🔧 Acadia - Transmission Fluid Drain & Refill

This is a “drain-and-refill” service on your Acadia’s automatic transmission. You’ll drain the old fluid from the transmission pan, then refill with the correct GM-spec fluid and verify the level on the dipstick.

Difficulty Level: Intermediate | Estimated Time: 1.0-2.0 hours

Assumption: Your Acadia has a transmission dipstick (common on this model) for level checking.

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface and support the SUV with jack stands before going underneath.
• ⚠️ Transmission fluid can be hot—let the vehicle cool if needed and wear gloves and safety glasses.
• ⚠️ Keep the engine OFF while you’re under the vehicle (except when checking level from above, per steps).
• ⚠️ Do not use the parking brake alone—use wheel chocks and jack stands.
• 🔋 Battery disconnect is not required for a basic drain-and-refill.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 10-quart)
• 15mm socket
• 3/8" drive ratchet
• Torque wrench (3/8" drive)
• 10mm socket
• Trim clip tool
• Long-neck funnel
• Measuring jug (at least 2-gallon)
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (DEXRON-VI ATF) - Qty: 6 quarts
• Transmission drain plug gasket/washer - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear wheels.
• Do a short 10–15 minute drive so the fluid is warm (it drains more completely).
• Open the hood and locate the transmission dipstick so you know where you’ll refill.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and support the front safely

• Use a floor jack (rated 3-ton minimum) to lift the front of the SUV at the proper front jacking point.
• Set it down onto jack stands (rated 3-ton minimum) and gently shake-test for stability.

Step 2: Remove the splash shield (if equipped)

• Use a 10mm socket with a 3/8" drive ratchet to remove any bolts holding the shield.
• Use a trim clip tool to pop plastic clips without breaking them. Clip tool saves your knuckles.

Step 3: Drain the transmission fluid

• Position your drain pan (at least 10-quart) under the transmission pan drain plug.
• Use a 15mm socket with a 3/8" drive ratchet to loosen and remove the drain plug.
• Let the fluid drain until it slows to an occasional drip (usually 10–20 minutes).
• Pour the drained fluid into a measuring jug (at least 2-gallon) so you know how much to put back in.

Step 4: Reinstall the drain plug

• Wipe the drain plug area clean with shop towels.
• Install a new transmission drain plug gasket/washer if your plug uses one.
• Thread the plug in by hand first (prevents cross-threading), then tighten using a torque wrench (3/8" drive).
• Torque to 12 N·m (106 in-lbs)

Step 5: Refill with the correct fluid

• Lower the SUV off the jack stands (rated 3-ton minimum) using the floor jack (rated 3-ton minimum).
• Under the hood, remove the transmission dipstick and insert a long-neck funnel into the dipstick tube.
• Pour in DEXRON-VI ATF equal to what you measured coming out (most drain-and-refills are around 4–6 quarts).
• Reinstall the dipstick.

Step 6: Circulate fluid and set the final level

• Start the engine and keep your foot on the brake.
• Move the shifter slowly through P-R-N-D, pausing 2–3 seconds in each position, then return to P.
• With the engine idling on level ground, pull the dipstick, wipe it with shop towels, reinsert fully, then recheck.
• Add fluid in small amounts (about 1/4 quart at a time) through the long-neck funnel until it reads in the HOT operating range after the vehicle is warmed up.
• Don’t overfill—small adds only.

Step 7: Reinstall the splash shield and clean up

• If removed, reinstall the splash shield using the 10mm socket, 3/8" drive ratchet, and trim clip tool.
• Wipe any spilled fluid with shop towels and ensure nothing is left in the engine bay.

---

✅ After Repair

• Test drive 10–15 minutes, then recheck the dipstick level again on level ground with the engine idling.
• Look underneath for leaks around the drain plug area after the drive.
• Dispose of used ATF properly—most auto parts stores accept used fluid for recycling.

---

💰 DIY vs Shop Cost

Shop Cost: $220-$380 (parts + labor)

DIY Cost: $45-$90 (parts only)

You Save: $175-$290 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
