🔧 4Runner - Transmission Fluid Drain & Refill (Sealed “No Dipstick”)

Your 4Runner’s automatic transmission uses a sealed fluid level setting method (no dipstick). The job is a drain-and-refill, then setting the fluid level at a specific transmission fluid temperature using an overflow plug.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Support the 4Runner on four jack stands so it stays level (front-to-back and side-to-side) when setting the fluid level.
• ⚠️ Transmission fluid can be hot—wear gloves and safety glasses.
• ⚠️ Keep the engine running only in a well-ventilated area during the level-setting step.
• ⚠️ Do not use “universal ATF.” This transmission requires Toyota WS spec fluid.
• 🔋 Battery disconnect is not required.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum) x4
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• 12mm socket
• 14mm socket
• 3/8" drive ratchet
• 6" extension (3/8" drive)
• Torque wrench (10–80 ft-lb range)
• 24mm socket
• 6mm hex bit socket
• Fluid transfer pump (specialty)
• OBD2 scan tool that reads ATF temperature (specialty)
• Funnel with hose
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Toyota WS equivalent) - Qty: 6 quarts
• Transmission drain plug gasket/crush washer - Qty: 1
• Transmission fill plug gasket/crush washer - Qty: 1

---

📋 Before You Begin

• Park on a level surface, set the parking brake, and chock the rear wheels with wheel chocks.
• Raise the 4Runner and support it on four jack stands so it sits level.
• Locate the plugs first: the fill plug is on the transmission case side (commonly 24mm), and the drain plug is at the bottom (commonly 14mm) with an internal overflow/level plug (commonly 6mm hex).
• Connect your OBD2 scan tool and confirm it can display ATF temperature (this is the key to setting level correctly).
• Tip: Always loosen the fill plug first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove skid plates (if equipped)

• Use a 12mm socket with a 3/8" ratchet and extension to remove the front/underbody skid plate bolts.
• Set the skid plate and bolts aside in order.

Step 2: Confirm you can remove the fill plug

• Place the drain pan under the transmission area.
• Use a 24mm socket and ratchet to crack the fill plug loose (do not remove it yet).
• If the fill plug won’t budge, stop here—don’t drain the transmission until you know you can refill it.

Step 3: Drain the old transmission fluid

• Use a 14mm socket and ratchet to remove the drain plug and let the fluid drain into the drain pan.
• Let it drip until it slows to an occasional drip.
• Clean the drain plug and replace the crush washer with the new one.

Step 4: Reinstall drain plug

• Thread the drain plug in by hand first (to avoid cross-threading).
• Use a torque wrench with 14mm socket: Torque to 20 Nm (15 ft-lb).

Step 5: Pump in new WS fluid (initial fill)

• Remove the fill plug fully using the 24mm socket.
• Use the fluid transfer pump (specialty) to pump Toyota WS fluid into the fill hole until it begins to run back out.
• Tip: A fluid transfer pump is a hand pump that pushes fluid uphill.
• Install the fill plug finger-tight for now (so you can run the engine next).

Step 6: Warm the fluid and circulate it

• Start the engine and keep the 4Runner on level jack stands.
• With your foot on the brake, move the shifter slowly through P-R-N-D and back, pausing 2–3 seconds in each gear.
• Use the OBD2 scan tool to monitor ATF temperature.

Step 7: Set the fluid level at the correct temperature (overflow method)

• With the engine idling, watch ATF temperature on the scan tool.
• When ATF reaches 40–45°C (104–113°F), place the drain pan under the drain area again.
• Use a 6mm hex bit socket to remove the internal overflow/level plug.
• Correct level behavior at the target temperature:
  • If fluid dribbles out in a thin stream, let it slow to a drip (that’s correct).
  • If nothing comes out, the level is low—reinstall the overflow plug, add more fluid through the fill hole using the fluid transfer pump, then re-check.
  • If a heavy stream pours out, let it drain until it becomes a thin stream/drip at temp.
• Reinstall the overflow/level plug using the 6mm hex bit socket: Torque to 15 Nm (11 ft-lb).

Step 8: Final tighten the fill plug

• Shut the engine off.
• Remove and replace the fill plug crush washer (if your fill plug uses one), then reinstall the fill plug.
• Use a torque wrench with 24mm socket: Torque to 39 Nm (29 ft-lb).
• Wipe everything clean with shop towels.

Step 9: Reinstall skid plates

• Reinstall skid plates using the 12mm socket, ratchet, and extension.
• Tighten securely with the ratchet (snug, do not over-tighten).

---

✅ After Repair

• Start the engine and check underneath for leaks around the fill, drain, and overflow plugs.
• Take a 10–15 minute test drive, then re-check for leaks on your driveway.
• If shifting feels abnormal, re-check fluid level again using the same 40–45°C (104–113°F) temperature method.
• Dispose of used ATF properly (parts stores often accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$120 (parts only)

You Save: $130-$390 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
