🔧 Sonata - Transmission Fluid Drain & Refill

This service replaces a portion of your automatic transmission fluid by draining what’s in the pan and refilling with fresh Hyundai-spec fluid. It helps maintain smooth shifting and reduces wear, especially as the fluid ages from heat.

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

Assumption: your Sonata uses the non-dipstick level check plug method (common on this model).

---

⚠️ Safety & Precautions

• Work on a level surface; the fluid level check is inaccurate if the car is tilted.
• Transmission fluid can be very hot. Let the car cool enough to avoid burns.
• Always support the car with jack stands; never rely on a floor jack alone.
• Keep the engine running only when instructed, and keep hands/clothes away from belts and fans.
• Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 2-ton minimum)
• Jack stands (rated 2-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Shop rags
• 10mm socket
• Ratchet (3/8" drive)
• Socket set (metric)
• 24mm socket
• Torque wrench (10–100 Nm range)
• Fluid transfer pump (specialty)
• Long funnel
• OBD2 scan tool with ATF temperature data (specialty)

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Hyundai ATF SP-IV) - Qty: 6 quarts
• Transmission drain plug crush washer - Qty: 1
• Transmission level/check plug washer or O-ring (if equipped) - Qty: 1

---

📋 Before You Begin

• Park on level ground and chock the rear wheels.
• Warm the transmission with a 10–15 minute drive so the fluid drains more completely.
• Raise the front of the car with a floor jack and support with jack stands; keep the car as level as possible.
• Set up your scan tool so you can view transmission fluid temperature (often shown as “TFT” or “ATF Temp”).

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Remove the lower splash shield (if equipped)

• Use a 10mm socket and ratchet (3/8" drive) to remove the fasteners and lower the shield.
• Set the fasteners aside so none are lost.

Step 2: Drain the old transmission fluid

• Place the drain pan under the transmission drain plug.
• Use a 24mm socket and ratchet (3/8" drive) to remove the drain plug and let fluid drain fully.
• Replace the drain plug crush washer.
• Reinstall the drain plug and tighten with a torque wrench: Torque to 39 Nm (29 ft-lbs).

Step 3: Refill with Hyundai SP-IV fluid

• Locate the transmission fill point (commonly on top/side of the transmission area).
• Use your socket set (metric) and ratchet (3/8" drive) to remove any parts blocking access (commonly air ducting/air box fasteners).
• Use a long funnel or fluid transfer pump (specialty) to add Hyundai ATF SP-IV.
• Add roughly the same amount you drained (measure what came out using your drain pan markings or pour into a measured container).
• Tip: Add fluid slowly to prevent burps/overflow.

Step 4: Circulate fluid and bring ATF to level-check temperature

• Start the engine and keep your foot on the brake.
• Move the shifter through P-R-N-D and manual ranges (if equipped), pausing 2–3 seconds in each position.
• Leave the shifter in P with the engine idling.
• Use the OBD2 scan tool with ATF temperature data (specialty) to monitor ATF temp.

Step 5: Set the fluid level (check/overflow plug method)

• With engine idling and ATF temperature around 50–60°C (122–140°F), locate the transmission level/check plug on the transmission pan/side area.
• Place the drain pan underneath.
• Use the correct tool from your socket set (metric) to loosen/remove the check plug carefully.
• If fluid dribbles out in a thin stream, the level is close to correct.
• If nothing comes out, add small amounts of Hyundai ATF SP-IV using the fluid transfer pump (specialty) until it begins to drip from the check opening.
• When it becomes a slow drip/thin stream, reinstall the check plug and tighten with a torque wrench: Torque to 9 Nm (80 in-lbs).
• Clean any spilled fluid using shop rags.

Step 6: Reinstall the splash shield and lower the car

• Reinstall the splash shield using a 10mm socket and ratchet (3/8" drive).
• Lower the car safely using the floor jack.

---

✅ After Repair

• Test drive 10–15 minutes and confirm normal shifting (no flare, slip, or harsh engagement).
• Park on a clean spot and check underneath for any leaks around the drain and check plugs.
• Recheck level if you notice delayed engagement or unusual shifting after the service.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$350 (parts + labor)

DIY Cost: $45-$90 (parts only)

You Save: $135-$260 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3 hours.

---
