🔧 Transmission Fluid - Drain and Refill

Your Camry uses a sealed-style automatic transmission with Toyota WS fluid. The safe DIY service is a drain and refill, not a power flush. This helps refresh the fluid while keeping the transmission fill level correct.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• Work with the vehicle level. Fluid level changes if the car is tilted.
• Transmission fluid can be hot. Let the vehicle cool before draining.
• Use only Toyota WS fluid.
• Do not overfill. The final level must be checked at the correct fluid temperature.
• A scan tool or fluid temperature readout is strongly recommended for accurate fill level.
• Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• 10mm socket
• 24mm socket
• Torque wrench
• Fluid transfer pump
• Drain pan
• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Funnel
• Scan tool with transmission fluid temperature display

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Toyota WS) - Qty: 4-5 quarts for a drain and refill
• Transmission drain plug gasket - Qty: 1
• Transmission overflow/fill plug gasket - Qty: 1

---

📋 Before You Begin

• Park on a level surface.
• Set the parking brake and chock the rear wheels.
• Raise and support the vehicle securely on jack stands.
• Have the new fluid ready before opening the drain plug.
• Menu > Vehicle > Transmission Fluid Temp if your scan tool uses a live data menu.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Warm the transmission slightly

• Drive the vehicle for 10-15 minutes so the fluid flows easily.
• Do not make it fully hot. Warm is enough.
• Warm fluid drains faster.

Step 2: Raise and level the vehicle

• Use the floor jack and support the Camry with jack stands.
• Keep the vehicle as level as possible front to rear and side to side.

Step 3: Remove the under cover

• Use a 10mm socket to remove the lower splash shield fasteners.
• Set the cover and fasteners aside in order.

Step 4: Drain the old fluid

• Place the drain pan under the transmission drain plug.
• Use a 24mm socket to remove the drain plug.
• Let the fluid drain completely.
• Install a new drain plug gasket.
• Reinstall the drain plug and Torque to 39 Nm (29 ft-lbs).

Step 5: Refill with new WS fluid

• Remove the fill/overflow plug using the 24mm socket.
• Use the fluid transfer pump to add Toyota WS fluid through the fill hole.
• Add fluid until it just begins to dribble out of the fill opening.
• Install a new fill plug gasket.
• Snug the fill plug for now. Final level check comes next.

Step 6: Set the final fluid level

• Start the engine and keep it idling.
• Move the shifter slowly through each gear position, then back to Park.
• Use the scan tool to watch transmission fluid temperature.
• At the correct level check range, remove the fill/overflow plug again with the 24mm socket.
• If fluid dribbles out, the level is correct.
• If no fluid comes out, add WS fluid with the fluid transfer pump until it just drips out.
• Reinstall the plug and Torque to 39 Nm (29 ft-lbs).
• Level checks must be done carefully.

Step 7: Reinstall the under cover

• Use the 10mm socket to reinstall the splash shield.
• Make sure all clips and bolts are secure.

---

✅ After Repair

• Lower the vehicle and test drive gently.
• Check for leaks at both plugs.
• Recheck fluid level if you notice shifting problems or leaks.
• No battery reset or adaptation procedure is normally required for this service.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $60-$110 (parts only)

You Save: $120-$210 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.0 hours.

---
