🔧 Highlander - Transmission Fluid Drain & Fill

Your Highlander uses a sealed automatic transmission (no dipstick). A proper service is a drain-and-fill plus an overflow level check at the correct fluid temperature so it’s neither underfilled nor overfilled.

Assumption: Your Highlander has Toyota WS-spec sealed 6-speed automatic with overflow-style level check (common on this model).

Difficulty Level: Intermediate | Estimated Time: 1.5-3 hours

---

⚠️ Safety & Precautions

• 🛑 Support the vehicle with jack stands on a level surface; never rely on a floor jack alone.
• 🔥 Transmission fluid can be hot; let the drivetrain cool and wear gloves and safety glasses.
• ⚙️ The level check is done with the engine running; keep hands/clothes away from moving parts.
• 🧱 Chock the wheels and keep the shifter in P with the parking brake on.
• 🔋 Battery disconnect is not required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (at least 10-quart)
• 10mm socket
• Ratchet (3/8")
• Socket extension (3/8")
• Trim clip removal tool
• Torque wrench (10–100 Nm range)
• Hex bit socket set (6mm, 8mm, 10mm)
• Fluid transfer pump (hand pump) (specialty)
• OBD2 scan tool that reads ATF temperature (specialty)
• Shop rags
• Brake cleaner spray
• Infrared thermometer

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Toyota WS equivalent) - Qty: 4–6 quarts
• Transmission drain plug gasket/crush washer - Qty: 1
• Transmission fill plug gasket/crush washer - Qty: 1
• Overflow/check plug gasket/crush washer - Qty: 1

---

📋 Before You Begin

• Park on a level surface; the transmission level check is inaccurate if the vehicle is tilted.
• Set parking brake, place shifter in P, and install wheel chocks.
• Gather your OBD2 scan tool and confirm you can view ATF Temperature (this is the temperature of the transmission fluid).
• Tip: Always loosen the fill plug first.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and level the vehicle

• Use a floor jack (rated 3-ton minimum) to lift the front, then the rear, and set the vehicle on jack stands (rated 3-ton minimum).
• Confirm the vehicle sits level (important for correct fluid level).

Step 2: Remove the lower engine/transmission under cover

• Use a 10mm socket, ratchet (3/8"), and trim clip removal tool to remove the fasteners and clips.
• Set the cover and hardware aside in a small pile so nothing is lost.

Step 3: Locate the transmission fill, drain, and overflow/check plugs

• Wipe the transmission case clean with shop rags and brake cleaner spray so dirt can’t fall into the openings.
• Use your hex bit socket set (6mm, 8mm, 10mm) to test-fit each plug (do not strip the hex).
• Fill plug: used to add fluid with the pump.
• Drain plug: drains fluid into the pan.
• Overflow/check plug: sets the final level when fluid is at the correct temperature.

Step 4: Loosen the fill plug first

• Place a drain pan (at least 10-quart) under the transmission area.
• Use the correct size from your hex bit socket set (6mm, 8mm, 10mm) with a ratchet (3/8") and socket extension (3/8") to crack the fill plug loose.
• If the fill plug will not loosen, stop here (draining first could leave you unable to refill).

Step 5: Drain the old transmission fluid

• Use the correct hex bit socket and ratchet (3/8") to remove the drain plug.
• Let fluid drain into the drain pan until it slows to a drip.
• Replace the drain plug gasket/crush washer with the new one.
• Reinstall the drain plug and use a torque wrench: Torque to 49 Nm (36 ft-lbs).

Step 6: Pump in new Toyota WS-spec fluid

• Insert the hose from the fluid transfer pump (hand pump) (specialty) into the fill port.
• Pump in new automatic transmission fluid (Toyota WS equivalent) until fluid begins to run out of the overflow/check opening (or until you’ve added roughly what you drained, if you’re not opening the check plug yet).
• Install a new fill plug gasket/crush washer, then thread the fill plug in by hand.
• Snug the fill plug with the hex bit socket and ratchet (3/8") (final torque comes after level set, if you removed it again).

Step 7: Set the fluid level using ATF temperature (overflow method)

• Connect your OBD2 scan tool that reads ATF temperature (specialty) and display ATF Temperature.
• Start the engine and keep your foot on the brake.
• Move the shifter slowly through R → N → D → S and back to P, pausing 2–3 seconds in each position to fill circuits.
• With engine still running, remove the overflow/check plug using the correct hex bit socket and ratchet (3/8").
• Watch ATF temperature on the scan tool and bring it to 40–45°C (104–113°F).
• At 40–45°C (104–113°F):
  • If fluid is a steady stream, let it drain until it becomes a thin drip.
  • If no fluid comes out, add fluid through the fill port using the fluid transfer pump (hand pump) (specialty) until it starts to drip from the overflow/check opening.
• Install a new overflow/check plug gasket/crush washer and reinstall the overflow/check plug.
• Use a torque wrench: Torque to 15 Nm (11 ft-lbs).
• Now torque the fill plug with a torque wrench: Torque to 49 Nm (36 ft-lbs).
• Tip: Temperature matters more than “how much you poured in”.

Step 8: Reinstall under cover and lower the vehicle

• Reinstall the under cover using the 10mm socket, ratchet (3/8"), and trim clip removal tool.
• Lower the vehicle safely using the floor jack (rated 3-ton minimum).
• Wipe down any spilled fluid using shop rags.

---

✅ After Repair

• With the engine running, inspect for leaks around the fill, drain, and overflow/check plugs.
• Road test 10–15 minutes. Confirm smooth shifts and no flare or slip.
• Recheck underneath for leaks after the test drive.
• Tip: Dispose of used ATF at a recycling center.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $45-$120 (parts only)

You Save: $130-$405 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
