🔧 Transmission Fluid - Drain & Fill

On your Equinox, the transmission uses a sealed-style fluid service process, so the fluid level is checked at a specific temperature with the vehicle running. The job is straightforward, but getting the level right matters a lot for shift quality and transmission life.

Difficulty Level: Intermediate | Estimated Time: 1.5-2.5 hours

---

⚠️ Safety & Precautions

• The transmission fluid can be hot. Wear gloves and safety glasses.
• Keep the vehicle level during the level-check step.
• Use jack stands. Never rely on a floor jack alone.
• Do not overfill. Overfilled transmission fluid can cause shifting issues and foaming.
• A scan tool is required to read transmission fluid temperature for final level check.
• If your Equinox has an undertray, remove it carefully before draining.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands (rated 3-ton minimum)
• Wheel chocks
• Drain pan
• 3/8-inch drive ratchet
• Metric socket set
• Torque wrench
• Fluid transfer pump
• Scan tool with transmission temperature data
• Safety glasses
• Nitrile gloves
• Shop towels
• Funnel

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (Dexron VI) - Qty: 6-8 quarts
• Transmission drain plug seal - Qty: 1
• Transmission fill plug seal - Qty: 1

---

📋 Before You Begin

• Park on a level surface and set the parking brake.
• Let the transmission warm slightly, but do not work on a very hot drivetrain.
• Raise and support the vehicle level on jack stands.
• Have the scan tool ready before you start the final fill check.
• Keep the engine off for draining and refilling, then run it only for the level check.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the vehicle

• Use the floor jack and jack stands to lift the vehicle level.
• Set wheel chocks at the tires still on the ground.
• Remove the lower splash shield if it blocks access to the transmission pan.

Step 2: Drain the old fluid

• Place the drain pan under the transmission drain plug.
• Use the correct metric socket or ratchet to remove the drain plug.
• Let the fluid drain completely.
• Replace the drain plug seal with a new one.
• Reinstall the drain plug and Torque to 18 Nm (13 ft-lbs).

Step 3: Refill the transmission

• Locate the fill plug on the transmission case.
• Use the correct metric socket to remove the fill plug.
• Use the fluid transfer pump to add Dexron VI transmission fluid.
• Add fluid until it begins to slightly run back out of the fill opening.
• Install the fill plug loosely for the level check.

Step 4: Set the final fluid level

• Start the engine and keep the vehicle level.
• Use the scan tool to monitor transmission fluid temperature.
• With the engine running, cycle the shifter slowly through all gear positions, then return to Park.
• When fluid temperature is in the proper check range, remove the fill plug again.
• Add or remove fluid as needed until a thin stream or steady drip is present at the fill opening.
• Reinstall the fill plug and Torque to 18 Nm (13 ft-lbs).

Step 5: Reassemble and inspect

• Reinstall the splash shield with the correct socket or fasteners.
• Lower the vehicle.
• Check for leaks around both plugs.

---

✅ After Repair

• Test drive gently and confirm normal shifting.
• Recheck for leaks after the drive.
• If you notice harsh shifts, delayed engagement, or slipping, the fluid level may need to be rechecked.
• Dispose of used fluid properly at a recycling center.

---

💰 DIY vs Shop Cost

Shop Cost: $180-$320 (parts + labor)

DIY Cost: $70-$140 (parts only)

You Save: $110-$180 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.0-1.5 hours.

---
