🔧 Explorer - Transmission Fluid Change

Your Explorer’s 6-speed automatic uses a “sealed” style system (no dipstick), so the fluid level is set through a level/check plug at a specific fluid temperature. A basic drain-and-fill refreshes a large portion of the fluid; a pan drop lets you clean the pan and replace the filter if equipped/serviceable.

Difficulty Level: Intermediate | Estimated Time: 1.5-3.0 hours

---

⚠️ Safety & Precautions

• ⚠️ Work on a level surface; the vehicle must be level to set fluid level correctly.
• ⚠️ Use jack stands—never rely on a floor jack alone.
• ⚠️ Transmission fluid can be hot; wear nitrile gloves and safety glasses.
• ⚠️ Keep the engine running only when instructed; keep hands clear of belts/fans.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Safety glasses
• Nitrile gloves
• Drain pan (10-quart minimum)
• Funnel with long hose
• Trim clip removal tool
• Shop rags
• Brake cleaner spray
• OBD2 scan tool with transmission fluid temperature PID (specialty)
• 3/8" drive ratchet
• 1/4" drive ratchet
• Torque wrench (inch-pound)
• Torque wrench (foot-pound)
• 8mm socket
• 10mm socket
• 13mm socket
• 19mm socket
• 5mm hex bit socket
• 6mm hex bit socket

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Motorcraft MERCON LV) - Qty: 6 quarts
• Transmission pan gasket - Qty: 1
• Transmission filter (if serviceable on your unit) - Qty: 1
• Drain/fill plug sealing washer (if equipped) - Qty: 1

---

📋 Before You Begin

• Park on level ground, set the parking brake, and place wheel chocks behind the rear tires.
• Plan to do a level check at temperature; you need an OBD2 scan tool that can display transmission fluid temperature (TFT). (TFT is the temperature of the fluid inside the transmission.)
• If your Explorer has a large lower splash shield, be ready to remove it for access.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Warm the transmission slightly

• Drive 10–15 minutes so the fluid is warm (not fully hot yet).
• Park on a level surface and leave the engine off for now.

Step 2: Raise and level the vehicle

• Use a floor jack (rated 3-ton minimum) to lift the front, then support with jack stands (rated 3-ton minimum).
• If needed, lift and support the rear as well so the vehicle sits level on stands.
• Give the vehicle a gentle push to confirm stability before going under.

Step 3: Remove the lower splash shield (if equipped)

• Use a trim clip removal tool for plastic clips and an 8mm socket or 10mm socket for bolts (varies by shield).
• Set fasteners aside in a small tray so they don’t get lost.

Step 4: Identify the fill plug BEFORE draining

• Locate the transmission case fill plug (commonly an internal-hex style plug).
• Use a 5mm hex bit socket or 6mm hex bit socket to confirm you can loosen it.
• Tip: If it won’t loosen, stop before draining.

Step 5: Drain the old fluid (drain plug method)

• Place a drain pan (10-quart minimum) under the transmission.
• If your transmission has a drain plug, remove it using a 19mm socket.
• Let it drain until it slows to a drip (typically 10–20 minutes).
• Reinstall the drain plug and Torque to 35 Nm (26 ft-lbs).

Step 6: If there is NO drain plug: drain by removing the pan

• Position the drain pan under one corner of the transmission pan.
• Use a 10mm socket to loosen pan bolts, leaving a few bolts threaded on one end so the pan can tip and drain.
• Carefully lower the pan once most fluid has drained.
• Clean the pan with brake cleaner spray and shop rags.
• If your unit has a removable filter, remove it with a 10mm socket (fastener style varies) and install the new filter.
• Install a new pan gasket and reinstall the pan.
• Tighten pan bolts evenly in a crisscross pattern and Torque to 10 Nm (89 in-lbs).

Step 7: Refill with MERCON LV

• Insert a funnel with long hose into the fill port.
• Add Motorcraft MERCON LV in the same amount you drained (most drain-and-fills are about 4–5 quarts).
• Reinstall the fill plug snug for now using a 5mm hex bit socket or 6mm hex bit socket.

Step 8: Set the fluid level at temperature (sealed level check)

• Connect your OBD2 scan tool with transmission fluid temperature PID (specialty) and display TFT.
• Start the engine with your foot on the brake.
• Move the shifter slowly through P-R-N-D and back to P, pausing ~2 seconds in each position.
• With the engine idling, wait until TFT is approximately 80–90°C (176–194°F).
• Place the drain pan under the level/check plug area and remove the check plug using the correct 5mm hex bit socket or 6mm hex bit socket (style varies).
• Correct level is typically a thin steady dribble from the check port at the specified temperature.
• If no fluid comes out, add MERCON LV through the fill port using the funnel with long hose until it begins to dribble, then let it slow to a thin stream.
• Reinstall the check plug and Torque to 12 Nm (106 in-lbs).
• Reinstall the fill plug and Torque to 35 Nm (26 ft-lbs).

Step 9: Reinstall the splash shield

• Reinstall the shield using the 8mm socket/10mm socket and any clips using the trim clip removal tool.

Step 10: Lower the vehicle

• Use the floor jack (rated 3-ton minimum) to lift slightly, remove jack stands (rated 3-ton minimum), then lower to the ground.

---

✅ After Repair

• Test drive 10 minutes, then check underneath for any leaks.
• Shift quality may improve over the next few drive cycles.
• If you did only a drain-and-fill and the fluid was very dark, consider doing a second drain-and-fill after 500–1,000 miles (avoids power-flushing risks).

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $60-$140 (parts only)

You Save: $110-$390 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-3.0 hours.

---
