🔧 Armada - Transmission Fluid Change

On your Armada, a “transmission fluid change” is typically a drain-and-refill (serviceable and DIY-friendly). It refreshes the ATF to help shift quality and transmission life without doing a power flush.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Transmission fluid gets very hot—let it cool enough to avoid burns.
• ⚠️ Support the Armada with jack stands on solid level ground; never rely on a jack alone.
• ⚠️ Keep the Armada level when draining and refilling, or the fluid level check will be wrong.
• ⚠️ Engine will run during level check—keep hands/clothes away from belts and fan.
• ⚠️ Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Metric socket set (8mm–19mm)
• 3/8" drive ratchet
• 6" extension (3/8")
• Torque wrench (10–80 ft-lbs range)
• Trim clip tool
• Long neck funnel
• Clean measuring container (marked quarts)
• Shop rags
• Brake cleaner spray
• OBD2 scan tool with ATF temperature (specialty)
• Infrared thermometer (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Nissan Matic S) - Qty: 6 quarts
• Transmission drain plug crush washer - Qty: 1
• Transmission pan gasket - Qty: 1
• Transmission strainer (filter) - Qty: 1

---

📋 Before You Begin

• Park the Armada on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Get the transmission warm with a 10–15 minute drive. Warm fluid drains more completely.
• Plan your level check method: use an OBD2 scan tool with ATF temperature (best) or an infrared thermometer on the transmission pan.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and level the Armada

• Use a floor jack (rated 3-ton minimum) to lift the front, then support with jack stands (rated 3-ton minimum).
• If you need more room, lift the rear and support it too so the Armada sits level front-to-rear.

Step 2: Remove the lower splash shield (if equipped)

• Use a trim clip tool to pop any plastic clips.
• Use a metric socket set (8mm–19mm) with a 3/8" drive ratchet to remove bolts and take the shield down.

Step 3: Drain the transmission fluid

• Place a drain pan (10-quart minimum) under the transmission drain plug.
• Use a metric socket set (8mm–19mm) with a 3/8" drive ratchet to remove the drain plug and let ATF drain fully.
• Pour the drained ATF into a clean measuring container (marked quarts) so you know how much to refill.

Step 4: Reinstall the drain plug with a new crush washer

• Clean the drain plug and sealing surface using shop rags and brake cleaner spray.
• Install a new transmission drain plug crush washer.
• Tighten the drain plug using a torque wrench (10–80 ft-lbs range): Torque to 34 N·m (25 ft-lbs).

Step 5 (Recommended): Drop the pan and replace the strainer (filter)

• Position the drain pan (10-quart minimum) under the transmission pan—more fluid will come out.
• Use a metric socket set (8mm–19mm) with a 3/8" drive ratchet and 6" extension (3/8") to remove the pan bolts evenly.
• Lower the pan carefully; keep it level so it doesn’t spill.
• Remove the strainer bolts using a metric socket set (8mm–19mm) and take the strainer off.
• Clean the pan and magnets with brake cleaner spray and shop rags. Magnets catch normal fine metal paste.
• Install the new strainer and tighten bolts with a torque wrench (10–80 ft-lbs range): Torque to 7.8 N·m (69 in-lbs).
• Install the new pan gasket, reinstall the pan, and tighten bolts evenly: Torque to 7.8 N·m (69 in-lbs).

Step 6: Refill with the correct ATF

• Under the hood, remove the transmission dipstick and insert a long neck funnel into the dipstick tube.
• Add the same amount you measured out (plus a little extra if you dropped the pan/changed the strainer) using Automatic transmission fluid (Nissan Matic S).
• Go slowly to avoid overfilling; use shop rags for any spills.

Step 7: Circulate fluid and set the level at temperature

• Start the engine and keep your foot on the brake.
• Move the shifter through P-R-N-D and back to P, pausing ~3 seconds in each gear.
• Monitor ATF temperature using OBD2 scan tool with ATF temperature (specialty). If you don’t have that, use an infrared thermometer (specialty) aimed at the transmission pan.
• With engine idling in P, check level on the dipstick at 35–45°C (95–113°F).
• Add ATF in small amounts through the funnel until it reaches the correct range on the dipstick for that temperature.

Step 8: Reinstall shields and lower the Armada

• Reinstall the splash shield using the trim clip tool and metric socket set (8mm–19mm).
• Lower the Armada safely using the floor jack (rated 3-ton minimum) and remove jack stands (rated 3-ton minimum).

---

✅ After Repair

• Test drive 10–15 minutes, then re-check the level again at 35–45°C (95–113°F) with the engine idling in P.
• Inspect underneath for seepage around the drain plug and pan gasket.
• Dispose of used ATF properly (most auto parts stores accept it).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$550 (parts + labor)

DIY Cost: $70-$170 (parts only)

You Save: $180-$380 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
