🔧 Grand Cherokee - Automatic Transmission Fluid Service

This service replaces the automatic transmission fluid and pan/filter assembly on your Grand Cherokee. The transmission uses a sealed-style fill system, so the fluid level must be checked at a specific temperature with the engine running.

Difficulty Level: Advanced | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• ⚠️ Transmission fluid gets very hot. Let the exhaust and transmission cool before removing the pan.
• ⚠️ The vehicle must be level and safely supported on all four corners to set the fluid level correctly.
• ⚠️ Never work under a vehicle supported only by a jack. Always use jack stands.
• ⚠️ Keep the engine running only when instructed during the final fluid-level check.
• ⚠️ Use only Mopar 8 & 9 Speed ATF or fluid that specifically meets the required Chrysler/ZF specification.
• ⚠️ Do not overfill. Too much fluid can cause harsh shifting, foaming, and transmission damage.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack rated 3-ton minimum
• Jack stands rated 3-ton minimum
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan 10-quart minimum
• 8mm socket
• 10mm socket
• Ratchet 3/8-inch drive
• Torque wrench inch-pound 3/8-inch drive
• Torque wrench foot-pound 3/8-inch drive
• Hex bit socket 8mm
• Fluid transfer pump with hose
• Scan tool with live transmission temperature data
• Infrared thermometer
• Plastic trim clip tool
• Shop towels
• Brake cleaner aerosol

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission pan with integrated filter - Qty: 1
• Automatic transmission fluid meeting Mopar 8 & 9 Speed ATF specification - Qty: 6-7 quarts
• Transmission pan bolts - Qty: 1 set
• Fill plug sealing washer - Qty: 1

---

📋 Before You Begin

• Park your Grand Cherokee on a flat, level surface.
• Set the parking brake and place wheel chocks behind the rear wheels.
• Raise and support the vehicle level on four jack stands using a floor jack rated 3-ton minimum.
• A scan tool with live transmission temperature data is required. This tool shows the actual transmission fluid temperature while the engine is running.
• The final fluid level must be checked with transmission fluid temperature around 30-50°C / 86-122°F.
• No battery disconnect is required for this service.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and Level the Vehicle

• Use the floor jack rated 3-ton minimum to lift the front of your Grand Cherokee.
• Place jack stands rated 3-ton minimum under approved front support points.
• Lift the rear and place jack stands rated 3-ton minimum under approved rear support points.
• Use the infrared thermometer or a small level on the transmission pan area to help confirm the vehicle sits evenly front-to-back.
• Level matters for correct fluid fill.

Step 2: Remove the Lower Shield if Equipped

• Put on safety glasses and nitrile gloves.
• Use a plastic trim clip tool to remove any push clips from the lower shield.
• Use an 8mm socket or 10mm socket with a ratchet 3/8-inch drive to remove the shield fasteners.
• Set the shield and fasteners aside in order.

Step 3: Locate the Fill Plug First

• Find the transmission fill plug on the side of the transmission case.
• Use the hex bit socket 8mm and ratchet 3/8-inch drive to carefully loosen the fill plug.
• Do not drain the fluid until you know the fill plug can be removed.
• Always open the fill plug first.

Step 4: Drain the Old Transmission Fluid

• Place the drain pan 10-quart minimum under the transmission pan.
• If your pan has a drain plug, use the correct hex bit socket 8mm with the ratchet 3/8-inch drive to remove it.
• If there is no drain plug, loosen the pan bolts slowly with a 10mm socket and ratchet 3/8-inch drive.
• Leave a few bolts loosely installed at one end so the pan can tip down and drain in a controlled way.
• Let the fluid drain until it slows to a drip.

Step 5: Remove the Transmission Pan and Filter Assembly

• Support the pan with one hand.
• Use the 10mm socket and ratchet 3/8-inch drive to remove the remaining pan bolts.
• Lower the pan carefully. More fluid will spill.
• The filter is built into the pan assembly, so the whole pan/filter unit is replaced together.

Step 6: Clean the Mounting Surface

• Use shop towels to wipe the transmission case sealing surface.
• Use brake cleaner aerosol on a shop towel to clean residue from the sealing surface.
• Do not scrape the aluminum case with metal tools.
• Check that the old seal or gasket material is fully removed.

Step 7: Install the New Pan and Filter Assembly

• Position the new automatic transmission pan with integrated filter against the transmission.
• Start all pan bolts by hand first to avoid cross-threading.
• Use the 10mm socket and ratchet 3/8-inch drive to snug the bolts in a crisscross pattern.
• Use the torque wrench inch-pound 3/8-inch drive to tighten pan bolts evenly.
• Torque to 10 Nm (89 in-lbs)
• Small bolts strip easily. Go gently.

Step 8: Add Initial Transmission Fluid

• Install the fluid transfer hose into the fill opening.
• Use the fluid transfer pump with hose to add automatic transmission fluid meeting Mopar 8 & 9 Speed ATF specification.
• Add fluid until it begins to run back out of the fill hole.
• Let the excess fluid slow to a light drip.
• Temporarily install the fill plug finger-tight using the hex bit socket 8mm.

Step 9: Warm the Transmission and Cycle the Gears

• Connect the scan tool with live transmission temperature data.
• Start the engine while keeping your foot firmly on the brake pedal.
• Move the shifter slowly through P-R-N-D, pausing 3 seconds in each position.
• Return the shifter to Park.
• Watch transmission fluid temperature on the scan tool.
• The target check range is about 30-50°C / 86-122°F.

Step 10: Set the Final Fluid Level

• Keep the engine running and the transmission in Park.
• Place the drain pan 10-quart minimum under the fill plug area.
• Use the hex bit socket 8mm and ratchet 3/8-inch drive to remove the fill plug.
• If no fluid comes out, use the fluid transfer pump with hose to add fluid until it begins to run out.
• If a heavy stream comes out, let it drain until it becomes a thin trickle.
• The correct level is reached when fluid just dribbles from the fill hole at the correct temperature.
• Install a new fill plug sealing washer.
• Use the hex bit socket 8mm and torque wrench foot-pound 3/8-inch drive to tighten the fill plug.
• Torque to 35 Nm (26 ft-lbs)

Step 11: Reinstall the Lower Shield

• Shut the engine off.
• Use shop towels and brake cleaner aerosol to clean any spilled fluid.
• Reinstall the lower shield using the 8mm socket or 10mm socket with the ratchet 3/8-inch drive.
• Tighten the shield fasteners snugly by hand. Do not overtighten plastic shield hardware.

Step 12: Lower the Vehicle

• Use the floor jack rated 3-ton minimum to raise one end slightly and remove the jack stands rated 3-ton minimum.
• Repeat for the other end.
• Lower your Grand Cherokee slowly to the ground.
• Remove the wheel chocks.

---

✅ After Repair

• Start the engine and check underneath for leaks.
• Road test gently for 10-15 minutes. Confirm smooth engagement into Reverse and Drive.
• Recheck for leaks after the road test.
• No reset is normally required after a simple fluid and pan/filter service.
• If shift quality was poor before the service, a shop-level scan tool may be needed to check transmission adaptation values and stored faults.
• Dispose of used transmission fluid properly at a recycling center or auto parts store.

---

💰 DIY vs Shop Cost

Shop Cost: $450-$800 parts + labor

DIY Cost: $180-$350 parts only

You Save: $270-$450 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
