🔧 Transmission Fluid - Drain and Fill

On your Equinox, the transmission fluid service is a drain-and-fill procedure with a level check at the side plug. The transmission is sealed, so the fluid level must be set at a specific temperature for an accurate fill.

Assumption: This guide is for the 9-speed automatic transmission.

Difficulty Level: Intermediate | Estimated Time: 2-3 hours

---

⚠️ Safety & Precautions

• Transmission fluid can be hot. Let the vehicle cool before opening any plugs.
• Keep the vehicle level during the fill and level-check steps.
• Do not overfill. The level must be set at the correct fluid temperature.
• Use jack stands on a solid surface. Never work under a vehicle supported only by a jack.
• No battery disconnect is required for this service.

---

🔧 Required Tools

You'll need the following tools for this repair:

• Floor jack (rated 3-ton minimum)
• Jack stands
• Wheel chocks
• Safety glasses
• Nitrile gloves
• 8mm socket
• 10mm socket
• Ratchet
• Torque wrench
• Fluid transfer pump
• Drain pan
• Scan tool with transmission temperature display (specialty)
• Catch bottle or measuring jug
• Shop towels

---

🔩 Required Parts

HowToo sells all the parts you need for this repair:

• Automatic transmission fluid (DEXRON ULV) - Qty: 8-10 quarts
• Transmission drain plug seal - Qty: 1
• Transmission fill/level plug seal - Qty: 1

---

📋 Before You Begin

• Park on a level surface.
• Set the parking brake and chock the rear wheels.
• Raise and support the vehicle so it stays level.
• Warm the transmission slightly with a short drive if the fluid is cold. Do not get it hot enough to burn yourself.
• Have your scan tool ready to monitor transmission fluid temperature.

---

🔨 Step-by-Step Instructions

Follow these steps in order:

Step 1: Raise and secure the vehicle

• Use a floor jack and jack stands to lift and support the vehicle on a level surface.
• Make sure the vehicle is level front-to-rear and side-to-side.
• Set the parking brake and place wheel chocks behind the rear wheels.

Step 2: Remove the transmission under cover

• Use an 8mm socket and ratchet to remove the lower splash shield or under cover.
• Set the fasteners aside in order so they go back in the same places.

Step 3: Drain the old fluid

• Place a drain pan under the transmission.
• Use the correct socket or ratchet on the drain plug and remove it carefully.
• Let the fluid drain fully.
• Install a new drain plug seal.
• Torque to 18 Nm (13 ft-lbs).

Step 4: Reinstall the drain plug

• Clean the drain area with shop towels.
• Reinstall the drain plug by hand first, then tighten with a torque wrench.
• Torque to 18 Nm (13 ft-lbs).

Step 5: Fill the transmission

• Locate the fill/level plug on the transmission case.
• Remove the fill plug using the correct socket.
• Use a fluid transfer pump to add DEXRON ULV fluid through the fill opening.
• Add fluid until it just begins to dribble back out of the fill hole.
• Install the fill plug loosely for now.

Step 6: Run the gears and set fluid level

• Start the engine and keep the vehicle level.
• Use the brake pedal and shift slowly through all gear positions, then return to Park.
• Use a scan tool with transmission temperature display to monitor fluid temperature.
• When the fluid reaches the correct check range, remove the level/fill plug again.
• Add fluid until a steady thin stream turns into a light drip.
• Small drips are normal.
• Reinstall the level plug and tighten.
• Torque to 18 Nm (13 ft-lbs).

Step 7: Reinstall the under cover

• Use the 8mm socket and ratchet to reinstall the splash shield.
• Make sure all clips and fasteners are seated fully.

---

✅ After Repair

• Lower the vehicle and remove the wheel chocks.
• Start the engine and check for leaks under the vehicle.
• Drive the vehicle gently and confirm smooth shifting.
• Recheck for leaks after the test drive.

---

💰 DIY vs Shop Cost

Shop Cost: $250-$450 (parts + labor)

DIY Cost: $90-$160 (parts only)

You Save: $160-$290 by doing it yourself!

Shop labor rates vary but typically run $100-$150/hour. This repair takes a shop approximately 1.5-2.5 hours.

---
