removal tool to pop any plastic clips.
• Set the shield and hardware aside in a small pile so nothing gets lost.

Step 3: Identify the fill plug before draining

• Locate the transmission fill plug on the transmission case (this is where new fluid goes in).
• Use the correct hex bit socket or socket (varies by plug style) and break it loose first.
• Tip: If you can’t open the fill plug, don’t drain yet.

Step 4: Drain the old transmission fluid

• Position a drain pan under the transmission drain plug.
• Use a 24mm socket and ratchet to remove the drain plug.
• Let it drain until it becomes a slow drip.
• Clean the drain plug area with shop rags and a light spray of brake cleaner.

Step 5: Reinstall the drain plug with a new washer

• Install a new drain plug crush washer on the drain plug.
• Thread the plug in by hand first (prevents cross-threading).
• Use a torque wrench (10-100 ft-lbs) and 24mm socket: Torque to 36 ft-lbs (49 Nm).

Step 6: Add new ATF (initial fill)

• Insert a funnel with long hose into the fill opening.
• Pour in about the same amount you drained (measure the drain pan if it has markings).
• Use only ATF SP-IV for your Santa Fe XL.

Step 7: Warm up fluid and circulate through all gears

• Connect the OBD2 scan tool with transmission fluid temperature data (specialty) and view TFT.
• Start the engine and keep your foot on the brake.
• Slowly move the shifter through P-R-N-D and back, pausing 2-3 seconds in each position.
• Let the transmission warm until TFT is approximately 122°F-140°F (50°C-60°C).

Step 8: Set the transmission fluid level (overflow/level plug method)

• With the engine running and the vehicle level, locate the transmission level/check plug.
• Use the correct hex bit socket and carefully remove the check plug.
• If fluid barely drips out, add ATF through the fill hole using the funnel with long hose until it becomes a thin stream, then allow it to slow to a steady drip.
• If fluid pours out heavily, wait until it slows to a drip (this indicates correct level at the specified temperature).
• Reinstall the level/check plug and use a torque wrench: Torque to 15 ft-lbs (20 Nm).

Step 9: Reinstall the fill plug and splash shield

• Install a new fill plug sealing washer (if used on your plug design).
• Reinstall the fill plug and use a torque wrench: Torque to 24 ft-lbs (33 Nm).
• Reinstall the splash shield using the 10mm socket and plastic trim clip removal tool.

---

✅ After Repair

• With the engine running, check underneath for any seepage at the drain plug, check plug, and fill plug.
• Take a 10-15 minute road test and confirm smooth shifting.
• Recheck for leaks once parked.
• Tip: Keep your drained fluid for recycling.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$120 (parts only)

You Save: $130-$390 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
